Caterpillar C18
Maintenance schedule, common problems & OEM parts breakdown
The Caterpillar D9 is a large track-type tractor and the primary Cat platform used in engineer support tractor roles. Powered by the Cat C18 ACERT inline-six diesel displacing 18.1 litres, the D9T (produced 2004–2020) delivered a net output of 306–325 kW (410–436 hp) at 1,800 rpm while the successor D9 (launched 2020) raised net output to 328–337 kW (440–452 hp) at 1,750 rpm across Tier 4 Final/Stage V and lesser-regulated configurations. Operating weight varies by configuration: the D9T with SU-blade and single-shank ripper sits at approximately 47,900 kg (105,600 lb), while the current D9 reaches approximately 49,988 kg (110,225 lb) in full field-ready trim. The D9 line spans an unbroken production history from the D9G (1961) through the D9H, D9L, D9N, D9R, D9T, and the present D9, with each generation advancing engine technology, emissions compliance, and undercarriage design. Configurations offered across the C18-era machines include Semi-U blade, Universal blade, and Variable Power Angle Tilt blade options combined with single- or multi-shank rear rippers, plus specialised Waste Handler and landfill variants with elevated air-intake stacks and belly guards.
The transition from the D9R to the D9T in 2004 marked the most significant powertrain change in modern D9 history: the older V8 engine was replaced by the longitudinal C18 ACERT inline-six, bringing ACERT combustion technology, electronic unit injection, and ultimately Tier 4 Final compliance with no sacrifice in drawbar pull. The 2020 D9 further refined the driveline by adding a torque-converter stator clutch that reduces fuel consumption relative to the D9T, while extending planned-maintenance intervals and reducing greasing points through an integrated AutoLube system. In the used and parts market the D9T/D9 with its C18 engine occupies a uniquely active segment: C18 long blocks and short blocks circulate widely through Cat Certified Rebuild and third-party remanufacturers, making engine-out exchanges at the major overhaul point commercially practical. Military engineer corps — including those operating armoured D9 variants — have sustained global demand for C18 powertrain assemblies and heavy undercarriage components, keeping parts pipelines robust and resale values relatively firm even on high-hour machines that carry documented S·O·S service histories.
Below: full specifications, fluids & capacities, the factory service schedule, common service parts, verified fault codes, what owners discuss, attachment guidance, the complete assembly directory, and a serial-number reference. Complete parts lists with full OEM part numbers, exploded diagrams, quantities, and fitment data are available free in Heavy Parts AI.
Caterpillar C18 specifications
Engine
| Engine make and model | Caterpillar C18 ACERT turbocharged and aftercooled diesel |
| Gross power output | 522 kW (700 hp) at 1,900 rpm (high-output twin-turbo industrial configuration); 306–337 kW (410–452 hp) net in D9T/D9 dozer configuration — varies by configuration/series |
| Displacement | 18.1 L (1,104 cu in) |
| Cylinder configuration | Six cylinders, inline arrangement |
| Bore | 145 mm (5.7 in) |
| Stroke | 183 mm (7.2 in) |
| Compression ratio | 16.0:1 to 16.3:1 (varies by sub-variant) |
| Maximum torque | Approximately 2,375 Nm (1,752 lb-ft) at high-output rating; varies by configuration |
| Emissions standard | Tier 4 Interim / EU Stage IIIB and Tier 4 Final / EU Stage V variants available; earlier configurations used Tier 2/3 equivalent |
Weights
| Operating weight (D9T track-type tractor) | Approximately 47,900 kg (105,600 lb) with SU-blade and single-shank ripper |
| Operating weight (D9, current generation, launched 2020) | Approximately 49,988 kg (110,225 lb) in full specification |
| Operating weight (Terrier CEV variant) | Approximately 30,000–32,000 kg (66,139–70,548 lb); varies by armour configuration |
Dimensions
| Overall length (D9T/D9, hull stowed) | Approximately 6.3 m (20 ft 8 in) without blade; overall with blade and ripper varies by configuration |
| Overall length (Terrier CEV) | Approximately 9.3 m (30 ft 6 in) |
| Fording depth (D9T, unprepared) | 0.7 m (2 ft 4 in) |
| Track gauge | 2,250 mm (88.6 in) — D9T/D9 |
Performance
| Maximum road speed (D9T/D9) | 10.5 km/h (6.5 mph) forward; varies by configuration |
| Maximum road speed (Terrier CEV) | 70 km/h (43 mph) |
| Gradeability (D9T/D9) | Approximately 60% (varies by configuration and loading) |
| Excavator arm lift capacity (Terrier CEV) | Up to 3,000 kg (6,614 lb) |
| Drawbar pull (D9T) | Approximately 706 kN (158,730 lbf) — varies by configuration |
Service capacities (summary)
| Engine crankcase with filter | 37–38 L (9.7–10.0 US gal) — varies by source and configuration |
| Cooling system | 98–104 L (25.9–27.5 US gal) — varies by configuration/series |
| Fuel tank (D9T) | 821 L (217 US gal) |
| Hydraulic system (tank refill, D9T) | 89 L (23.5 US gal) |
Values vary by configuration, region, and serial range — confirm against your machine before planning transport or lifts.
C18 fluids & capacities
| System | Capacity | Recommended fluid |
|---|---|---|
| Engine Crankcase (with filters) — Cat C18 ACERT | 37–38 L (9.7–10.0 US gal); varies by source rounding | Cat DEO-ULS SAE 15W-40 (standard/warm); SAE 10W-30 preferred for moderate climates (-18 °C to 40 °C); Cat DEO-ULS SYN SAE 5W-40 for extended drain range (-30 °C to 50 °C); Cat DEO Cold Weather SAE 0W-40 below -25 °C. Meets ECF-2/ECF-3 and API CJ-4/CK-4. |
| Cooling System (total) | 98–104 L (25.9–27.5 US gal); varies by configuration/series | Cat ELC (Extended Life Coolant), EC-1 specification, premixed 50/50 with deionized water. Service life up to 12,000 hours standard; extended service available with mid-life extender. Do not mix with conventional coolants. |
| Fuel Tank | 821 L (217 US gal) | Ultra Low Sulfur Diesel (ULSD, max 15 ppm sulfur) as required by the C18 ACERT Tier 4 Final emissions system. |
| Power Train Compartment (transmission, steering clutches, brakes, bevel gear — combined) | 164 L (43.3 US gal) | Cat TDTO (Transmission/Drive Train Oil) SAE 30 for moderate to warm climates; SAE 10W for cold climates; SAE 50 for sustained high-load/high-ambient operations. Meets Cat TO-4 specification. Cat TDTO-TMS (Multi-Season) available for variable climate operations. |
| Final Drive (each side) | 15 L (3.9 US gal) per side | Cat TDTO SAE 30 (moderate/warm) or SAE 50 (high-load/hot); SAE 10W for cold climates. Cat FDAO (Final Drive and Axle Oil, FD-1 spec) is an approved higher-performance alternative. |
| Roller Frames (each) | 45 L (11.9 US gal) per frame | Cat TDTO SAE 30 (standard). Same TO-4 specification as power train and final drives. |
| Pivot Shaft Compartment | 30 L (7.9 US gal) | Cat TDTO SAE 30. Same TO-4 specification. |
| Hydraulic System (tank refill) | 89 L (23.5 US gal) | Cat HYDO Advanced 10 (SAE 10W, ISO VG 32) for cold to moderate climates; Cat HYDO Advanced 30 (SAE 30, ISO VG 68) for hot/high-ambient conditions. Extended drain to 3,000 hours standard; extended intervals available with Cat S·O·S oil analysis. |
| DEF Tank (Tier 4 Final machines only) | 36 L (9.5 US gal) | Cat DEF (Diesel Exhaust Fluid) meeting ISO 22241 / API certification. Do not substitute or dilute. |
| Grease (all lubrication points: pins, bearings, track adjusters) | As required per lubrication interval (no fixed tank) | Cat MPGM (Multipurpose Molybdenum Grease), NLGI Grade 2, lithium complex thickener. Cat Ultra 5Moly (NLGI 2, 5% MoS₂) for heavily loaded pivot and track pins in severe-duty applications. |
Capacities are refill values from factory literature — always fill to the dipstick/sight gauge, not the number.
Caterpillar C18 maintenance schedule
| Service interval | Tasks |
|---|---|
| Every 10 h |
|
| Every 50 h |
|
| Every 250 h |
|
| Every 500 h |
|
| Every 1,000 h |
|
| Every 2,000 h |
|
| Every 3,000 h |
|
Servicing the C18 beyond the schedule
Predictive Maintenance & Fluid Analysis for the C18-Powered D9
The C18 ACERT's 18.1-litre inline-six responds well to Cat S·O·S sampling at every 250-hour oil change. Pull engine, final-drive, transmission, and hydraulic samples simultaneously so trend lines develop in parallel. Elevated iron in final-drive oil is the earliest indicator of planetary gear distress in the D9's modular final drives. Coolant SCA concentration must stay within the specified range in the non-ELC fill; glycol in engine oil signals a failed liner O-ring — catch it early to avoid a block replacement on this engine.
Corrective & Common Repairs on the D9 C18 Platform
The C18's electronic unit injectors are a common wear item: rough idle, white smoke at cold start, and persistent misfires under load all point to injector calibration drift or tip erosion — address with Cat ET data logging before condemning. Final-drive oil seal failures are frequent on machines working in abrasive or wet underfoot conditions; the D9's modular final-drive design allows an in-field exchange. Track adjuster cylinder seals weep under sustained high-travel speeds; inspect the grease-relief valve and adjuster bore at every 500-hour track measurement.
Overhaul & Rebuild Points for the D9 / D9T
The C18 ACERT is typically pulled for a top-end overhaul between 10,000–12,000 hours, addressing valve train, injectors, and head gaskets; major in-frame or exchange overhauls follow at 15,000–18,000 hours. The D9's modular powertrain — transmission, bevel-gear group, and final drives each removable independently — enables component exchange without full strip-down. Undercarriage rebuild is typically triggered at 60–70 percent wear on track bushings and rollers, often coinciding with the first engine overhaul; Cat's elevated-drive-sprocket design concentrates wear on rebuildable components rather than the main frame.
Seasonal & Environment Servicing for the D9 C18
In sub-zero deployment, switch to low-viscosity Cat DEO-ULS and verify Cat ELC freeze protection before first start; use the optional diesel-fired coolant pre-heater to bring the C18 block to operating temperature before load. Track adjuster grease stiffens in freezing conditions — run the machine forward and reverse briefly after cold starts to re-seat frozen links before full-load pushing. In desert or high-dust environments, service the air-cleaner primary element more frequently than the standard 250-hour interval and clean the radiator and aftercooler fins with low-pressure air daily to maintain C18 charge-air cooling efficiency.
C18 common service parts
| Part number | Part | Notes | |
|---|---|---|---|
| 220-8678 | Seal-Ring | Fuel system service | Check fitment → |
| 326-1641 | Filter As-Water Sep & Fuel | Fuel system service | Check fitment → |
| 129-0375 | Bowl As-Water Collection | Fuel system service | Check fitment → |
| 133-5673 | Element | Fuel system service | Check fitment → |
| 141-0284 | Kit-Fuel Filter & Waterseparator | Fuel system service | Check fitment → |
Always confirm against your machine's serial number — cross-check any part in Heavy Parts AI before ordering.
C18 fault codes & troubleshooting
| Code | Meaning | Likely cause | What to do |
|---|---|---|---|
| E360(3) / 100-1 | Engine Oil Pressure Low — most severe level; triggers immediate engine protection shutdown after sustained low-pressure condition | Low oil level, aerated oil, plugged oil filter, failed oil pump, worn bearings, or faulty oil pressure sensor | Stop engine immediately; check oil level and condition; verify reading with a mechanical gauge before assuming sensor failure; inspect filter and pump if level is correct |
| E361(3) / 110-0 | Engine Coolant Temperature High — most severe level; triggers progressive power deration at one percent per second followed by engine shutdown if temperature is not reduced | Low coolant level, blocked radiator or heat exchanger, failed cooling fan, faulty water pump, failed head gasket, or malfunctioning thermostat | Reduce load and safely stop engine; check coolant level first; inspect for external leaks and fan operation; pressure-test cooling system before returning to service |
| 190-8 | Primary Engine Speed/Timing Sensor — Abnormal Frequency, Pulse Width, or Period | Incorrect sensor-to-tone-ring air gap, damaged tone wheel tooth, connector corrosion, or sensor wiring fault | Check primary sensor air gap with a feeler gauge and adjust to spec; inspect tone wheel for damage; test harness resistance and connector condition before replacing sensor |
| 723-8 | Secondary Engine Speed/Timing Sensor — Abnormal Frequency, Pulse Width, or Period; engine can continue running on the primary sensor alone but starting may be degraded | Incorrect air gap, tone wheel damage, or corroded connector on secondary (camshaft) sensor | Inspect and measure secondary sensor gap; verify secondary sensor resistance (600–1800 ohms); replace sensor if gap and harness checks are correct |
| E362(3) / 190-0 | Engine Overspeed — most severe level; logged as a shutdown event requiring a factory password to clear from ECM memory | Steep downhill grade without engine braking, turbocharger oil seal failure allowing oil into the intake air stream, or ingestion of combustible gases through the air intake | Do not restart without investigating the cause; inspect turbocharger for oil leakage into the air inlet; verify no combustible atmosphere at the air intake; engage compression braking on grades; obtain factory password through a Cat dealer to clear the event |
| 2458-2 | DPF Differential Pressure Sensor — Erratic, Intermittent, or Incorrect Signal; ECM receives an implausible pressure differential across the diesel particulate filter (applicable to Tier 4 Interim and Tier 4 Final C18 variants equipped with DPF) | Soot-plugged sampling ports, most common on machines with high idle time or short-cycle operation; sensor wiring fault; failed sensor | Clean both DPF pressure sampling ports before replacing the sensor — this resolves the majority of 2458-2 codes at no parts cost; confirm resolution with Cat ET after cleaning |
| E995(2) / 3719-16 | DPF Soot Loading High — ECM estimates soot load is elevated; first activation triggers an engine shutdown, after which the engine can be restarted but power progressively decreases as soot load continues to rise (applicable to Tier 4 Interim and Tier 4 Final C18 variants equipped with DPF) | Extended low-load or idle operation preventing passive regeneration, failed active regeneration due to ARD system fault, or DPF requiring cleaning or replacement | Perform a stationary active regeneration via Cat ET; resolve any associated ARD or air system codes first; if regeneration fails, have DPF professionally cleaned or replaced |
| 651-5 / 652-5 / 653-5 | Engine Injector Cylinder 1 / 2 / 3 — Current Below Normal on injector solenoid circuit (one code per affected cylinder) | Open circuit or high-resistance fault in the injector wiring harness, corroded injector connector, or failed injector solenoid on the identified cylinder; two cylinders share a common supply wire so a single harness fault may trigger codes on two cylinders simultaneously | Check injector harness connectors on the flagged cylinder for corrosion and secure seating; measure solenoid resistance; use Cat ET to perform an injector solenoid test before condemning the injector |
| 110-3 / 110-4 | Engine Coolant Temperature Sensor — Voltage Above Normal (110-3) or Voltage Below Normal (110-4); indicates a sensor or circuit fault rather than actual overheating | Open circuit or short to a voltage source on the signal wire (110-3); short to ground on the signal wire (110-4); failed sensor element | Inspect sensor wiring and connector first; compare ECM-reported temperature against a manual gauge or infrared reading; replace sensor if wiring is intact and reading is implausible |
| 100-3 / 100-4 | Engine Oil Pressure Sensor — Voltage Above Normal (100-3) or Voltage Below Normal (100-4); indicates a sensor or circuit fault, not necessarily actual low oil pressure | Open circuit on the signal wire driving voltage above the valid range, or short to a voltage source (100-3); short to ground or open return circuit (100-4); failed sensor; connector corrosion | Compare ECM pressure reading against a mechanical gauge to determine whether low pressure is genuine or a sensor artefact; inspect and clean connector; replace sensor if wiring checks out |
Codes and remedies are general guidance for this model family — always confirm with diagnostic tooling and your dealer before major repairs.
C18 attachments & work tools
Engine & Power Identity
The Cat D9 (current generation, released 2020) and its predecessor the D9T are the large track-type tractors powered by the Cat C18 ACERT inline-six engine displacing 18.1 L. Net power is 337 kW (452 hp) on Tier 2/3-equivalent builds and 328 kW (440 hp) on Tier 4 Final/EU Stage V builds, both at 1,750 rpm. The D9T used the same C18 ACERT platform; Caterpillar upgraded to Tier 4 Final emissions compliance in 2014 before the D9 replaced it.
Semi-Universal (SU) Blade Family
The standard Semi-Universal (9SU) blade measures 4,350 mm (171.3 in) wide and 1,934 mm (76.1 in) tall with a rated capacity of 13.6 m³ (17.8 yd³) and a maximum digging depth of 606 mm (23.9 in). An abrasion-resistant SU variant is offered for hard-rock and high-wear duty; a Push Plate variant replaces the mouldboard cutting edge with a flat contact surface for scraper-pan assist and pipeline work. The SU blade is mounted via the Tag-Link push-arm system.
Universal (U) Blade Family
The 9U blade is wider at 4,680 mm (184.3 in) with the same 1,934 mm (76.1 in) height, offering a larger capacity of 16.6 m³ (21.7 yd³), making it the preferred choice for loose, light materials and bulk earthmoving in soft ground. Maximum tilt stroke is 1,014 mm (39.9 in) and blade weight is approximately 5,450 kg (12,016 lb). An abrasion-resistant U variant is available for aggressive-wear environments.
High-Volume & Specialty Blade Variants
For coal stockpile and light-material applications, a Coal blade reaches approximately 36.8 m³ (48.2 yd³) capacity, while a Woodchip U-blade extends to approximately 46.1 m³ (60.3 yd³) with a distinctive wing geometry. A Semi-Universal Landfill blade is rated around 28.2 m³ (36.8 yd³) and a Universal Landfill variant at approximately 38.8 m³ (50.8 yd³); both are available through Cat Work Tools and require no hydraulic circuit modifications beyond standard dual-tilt if fitted.
Ripper Attachments — Single-Shank
The standard single-shank rear ripper develops 158 kN (35,520 lbf) penetration force to a maximum depth of 1,231 mm (48.5 in) and a pryout force of 332 kN (74,637 lbf), weighing approximately 4,854 kg (10,701 lb). A deep-rip configuration increases penetration force to 172 kN (38,667 lbf) and extends maximum depth to 1,727 mm (68.0 in). Optional CapSure hammerless tip protectors enable tool-free tip changes.
Ripper Attachments — Multi-Shank
The multi-shank adjustable parallelogram ripper accepts one, two, or three shanks in individual pockets, giving the operator flexibility for lighter ripping in less consolidated materials. With three shanks fitted, penetration force is approximately 154 kN (34,621 lbf) per shank to a standard depth of 798 mm (31.4 in), with a combined pryout capacity of 361 kN (81,156 lbf). An optional Automatic Ripper Control system adjusts ground speed and shank depth in real time to prevent track slip.
Blade Mounting & Coupler System
Both SU and U blade families use the Tag-Link push-arm mounting architecture in which a single diagonal link per side transmits lateral loads directly to the main frame. Blade lift is controlled by twin hydraulic cylinders; a standard single-tilt cylinder provides pitch adjustment, while the optional Dual-Tilt kit adds a second tilt cylinder for fore-and-aft blade pitch variation. Dual Tilt also activates the Automated Blade Assist function, which stores preset pitch angles for dig, carry, and spread positions.
Hydraulic System & Blade Control Arrangements
The main hydraulic system delivers up to 363 L/min (96 gpm) for steering and a dedicated implement circuit; lift-cylinder relief is set at 26,200 kPa (3,800 psi) and tilt-cylinder relief at 19,300 kPa (2,799 psi). The optional Cat Grade with 3D factory-integrated system uses dual GNSS receivers and Real Time Kinematic positioning to control both blade lift and tilt automatically against a 3D digital design surface. AutoCarry automates blade lift to maintain target blade load and minimise track slip.
Winch System
The optional rear-mounted PTO-driven variable-speed winch is factory-ordered or dealer-fitted on winch-ready tractors; it weighs approximately 1,790 kg (3,950 lb) base and approximately 3,700 kg (8,150 lb) with counterweight ballast. Recommended cable diameter is 28 mm (1.13 in); an alternative 32 mm (1.25 in) cable is available. The unit features variable-speed hydraulic drive, dual braking, and a three-roller fairlead; maximum line pull is approximately 63,500 kg (140,000 lb).
Track Shoe & Undercarriage Options
Standard Extreme Service (ES) shoes are 610 mm (24 in) wide; the range extends from 560 mm (22 in) up to 760 mm (30 in) Moderate Service shoes, with trapezoidal-hole and clipped-grouser variants for specific ground conditions. The current D9 features the DuraLink heavy-duty extended-life (HDXL) track link system with extended seal life; optional abrasion, waste-handling, cold-weather, and anti-packing round-hole undercarriage arrangements are available.
Guarding & Protection Packages
Bottom guard options range from partial to fully sealed configurations providing progressive undercarriage protection; fuel tank guards and optional transmission guard are available. The Waste Handler variant adds sealed bottom guards, clamshell-style idler guards, a turbine precleaner with dust ejector, perforated hood panels, and wrapped insulated exhaust shields. A High Debris special arrangement bundles elevated air intake, engine enclosure screens, and strengthened track guarding for land clearing, stumping, and landfill push.
Special Factory Arrangements
Caterpillar formally offers the D9-class machine in four documented special arrangements beyond the base configuration: High Debris, Stockpile, Waste Handling, and Sound (noise-reduction). A Cold Weather/Arctic package addresses hydraulic and cooling system requirements for sub-zero operation, and a Fire Suppression ready option provides pre-wired and pre-plumbed anchor points for aftermarket suppression systems.
Automation & Technology Work-Tool Options
Automated Blade Assist (ABA) is standard when Dual Tilt hydraulics are fitted. Cat Grade with 3D is a factory-integrated GNSS-based grade control option compatible with Leica, Topcon, and Trimble base stations; Slope Assist, a no-base-station version, automatically locks user-defined blade angle without external infrastructure. Automatic Ripper Control and AutoCarry are additional electronic options that can be specified at order.
All C18 assemblies by section
Every catalogued assembly group for the Caterpillar C18. Open an assembly to preview the parts inside — full OEM part numbers are available in Heavy Parts AI.
Air Inlet And Exhaust System
241-6668 Air Cleaner Gp
| 12***71 | Tube | 2 |
| 24***68 | Air Cleaner Group | 1 |
| 29***73 | Reducer | 2 |
240-9438 Air Cleaner Gp
| 09***28 | Indicator-Air Filter Change; (Air Filter Service) | 1 |
| 10***49 | U-Bolt | 2 |
| 11***84 | Strip | 2 |
247-9632 Air Cleaner Gp
| 11***48 | Gasket | 2 |
| 14***33 | Flange; (Exhaust 8in.) | 2 |
| 14***36 | Elbow As-Exhaust | 1 |
254-5295 Air Cleaner Gp
| 14***46 | Gasket; (10-In) | 2 |
| 14***47 | Flange | 2 |
| 14***52 | Elbow As-Exhaust; (90 Deg) | 1 |
243-0897 Air Cleaner Gp
| 15***14 | Precleaner Group; -Air Cleaner | 1 |
| 15***36 | Air Cleaner Group | 1 |
| 18***02 | Filter Element As-Air; (Secondary) | 1 |
240-9439 Air Cleaner Gp
| 09***28 | Indicator-Air Filter Change; (Air Filter Service) | 1 |
| 10***49 | U-Bolt | 2 |
| 11***45 | Clamp-Hose | 2 |
241-6667 Air Cleaner Gp
| 24***66 | Hose | 1 |
| 24***67 | Air Cleaner Group | 1 |
| 25***59 | Bracket As | 1 |
294-9976 Air Cleaner Gp
| 11***48 | Gasket | 2 |
| 14***53 | Cap As-Rain; (Exhaust)(Exhaust Fitting) | 1 |
| 16***27 | Strap | 2 |
300-4978 Air Cleaner Gp
| 24***30 | Strap | 5 |
| 26***76 | Bracket | 1 |
| 30***78 | Air Cleaner Group | 1 |
151-7736 Air Cleaner Gp
| 15***36 | Air Cleaner Group | 1 |
| 24***09 | Filter Element As-Air; (Primary) | 1 |
| 24***10 | Filter Element As-Air; (Secondary) | 1 |
246-8413 Air Cleaner Gp
| 0S***88 | Bolt,Machine; Hose Assembly Mounting,Hose Assembly To Transmission,And To Torque Converter | 3 |
| 17***72 | Elbow | 1 |
| 24***13 | Air Cleaner Group | 1 |
246-6087 Air Cleaner Gp
| 10***49 | U-Bolt | 2 |
| 11***45 | Clamp-Hose | 2 |
| 11***84 | Strip | 2 |
296-2966 Air Cleaner Gp -Fan Drive
| 11***48 | Gasket | 1 |
| 14***33 | Flange; (Exhaust 8in.) | 1 |
| 16***71 | Adapter As | 1 |
179-1482 Elbow Gp-Air Inlet
| 14***94 | Rivet | 4 |
| 17***82 | Elbow Group-Air Inlet | 1 |
| 24***18 | Guard As | 1 |
249-2672 Elbow Gp-Exhaust
| 12***29 | Clamp; (V-Band) | 2 |
| 23***96 | Hose | 2 |
| 24***02 | Tube As | 2 |
249-2671 Elbow Gp-Exhaust
| 0L***43 | Bolt 63.5 mm (3/8" X 2 1/2" -Cover Assembly To Fender | 10 |
| 12***35 | Seal-Integral | 1 |
| 18***32 | Elbow-Exhaust | 1 |
233-7482 Exhaust Gp
| 12***29 | Clamp; (V-Band) | 2 |
| 23***96 | Hose | 2 |
| 23***82 | Exhaust Group | 1 |
148-5233 Exhaust Gp-Flexible
| 10***92 | Stud-Taperlock; (3/8-16x3.93in) | 12 |
| 11***24 | Spacer; (11.13x19.05x47-mm Thk) | 12 |
| 14***33 | Seal; Packet Seal, Seal, Exhaust Group-Flexible | 1 |
299-4141 Fastener Gp-Aftercooler
| 14***57 | Plug | 2 |
| 29***41 | Fastener Group-Aftercooler | 1 |
243-4017 Guard Gp-Exhaust
| 14***57 | Plug | 2 |
| 24***17 | Guard Group-Exhaust | 1 |
232-1829 Lines Gp-Exhaust
| 14***57 | Plug | 2 |
| 23***29 | Lines Group-Air | 1 |
312-1164 Lines Gp-Turbocharger Air
| 0S***71 | Screw,Cap,Hexagon; Tube Assembly To Turbocharger And Elbow Mounting | 8 |
| 11***48 | Gasket | 3 |
| 16***71 | Adapter As | 1 |
297-5774 Lines Gp-Turbocharger Air
| 11***48 | Gasket | 1 |
| 24***77 | Muffler As | 1 |
| 24***78 | Muffler As | 1 |
192-0772 Manifold Gp-Exhaust
| 0S***71 | Screw,Cap,Hexagon; Tube Assembly To Turbocharger And Elbow Mounting | 8 |
| 11***48 | Gasket | 3 |
| 16***71 | Adapter As | 1 |
249-2673 Mounting Gp-Muffler
| 0S***71 | Screw,Cap,Hexagon; Tube Assembly To Turbocharger And Elbow Mounting | 8 |
| 11***48 | Gasket | 2 |
| 14***46 | Gasket; (10-In) | 1 |
243-6278 Muffler As
| 11***45 | Clamp-Hose | 2 |
| 24***06 | Hose | 1 |
| 24***78 | Muffler As | 1 |
243-6276 Muffler As
| 14***33 | Flange; (Exhaust 8in.) | 1 |
| 24***76 | Muffler As | 1 |
243-6277 Muffler As
| 24***77 | Muffler As | 1 |
| 2S***93 | Precleaner Cover Assembly | 1 |
| 2S***08 | Collector-Dust; (Air Precleaner) | 1 |
244-3709 Muffler Gp
| 13***02 | Clamp As; (Turbine)(Turbine) | 1 |
| 21***60 | Cartridge Group-Turbocharger | 1 |
| 21***61 | Cover | 1 |
254-3753 Muffler Gp
| 14***94 | Rivet | 24 |
| 23***95 | Base As | 1 |
| 25***53 | Muffler Group | 1 |
254-3751 Muffler Gp
| 13***02 | Clamp As; (Turbine)(Turbine) | 1 |
| 21***60 | Cartridge Group-Turbocharger | 1 |
| 21***61 | Cover | 1 |
254-3752 Muffler Gp
| 21***64 | Turbocharger Group | 1 |
| 21***52 | Turbocharger Group | 1 |
| 25***52 | Muffler Group | 1 |
259-8872 Pipe As-Exhaust
| 13***17 | Base As-Fuel Filter | 1 |
| 13***73 | Valve Group-Fuel Bypass; -Filter | 1 |
| 14***33 | Fitting | 1 |
150-1714 Precleaner Gp -Air Cleaner
| 06***10 | Plug-Steel Pipe | 1 |
| 15***14 | Precleaner Group; -Air Cleaner | 1 |
| 17***60 | Switch Group-Liquid Level; -Rear Engine Oil-Ster, Hydraulic Fan Oil-Engine On-Steering Oil, Engine Off-Auxiliary Coolant-Front Engine Oil-Brake Oil, Hoist-Engine Coolant-Tc Oil-Low, Cold | 1 |
246-8476 Shutoff Gp-Air
| 06***10 | Plug-Steel Pipe | 1 |
| 17***60 | Switch Group-Liquid Level; -Rear Engine Oil-Ster, Hydraulic Fan Oil-Engine On-Steering Oil, Engine Off-Auxiliary Coolant-Front Engine Oil-Brake Oil, Hoist-Engine Coolant-Tc Oil-Low, Cold | 1 |
| 22***37 | Tank-Fuel | 1 |
359-5393 Turbocharger Gp
| 06***10 | Plug-Steel Pipe | 1 |
| 17***60 | Switch Group-Liquid Level; -Rear Engine Oil-Ster, Hydraulic Fan Oil-Engine On-Steering Oil, Engine Off-Auxiliary Coolant-Front Engine Oil-Brake Oil, Hoist-Engine Coolant-Tc Oil-Low, Cold | 1 |
| 22***41 | Tank-Fuel | 1 |
234-5850 Turbocharger Gp
| 06***10 | Plug-Steel Pipe | 1 |
| 17***60 | Switch Group-Liquid Level; -Rear Engine Oil-Ster, Hydraulic Fan Oil-Engine On-Steering Oil, Engine Off-Auxiliary Coolant-Front Engine Oil-Brake Oil, Hoist-Engine Coolant-Tc Oil-Low, Cold | 1 |
| 22***39 | Tank-Fuel | 1 |
359-5392 Turbocharger Gp
| 06***10 | Plug-Steel Pipe | 1 |
| 17***60 | Switch Group-Liquid Level; -Rear Engine Oil-Ster, Hydraulic Fan Oil-Engine On-Steering Oil, Engine Off-Auxiliary Coolant-Front Engine Oil-Brake Oil, Hoist-Engine Coolant-Tc Oil-Low, Cold | 1 |
| 22***40 | Tank-Fuel | 1 |
Basic Engine
133-9907 Adapter Gp-Pump Drive
| 13***06 | Adapter | 1 |
| 13***07 | Adapter Group-Pump Drive; -Remote | 1 |
| 1B***67 | Ball Bearing | 2 |
278-5662 Base Gp-Valve Cover & Inj Harn
| 10***18 | Clip | 3 |
| 10***19 | Clip | 3 |
| 10***34 | Kit-Receptacle; (12-Pin)(Valve Cover & Inj Harness) | 1 |
283-6594 Bracket Gp-Support -Front Housing
| 0S***88 | Bolt,Machine; Hose Assembly Mounting,Hose Assembly To Transmission,And To Torque Converter | 1 |
| 0S***90 | Bolt; (3/8-16x2in)(Clip Thru Spacer To Bracket As) | 2 |
| 23***29 | Bracket As | 1 |
201-0566 Camshaft Gp
| 10***89 | Cover | 1 |
| 11***36 | Screw-Flat Head; (5/16-18x0.875-In) | 3 |
| 20***66 | Camshaft Group | 1 |
249-3098 Coupling Gp-Generator
| 0S***66 | Bolt-Pulley To Crankshaft Adapter | 6 |
| 24***98 | Coupling Group-Generator | 1 |
| 2S***36 | Washer,Flat Cover Assembly Mounting And Flywheel Housing Cover | 6 |
250-0792 Coupling Gp-Generator
| 0S***66 | Bolt-Pulley To Crankshaft Adapter | 6 |
| 0S***85 | Bolt; 12.7 mm (1/2") Diameter X 38.1 mm (1 1/2") Length Generator To Engine | 2 |
| 25***92 | Coupling Group-Generator | 1 |
270-1482 Coupling Gp-Generator
| 27***82 | Coupling Group-Generator | 1 |
| 27***85 | Plate-Coupling | 1 |
| 27***86 | Plate-Coupling | 2 |
223-4730 Cover Gp-Air Compressor
| 03***53 | Seal-O-Ring; (08.92mm Id) | 1 |
| 18***09 | Plug As; (High Temperature) | 1 |
| 1F***58 | Nut-Full; (1/2-13-Thd)(Air Lines) | 3 |
232-6635 Cover Gp-Cylinder Block
| 16***37 | Seal-Integral | 1 |
| 1A***29 | Bolt (1-1/8") Tube Assembly To Transfer Drive Case | 2 |
| 23***35 | Cover Group-Cylinder Block | 1 |
144-7184 Cover Gp-Engine Lifting Eye
| 14***84 | Cover Group-Engine Lifting Eye | 1 |
| 14***85 | Cover-Lifting Eye | 1 |
| 8T***89 | Locknut; (M10x1.15-Thd) | 1 |
159-6159 Cover Gp-Front Housing
| 03***55 | Locknut; (5/16-18-Thd)(Marked X) | 2 |
| 15***59 | Cover Group-Front Housing | 1 |
| 16***71 | Seal | 1 |
184-2453 Cover Gp-Rear Housing
| 0S***94 | Bolt (1 In. Long 3/8 In. Dia.); Plate Assembly To Support Assembly | 2 |
| 0S***19 | Bolt,Machine Gear Retaining Part Of Kit P/N 1w***46 | 2 |
| 16***37 | Seal-Integral | 1 |
239-4111 Cover Gp-Valve Mechanism
| 18***81 | Gear-Crankshaft; (80-Teeth) | 1 |
| 18***18 | Crankshaft As | 1 |
| 23***11 | Cover Group-Valve Mechanism | 1 |
150-3135 Cover Gp-Valve Mechanism
| 14***78 | Grommet | 1 |
| 15***35 | Cover Group-Valve Mechanism | 1 |
| 22***44 | Cover-Valve | 1 |
225-1148 Cover Gp-Valve Mechanism
| 22***48 | Cover Group-Valve Mechanism | 2 |
| 23***11 | Cover Group-Valve Mechanism | 2 |
341-6804 Cover Gp-Valve Mechanism
| 15***09 | Seal-Liner | 6 |
| 15***10 | Seal-Liner | 6 |
| 15***93 | Seal-Liner | 6 |
222-4412 Cover Gp-Valve Mechanism
| 14***78 | Grommet | 1 |
| 22***12 | Cover Group-Valve Mechanism | 1 |
| 24***37 | Seal; (Cover, Valve Mechanism) | 1 |
255-4650 Cover Gp-Valve Mechanism
| 16***81 | Cap-Crankshaft Bearing | 7 |
| 16***83 | Bolt; (7/8-14x7.5-In) | 14 |
| 25***50 | Cover Group-Valve Mechanism | 1 |
189-4917 Crankshaft Gp
| 16***81 | Cap-Crankshaft Bearing | 7 |
| 16***83 | Bolt; (7/8-14x7.5-In) | 14 |
| 18***17 | Crankshaft Group | 1 |
301-3018 Cylinder Block As
| 10***99 | Plug | 2 |
| 14***29 | Seal; (Drainback) | 1 |
| 1S***40 | Dowel; (30.23 mm X 9.37 mm) | 1 |
261-0052 Cylinder Block As
| 15***09 | Seal-Liner | 6 |
| 15***93 | Seal-Liner | 12 |
| 26***52 | Cylinder Block As | 1 |
323-8451 Cylinder Block As
| 10***99 | Plug | 2 |
| 14***29 | Seal; (Drainback) | 1 |
| 1S***40 | Dowel; (30.23 mm X 9.37 mm) | 1 |
229-8568 Cylinder Block As
| 15***09 | Seal-Liner | 6 |
| 15***10 | Seal-Liner | 6 |
| 15***93 | Seal-Liner | 6 |
267-4631 Cylinder Block As
| 10***99 | Plug | 2 |
| 14***29 | Seal; (Drainback) | 1 |
| 1S***40 | Dowel; (30.23 mm X 9.37 mm) | 1 |
261-0191 Cylinder Block Gp
| 12***47 | Guide-Valve; (0.51-mm Os)(Standard) | 0 |
| 12***75 | Guide-Valve; (Standard) | 24 |
| 12***12 | Guide-Valve; (0.13-mm Os)(Standard) | 0 |
223-7263 Cylinder Head As
| 14***71 | Bolt; (5/8-18x9-In) | 6 |
| 21***99 | Damper As | 1 |
| 22***63 | Cylinder Head As | 1 |
223-9250 Cylinder Head Gp
| 14***71 | Bolt; (5/8-18x9-In) | 6 |
| 20***00 | Damper As | 1 |
| 22***50 | Cylinder Head Group | 1 |
244-6893 Cylinder Head Gp
| 00***70 | Nipple-Strainer To Flange | 1 |
| 14***67 | Adapter; (Hosetail 3/4" Mlx1) | 1 |
| 16***02 | Plug; (3/4" Nb Screwed Bsp) | 1 |
262-1758 Damper Gp
| 00***70 | Nipple-Strainer To Flange | 1 |
| 14***67 | Adapter; (Hosetail 3/4" Mlx1) | 1 |
| 16***02 | Plug; (3/4" Nb Screwed Bsp) | 1 |
231-5385 Damper Gp
| 00***70 | Nipple-Strainer To Flange | 1 |
| 14***67 | Adapter; (Hosetail 3/4" Mlx1) | 1 |
| 16***02 | Plug; (3/4" Nb Screwed Bsp) | 1 |
245-4467 Drain Gp-Engine Oil
| 0L***70 | Bolt (2-1/4") Filler Tube Assembly To Transfer Drive Case | 6 |
| 19***67 | Washer-Hard; (13.5x30x12-mm Thk) | 4 |
| 1A***29 | Bolt (1-1/8") Tube Assembly To Transfer Drive Case | 2 |
245-4466 Drain Gp-Engine Oil
| 0L***70 | Bolt (2-1/4") Filler Tube Assembly To Transfer Drive Case | 6 |
| 19***67 | Washer-Hard; (13.5x30x12-mm Thk) | 4 |
| 1A***29 | Bolt (1-1/8") Tube Assembly To Transfer Drive Case | 2 |
293-6373 Drive Gp-Fan
| 0S***94 | Bolt (1 In. Long 3/8 In. Dia.); Plate Assembly To Support Assembly | 2 |
| 29***73 | Drive Group-Fan | 1 |
| 5M***94 | Washer; Bracket To Tee, Bracket To Block, Tube As. To Tee, Tube As. To Oil Cooler | 2 |
232-6577 Drive Gp-Fan
| 23***77 | Drive Group-Fan | 1 |
| 5P***24 | Bolt-Plt; (1/2unc X 2 1/4) | 14 |
| 5P***66 | Capscrew; (Hex Hd) (1/2-13 Nc X 1 1/2) (Gd 8 Z) | 2 |
6i-3638 Drive Gp-Pump
| 5J***94 | Screw,Cap,Socket He Manifold Mtg | 12 |
| 6I***38 | Drive Group-Pump; -Fuel Transfer Pump | 1 |
| 8L***13 | Strap-Cable(Tie 5.50" Long) | 6 |
314-6211 Fastener Gp-Coupling
| 2W***65 | Flywheel As | 1 |
| 31***11 | Fastener Group-Coupling | 1 |
| 3G***56 | Washer-Special; (5.0mm Thk) | 12 |
4p-6846 Fastener Gp-Front Housing
| 10***26 | Dowel | 1 |
| 4P***46 | Fastener Group-Front Housing; -Remote | 1 |
| 9X***72 | Bolt-Locking; (3/8-16x0.875-In) | 16 |
109-1657 Fastener Gp-Valve Mechanism
| 03***85 | Bolt-12 Point Hd-Engine Flywheel To | 6 |
| 0S***71 | Screw,Cap,Hexagon; Tube Assembly To Turbocharger And Elbow Mounting | 1 |
| 10***68 | Bearing-Sleeve | 1 |
9y-7571 Flywheel Gp
| 17***17 | Bracket | 1 |
| 17***19 | Mount As | 4 |
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 11 |
204-9316 Gear Gp-Camshaft
| 14***68 | Seal-Crankshaft; (Rear)(Flywheel Housing) | 1 |
| 16***29 | Bolt; (3/8-16x1.5-In)(Marked Z) | 8 |
| 16***31 | Bolt; (3/8-16x1.75-In)(Marked Y) | 7 |
207-0449 Gear Gp-Front
| 16***29 | Bolt; (3/8-16x1.5-In)(Marked Z) | 8 |
| 16***31 | Bolt; (3/8-16x1.75-In)(Marked Y) | 7 |
| 20***49 | Gear Group-Front | 1 |
234-5561 Guard Gp-Pulley
| 06***55 | Seal-O-Ring (Id=47.22mm) | 1 |
| 0L***70 | Bolt (2-1/4") Filler Tube Assembly To Transfer Drive Case | 1 |
| 0S***88 | Bolt,Machine; Hose Assembly Mounting,Hose Assembly To Transmission,And To Torque Converter | 14 |
178-8579 Housing Gp-Flywheel
| 0L***70 | Bolt (2-1/4") Filler Tube Assembly To Transfer Drive Case | 1 |
| 0S***71 | Screw,Cap,Hexagon; Tube Assembly To Turbocharger And Elbow Mounting | 2 |
| 0S***88 | Bolt,Machine; Hose Assembly Mounting,Hose Assembly To Transmission,And To Torque Converter | 16 |
257-3276 Housing Gp-Front
| 25***76 | Housing Group-Front | 1 |
| 27***29 | Rocker Arm Group | 3 |
| 6I***58 | Bridge-Valve | 12 |
244-5683 Housing Gp-Front -Sound Suppression
| 0S***95 | Bolt 1.25 In. (31.75 mm) Long Guard Assemblies To Radiator Guard | 4 |
| 12***63 | Eye-Lifting | 1 |
| 24***83 | Housing Group-Front; -Sound Suppression | 1 |
111-2088 Lifting Gp-Engine
| 11***88 | Lifting Group-Engine; (Rear) | 1 |
| 32***36 | Rocker Arm Group; -Non-Brake | 3 |
| 6I***58 | Bridge-Valve | 12 |
127-0564 Lifting Gp-Engine
| 0S***85 | Bolt; 12.7 mm (1/2") Diameter X 38.1 mm (1 1/2") Length Generator To Engine | 1 |
| 0S***94 | Bolt (1 In. Long 3/8 In. Dia.); Plate Assembly To Support Assembly | 2 |
| 10***92 | Stud-Taperlock; (3/8-16x3.93in) | 2 |
190-0009 Mechanism Gp-Fuel Pump & Valve
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 3 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 3 |
| 19***09 | Mechanism Group-Fuel Pump & Valve | 1 |
232-6576 Mounting Gp-Alternator
| 23***76 | Mounting Group-Alternator | 1 |
| 29***84 | Bracket | 1 |
| 2Y***29 | Nut-Hard; (M10 X 1.5) | 2 |
258-6773 Mounting Gp-Bracket -Panel
| 20***23 | Washer; (22x90x6-mm Thk) | 2 |
| 21***04 | Base As | 1 |
| 21***69 | Mount As | 2 |
295-2383 Mounting Gp-Bracket
| 06***05 | . Ring; Slide, Washer; (26x63.5x6-mm Thk) | 2 |
| 20***23 | Washer; (22x90x6-mm Thk) | 2 |
| 21***69 | Mount As | 2 |
295-2385 Mounting Gp-Bracket
| 06***05 | . Ring; Slide, Washer; (26x63.5x6-mm Thk) | 2 |
| 20***23 | Washer; (22x90x6-mm Thk) | 2 |
| 21***48 | Beam As | 1 |
237-4099 Mounting Gp-Engine & Generator
| 20***23 | Washer; (22x90x6-mm Thk) | 2 |
| 21***69 | Mount As | 2 |
| 23***99 | Mounting Group-Engine & Generator | 1 |
252-2326 Mounting Gp-Engine & Generator
| 20***23 | Washer; (22x90x6-mm Thk) | 2 |
| 21***69 | Mount As | 2 |
| 24***86 | Beam As | 1 |
282-6151 Mounting Gp-Engine & Generator
| 05***13 | Connector | 1 |
| 06***58 | Seal-O-Ring; (Oil Pan Drain Plug) | 1 |
| 0L***51 | Bolt Starting Engine Fuel Tank Bracket To Diesel Intake Manifold | 1 |
249-2791 Mounting Gp-Engine & Generator
| 20***23 | Washer; (22x90x6-mm Thk) | 2 |
| 21***69 | Mount As | 2 |
| 24***05 | Bracket As | 2 |
237-4098 Mounting Gp-Engine & Generator
| 11***48 | Gasket | 1 |
| 14***33 | Flange; (Exhaust 8in.) | 1 |
| 14***46 | Gasket; (10-In) | 1 |
282-6189 Mounting Gp-Engine & Generator
| 15***25 | Bolt; (7/16-14-2a-Thd) | 1 |
| 18***50 | Pin-Piston | 1 |
| 21***17 | Bolt; (Mj11x1.25x84-mm) | 4 |
242-0281 Mounting Gp-Engine & Generator
| 20***23 | Washer; (22x90x6-mm Thk) | 2 |
| 21***69 | Mount As | 2 |
| 23***02 | Beam As | 1 |
252-4846 Mounting Gp-Engine & Generator
| 20***23 | Washer; (22x90x6-mm Thk) | 2 |
| 21***69 | Mount As | 2 |
| 23***80 | Union; (3/4-14 Bspp Thd) | 2 |
282-6122 Mounting Gp-Engine & Generator
| 20***23 | Washer; (22x90x6-mm Thk) | 2 |
| 21***69 | Mount As | 2 |
| 23***80 | Union; (3/4-14 Bspp Thd) | 2 |
252-2327 Mounting Gp-Engine & Generator
| 20***23 | Washer; (22x90x6-mm Thk) | 2 |
| 21***69 | Mount As | 2 |
| 23***80 | Union; (3/4-14 Bspp Thd) | 2 |
212-8983 Mounting Gp-Engine & Generator
| 20***23 | Washer; (22x90x6-mm Thk) | 2 |
| 21***04 | Base As | 1 |
| 21***83 | Mounting Group-Engine & Generator | 1 |
282-6158 Mounting Gp-Engine & Generator
| 15***25 | Bolt; (7/16-14-2a-Thd) | 1 |
| 18***50 | Pin-Piston | 1 |
| 18***03 | Ring-Piston; (Intermediate) | 1 |
257-3113 Pan Gp-Oil -Engine
| 03***53 | Seal-O-Ring; (08.92mm Id) | 1 |
| 18***09 | Plug As; (High Temperature) | 1 |
| 25***13 | Pan Group-Oil; -Engine | 1 |
283-7669 Piston & Rod Gp
| 28***69 | Piston & Rod Group | 1 |
| 6V***65 | O-Ring - For Oil Fill Plug | 1 |
| 9S***10 | Plug; (Straight Thread O-Ring)(Cylinder Head) | 1 |
235-6393 Piston & Rod Gp
| 03***53 | Seal-O-Ring; (08.92mm Id) | 1 |
| 18***09 | Plug As; (High Temperature) | 1 |
| 23***93 | Piston & Rod Group | 1 |
353-9982 Plate As-Front Housing
| 18***08 | Plug As; (High Temperature) | 4 |
| 35***82 | Plate As-Front Housing | 1 |
| 6V***51 | Seal-O-Ring (Id=19.18mm) | 1 |
305-9196 Plug Gp-Cylinder Block
| 25***21 | Button | 1 |
| 27***91 | Screw-Arm Adjustment; (3/8-24x1.20-In) | 1 |
| 27***17 | Nut; (3/8-24-Thd) | 1 |
234-9222 Plug Gp-Cylinder Block
| 18***08 | Plug As; (High Temperature) | 5 |
| 23***22 | Plug Group-Cylinder Block | 1 |
| 6V***51 | Seal-O-Ring (Id=19.18mm) | 1 |
299-9570 Plug Gp-Cylinder Block
| 06***39 | Seal-O-Ring | 2 |
| 19***51 | Button; (24-mm Od) | 2 |
| 19***69 | Screw-Arm Adjustment; (9/16-18x2-In) | 2 |
299-9568 Plug Gp-Cylinder Head
| 06***39 | Seal-O-Ring | 1 |
| 19***51 | Button; (24-mm Od) | 1 |
| 19***69 | Screw-Arm Adjustment; (9/16-18x2-In) | 1 |
230-5378 Plug Gp-Cylinder Head
| 23***78 | Plug Group-Cylinder Head | 1 |
| 30***22 | Shaft As-Rocker Arm, Exhaust Manifold | 1 |
| 32***96 | Rocker Arm Group; -Intake | 4 |
328-4238 Rocker Arm Gp
| 32***38 | Rocker Arm Group; -Exhaust | 1 |
278-1929 Rocker Arm Gp
| 14***68 | Seal-Crankshaft; (Rear)(Flywheel Housing) | 1 |
| 27***29 | Rocker Arm Group | 1 |
320-2796 Rocker Arm Gp
| 14***67 | Seal Group-Crankshaft; (Front) | 1 |
| 32***96 | Rocker Arm Group; -Intake | 1 |
328-4236 Rocker Arm Gp -Non-Brake
| 24***68 | Support As | 1 |
| 32***36 | Rocker Arm Group; -Non-Brake | 1 |
| 5P***45 | Washer-Hard; (13.5x25.5x3-mm Thk)(Turbocharger Blanking Plate) | 8 |
319-0785 Seal Gp-Crankshaft -Rear
| 31***85 | Seal Group-Crankshaft; -Rear | 1 |
| 9L***41 | V-Belt; (Alternator) | 3 |
319-7401 Seal Gp-Crankshaft -Front
| 23***01 | Union; (3/4-14 Npsf Thd) | 1 |
| 2P***86 | Locknut-Bulkhead; (1-5/16-12-Thd) | 1 |
| 31***01 | Seal Group-Crankshaft; -Front | 1 |
238-0025 Support Gp-Engine
| 23***01 | Union; (3/4-14 Npsf Thd) | 1 |
| 23***25 | Support Group-Engine | 1 |
| 2P***86 | Locknut-Bulkhead; (1-5/16-12-Thd) | 1 |
7e-7646 V-Belt Set -Includes 3-Belts, Fan Drive
| 0L***43 | Bolt 63.5 mm (3/8" X 2 1/2" -Cover Assembly To Fender | 2 |
| 0S***90 | Bolt; (3/8-16x2in)(Clip Thru Spacer To Bracket As) | 1 |
| 5M***94 | Washer; Bracket To Tee, Bracket To Block, Tube As. To Tee, Tube As. To Oil Cooler | 3 |
284-8095 V-Belt Set -Includes 3-Belts, Fan Drive
| 06***55 | Seal-O-Ring (Id=47.22mm) | 1 |
| 06***97 | Cap-Oil Filler; (Engine Oil) | 1 |
| 24***42 | Tube As-Oil; (Filler) | 1 |
Cooling System
299-5913 Cover Gp -Top
| 23***01 | Union; (3/4-14 Npsf Thd) | 1 |
| 29***13 | Cover Group; -Top | 1 |
| 2P***86 | Locknut-Bulkhead; (1-5/16-12-Thd) | 1 |
299-2382 Drain Gp-Coolant
| 21***22 | Spider As-Fan; (9 Blades) | 1 |
| 29***82 | Drain Group-Coolant | 1 |
| 5P***28 | Capscrew; (Hex Hd) (1/2-13 Unc X 1.00, Gd 8 Z) | 6 |
309-0785 Drain Gp-Coolant
| 24***00 | Flange As | 1 |
| 30***85 | Drain Group-Coolant | 1 |
| 8T***24 | Washer-To Assemble Valve As And Plates | 10 |
302-7354 Drain Gp-Coolant
| 0S***94 | Bolt (1 In. Long 3/8 In. Dia.); Plate Assembly To Support Assembly | 1 |
| 30***54 | Drain Group-Coolant | 1 |
309-0787 Drain Gp-Coolant
| 00***70 | Nipple-Strainer To Flange | 1 |
| 11***36 | Valve As-Shutoff; (Jacket Water Heater) | 1 |
| 14***67 | Adapter; (Hosetail 3/4" Mlx1) | 1 |
218-4698 Fan Gp-Blower
| 00***70 | Nipple-Strainer To Flange | 1 |
| 11***36 | Valve As-Shutoff; (Jacket Water Heater) | 1 |
| 14***67 | Adapter; (Hosetail 3/4" Mlx1) | 1 |
211-4360 Fastener Gp-Water Pump
| 0L***52 | Capscrew (3/8 - 16 Nc X 3 1/4 Gd8, Hex) | 2 |
| 0S***88 | Bolt,Machine; Hose Assembly Mounting,Hose Assembly To Transmission,And To Torque Converter | 4 |
| 0S***94 | Bolt (1 In. Long 3/8 In. Dia.); Plate Assembly To Support Assembly | 5 |
250-0385 Flange Gp-Radiator
| 06***69 | Stem | 1 |
| 25***85 | Flange Group-Radiator | 1 |
| 29***03 | Tube | 1 |
245-4465 Lines Gp-Coolant Drain
| 12***72 | Seal-O-Ring (215.49mm Id) | 1 |
| 24***65 | Lines Group-Coolant Drain | 1 |
| 27***55 | Pump Group-Water | 1 |
243-2641 Lines Gp-Coolant Drain
| 15***98 | Seal-O-Ring | 1 |
| 24***41 | Lines Group-Coolant Drain | 1 |
| 24***32 | Pump Group-Water | 1 |
298-8502 Lines Gp-Water
| 12***72 | Seal-O-Ring (215.49mm Id) | 1 |
| 29***02 | Lines Group-Water | 1 |
| 31***55 | Pump Group-Water | 1 |
201-0824 Lines Gp-Water
| 12***72 | Seal-O-Ring (215.49mm Id) | 1 |
| 20***24 | Lines Group-Water | 1 |
| 28***74 | Pump Group-Water | 1 |
224-3239 Pump Gp-Water
| 18***07 | Clamp-Hose | 6 |
| 19***16 | Cap-Radiator; (Pressure) | 1 |
| 22***53 | Clip | 3 |
246-3132 Pump Gp-Water
| 12***29 | Clamp; (V-Band) | 2 |
| 13***43 | Clamp-Hose | 24 |
| 20***64 | Guard As-Fan; (Upper) | 1 |
336-2213 Pump Gp-Water
| 29***02 | Lines Group-Water | 1 |
| 30***86 | Radiator Group | 1 |
| 31***64 | Lines Group-Turbocharger Air | 1 |
280-7374 Pump Gp-Water
| 28***74 | Pump Group-Water | 1 |
| 29***08 | Radiator Group | 1 |
| 29***74 | Lines Group-Turbocharger Air | 1 |
314-5155 Pump Gp-Water
| 00***63 | Elbow, 90 Deg Street, 3/4in. N.P.T. | 1 |
| 00***26 | Connector; (Flared)(3/4-16 Thd, 47 mm Long) | 2 |
| 11***36 | Valve As-Shutoff; (Jacket Water Heater) | 1 |
276-4755 Pump Gp-Water
| 12***29 | Clamp; (V-Band) | 2 |
| 21***66 | Tube As | 1 |
| 21***54 | Tube As | 1 |
308-4894 Radiator Gp
| 1W***36 | Filter Element As-Air; (Secondary) | 1 |
| 1W***37 | Filter Element As-Air; (Primary) | 1 |
| 24***98 | Valve; (Vacuum) | 1 |
308-2686 Radiator Gp
| 1W***37 | Filter Element As-Air; (Primary) | 1 |
| 24***98 | Valve; (Vacuum) | 1 |
| 30***86 | Radiator Group | 1 |
296-5207 Radiator Gp
| 24***09 | Filter Element As-Air; (Primary) | 1 |
| 24***74 | Cover As | 1 |
| 29***07 | Radiator Group | 1 |
214-0588 Radiator Gp -Aftercooler
| 09***28 | Indicator-Air Filter Change; (Air Filter Service) | 1 |
| 10***49 | U-Bolt | 2 |
| 11***45 | Clamp-Hose | 2 |
214-0512 Radiator Gp
| 15***37 | Filter Element As-Air; (Primary) | 1 |
| 17***93 | Cover As | 1 |
| 17***12 | Body As | 1 |
Electrical And Starting System
5n-5692 Alternator Gp-Charging
| 14***59 | Bolt; (M6x1x275-mm) | 3 |
| 24***65 | Cable As | 1 |
| 5J***05 | Washer; (6.4x19.8x1.9-mm Thk) | 3 |
143-4495 Battery Charger
| 14***58 | Bolt | 2 |
| 14***95 | Battery Charger | 1 |
| 24***65 | Cable As | 1 |
290-4433 Battery Charger
| 14***57 | Angle | 1 |
| 14***58 | Bolt | 3 |
| 25***82 | Cable As; (Battery Positive) | 1 |
292-8006 Battery Charger
| 09***57 | Screw-Machine; (M6x1x8.6-mm) | 4 |
| 09***26 | Lockwasher-Tooth; (M4 Id) | 5 |
| 14***80 | Fuse; (10-Ampere)(European Sourced) | 1 |
261-6627 Battery Charger Gp
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 10***82 | Bolt-Socket Head; (M8x1.25x16-mm) | 4 |
| 15***76 | Cover As | 1 |
261-6626 Battery Charger Gp
| 09***28 | Screw; (Machine) (M4x0.7x12mm) | 1 |
| 09***26 | Lockwasher-Tooth; (M4 Id) | 3 |
| 15***72 | Box As; (Power Distribution) | 1 |
115-2421 Battery Gp
| 11***21 | Battery Group | 1 |
| 1B***82 | Bolt (1.25 In. Long X .313 In. Dia.) | 10 |
| 3N***34 | Nut-Spring (3/8-16 Thd) | 4 |
237-7206 Battery Gp
| 06***88 | Locknut; (1-11-1/2-Thd) | 1 |
| 10***50 | Bushing | 1 |
| 13***00 | Clip; (Tab) | 1 |
9x-9730 Battery Gp -Dry
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 10***82 | Bolt-Socket Head; (M8x1.25x16-mm) | 4 |
| 15***71 | Box Group-Connection; -Power Distribution | 1 |
237-7205 Battery Gp
| 06***88 | Locknut; (1-11-1/2-Thd) | 1 |
| 10***50 | Bushing | 1 |
| 13***00 | Clip; (Tab) | 1 |
301-4487 Battery Gp
| 03***95 | Terminal-Ring; (0000-Ga, 3/8-In Screw) | 2 |
| 18***58 | Cable; (0000-Ga)(180-cm) | 0 |
| 30***87 | Battery Group | 1 |
259-8712 Battery Gp
| 14***56 | Insulator | 2 |
| 25***12 | Battery Group | 1 |
| 31***97 | Terminal | 1 |
259-8746 Battery Gp
| 03***95 | Terminal-Ring; (0000-Ga, 3/8-In Screw) | 2 |
| 18***58 | Cable; (0000-Ga)(180-cm) | 0 |
| 25***46 | Battery Group | 1 |
240-0170 Box Gp-Connection -Power Distribution
| 24***70 | Box Group-Connection; -Power Distribution | 1 |
| 27***74 | Plate | 2 |
166-0845 Box Gp-Connection -Power Distribution
| 16***45 | Box Group-Connection; -Power Distribution | 1 |
| 27***74 | Plate | 2 |
241-6596 Box Gp-Connection -Power Distribution
| 03***95 | Terminal-Ring; (0000-Ga, 3/8-In Screw) | 2 |
| 18***58 | Cable; (0000-Ga)(180-cm) | 0 |
| 24***96 | Box Group-Connection; -Power Distribution | 1 |
154-9671 Box Gp-Connection -Power Distribution
| 15***71 | Box Group-Connection; -Power Distribution | 1 |
| 27***74 | Plate | 2 |
144-7930 Box Gp-Extension Terminal
| 03***95 | Terminal-Ring; (0000-Ga, 3/8-In Screw) | 2 |
| 14***30 | Box Group-Extension Terminal | 1 |
| 18***58 | Cable; (0000-Ga)(180-cm) | 0 |
301-1641 Box Gp-Junction
| 03***95 | Terminal-Ring; (0000-Ga, 3/8-In Screw) | 2 |
| 18***58 | Cable; (0000-Ga)(180-cm) | 0 |
| 30***41 | Box Group-Junction | 1 |
302-7362 Box Gp-Junction
| 03***95 | Terminal-Ring; (0000-Ga, 3/8-In Screw) | 2 |
| 18***58 | Cable; (0000-Ga)(180-cm) | 0 |
| 30***62 | Box Group-Junction | 1 |
323-5759 Bracket Gp-Terminal
| 23***66 | Cable As; (Ground Strap) | 1 |
| 32***59 | Bracket Group-Terminal | 1 |
| 8T***21 | Washer-Hard; (11x21x2.5-mm Thk)(M10x1.50x30mm) | 2 |
268-1239 Cable As
| 09***92 | Washer, Tooth | 4 |
| 24***38 | Circuit Breaker As; (800-Ampere) | 1 |
| 24***31 | Kit-Terminal; (Circuit Breaker) | 1 |
268-1238 Cable As
| 09***92 | Washer, Tooth | 4 |
| 24***37 | Circuit Breaker As; (800-Ampere) | 1 |
| 24***30 | Kit-Terminal; (Circuit Breaker) | 1 |
246-6853 Cable As -Copper Braid
| 24***25 | Switch-Auxiliary; (Single Pole, Dual Throw)(Circuit Breaker Posn Indicator) | 1 |
| 24***37 | Trip Unit | 1 |
| 24***41 | Harness As-Wiring; (Circuit Breaker)(4-Pin) | 1 |
268-1237 Cable As
| 26***37 | Cable As; -Black | 1 |
| 6V***78 | Nut; (10-32-Thd) | 2 |
| 8F***34 | Lockwasher; (External Teeth) | 2 |
245-2085 Cable As
| 24***25 | Switch-Auxiliary; (Single Pole, Dual Throw)(Circuit Breaker Posn Indicator) | 1 |
| 24***37 | Trip Unit | 1 |
| 24***41 | Harness As-Wiring; (Circuit Breaker)(4-Pin) | 1 |
246-6852 Cable As -Copper Braid
| 24***25 | Switch-Auxiliary; (Single Pole, Dual Throw)(Circuit Breaker Posn Indicator) | 1 |
| 24***37 | Trip Unit | 1 |
| 24***41 | Harness As-Wiring; (Circuit Breaker)(4-Pin) | 1 |
246-6868 Cable As -Copper Braid
| 24***25 | Switch-Auxiliary; (Single Pole, Dual Throw)(Circuit Breaker Posn Indicator) | 1 |
| 24***37 | Trip Unit | 1 |
| 24***41 | Harness As-Wiring; (Circuit Breaker)(4-Pin) | 1 |
246-6851 Cable As -Copper Braid
| 24***25 | Switch-Auxiliary; (Single Pole, Dual Throw)(Circuit Breaker Posn Indicator) | 1 |
| 24***37 | Trip Unit | 1 |
| 24***41 | Harness As-Wiring; (Circuit Breaker)(4-Pin) | 1 |
245-2084 Cable As
| 24***25 | Switch-Auxiliary; (Single Pole, Dual Throw)(Circuit Breaker Posn Indicator) | 1 |
| 24***37 | Trip Unit | 1 |
| 24***41 | Harness As-Wiring; (Circuit Breaker)(4-Pin) | 1 |
268-1236 Cable As
| 26***36 | Cable As; -Black | 1 |
| 6V***78 | Nut; (10-32-Thd) | 2 |
| 8F***34 | Lockwasher; (External Teeth) | 2 |
240-1622 Cable Gp -Ground Strap
| 09***92 | Washer, Tooth | 4 |
| 24***22 | Cable Group; -Ground Strap | 1 |
| 24***39 | Circuit Breaker As; (1250-Ampere) | 1 |
244-9796 Circuit Breaker As -Ul, Mccb, Lsi
| 09***92 | Washer, Tooth | 4 |
| 24***41 | Circuit Breaker As; (1600-Ampere) | 1 |
| 24***96 | Circuit Breaker As; -Ul, Molded Case Circuit Breaker, Lsi | 1 |
244-9868 Circuit Breaker As -Ul, Mccb, Lsi
| 09***92 | Washer, Tooth | 4 |
| 24***69 | Circuit Breaker As; (1200-Ampere) | 1 |
| 24***30 | Kit-Terminal; (Circuit Breaker) | 1 |
244-9864 Circuit Breaker As -Ul, Mccb, Lsi
| 09***92 | Washer, Tooth | 4 |
| 24***68 | Circuit Breaker As; (800-Ampere) | 1 |
| 24***30 | Kit-Terminal; (Circuit Breaker) | 1 |
248-3289 Circuit Breaker As -20-Ampere, Automatic Reset
| 09***92 | Washer, Tooth | 4 |
| 24***47 | Terminal-Circuit Breaker | 1 |
| 24***89 | Circuit Breaker As; -20-Ampere, Automatic Reset | 1 |
244-9780 Circuit Breaker As -Ul, Mccb, Lsi
| 09***92 | Washer, Tooth | 4 |
| 24***40 | Circuit Breaker As; (1250-Ampere) | 1 |
| 24***31 | Kit-Terminal; (Circuit Breaker) | 1 |
244-9808 Circuit Breaker As -Ul, Mccb, Lsi
| 09***92 | Washer, Tooth | 4 |
| 24***42 | Circuit Breaker As; (1600-Ampere) | 1 |
| 24***08 | Circuit Breaker As; -Ul, Molded Case Circuit Breaker, Lsi | 1 |
248-3288 Circuit Breaker Gp -Automatic Reset
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 3 |
| 16***16 | Insulator | 3 |
| 24***88 | Circuit Breaker As; -15-Ampere, Automatic Reset | 1 |
244-9919 Circuit Breaker As -Ul, Mccb, Lsi
| 09***92 | Washer, Tooth | 4 |
| 24***62 | Circuit Breaker As; (800-Ampere) | 1 |
| 24***30 | Kit-Terminal; (Circuit Breaker) | 1 |
242-8197 Circuit Breaker Gp
| 20***44 | Kit-Terminal; (Circuit Breaker) | 1 |
| 24***98 | Bracket | 1 |
| 24***09 | Circuit Breaker As; (150-Ampere) | 1 |
243-3540 Circuit Breaker Gp
| 20***45 | Kit-Terminal; (Circuit Breaker) | 1 |
| 24***98 | Bracket | 1 |
| 24***13 | Circuit Breaker As; (250-Ampere) | 1 |
315-8423 Circuit Breaker Gp
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 1 |
| 14***80 | Fuse; (10-Ampere)(European Sourced) | 1 |
242-8194 Circuit Breaker Gp
| 20***44 | Kit-Terminal; (Circuit Breaker) | 1 |
| 24***98 | Bracket | 1 |
| 24***08 | Circuit Breaker As; (125-Ampere) | 1 |
243-3542 Circuit Breaker Gp
| 24***42 | Circuit Breaker Group | 1 |
| 6V***78 | Nut; (10-32-Thd) | 2 |
| 8F***34 | Lockwasher; (External Teeth) | 2 |
243-5643 Circuit Breaker Gp
| 24***43 | Circuit Breaker Group | 1 |
| 24***68 | Circuit Breaker As; -Ul, Molded Case Circuit Breaker, Lsi | 1 |
| 28***08 | Harness As-Wiring | 1 |
6t-3645 Circuit Breaker Gp
| 09***92 | Washer, Tooth | 4 |
| 24***65 | Circuit Breaker As; (1200-Ampere) | 1 |
| 24***30 | Kit-Terminal; (Circuit Breaker) | 1 |
242-8199 Circuit Breaker Gp
| 20***56 | Kit-Terminal; (Circuit Breaker) | 1 |
| 24***98 | Bracket | 1 |
| 24***11 | Circuit Breaker As; (200-Ampere) | 1 |
243-3541 Circuit Breaker Gp
| 16***55 | Terminal | 1 |
| 24***14 | Circuit Breaker As; (400-Ampere) | 1 |
| 24***41 | Circuit Breaker Group | 1 |
243-4027 Circuit Breaker Gp
| 24***27 | Circuit Breaker Group | 1 |
| 24***96 | Circuit Breaker As; -Ul, Molded Case Circuit Breaker, Lsi | 1 |
| 28***08 | Harness As-Wiring | 1 |
242-8200 Circuit Breaker Gp
| 20***56 | Kit-Terminal; (Circuit Breaker) | 1 |
| 24***98 | Bracket | 1 |
| 24***12 | Circuit Breaker As; (225-Ampere) | 1 |
243-5650 Circuit Breaker Gp
| 14***56 | Insulator | 2 |
| 23***70 | Terminal | 1 |
| 24***50 | Circuit Breaker Group | 1 |
283-9217 Circuit Breaker Gp
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 1 |
| 14***80 | Fuse; (10-Ampere)(European Sourced) | 1 |
243-5646 Circuit Breaker Gp
| 24***46 | Circuit Breaker Group | 1 |
| 24***19 | Circuit Breaker As; -Ul, Molded Case Circuit Breaker, Lsi | 1 |
| 28***08 | Harness As-Wiring | 1 |
283-9215 Circuit Breaker Gp
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 2 |
| 14***95 | Battery Charger | 1 |
243-5645 Circuit Breaker Gp
| 24***45 | Circuit Breaker Group | 1 |
| 24***08 | Circuit Breaker As; -Ul, Molded Case Circuit Breaker, Lsi | 1 |
| 28***08 | Harness As-Wiring | 1 |
243-5649 Circuit Breaker Gp
| 1S***94 | Boot-Conduit 16mm (.63in) Id | 5 |
| 24***49 | Circuit Breaker Group | 1 |
| 26***93 | Connector | 1 |
283-9216 Circuit Breaker Gp
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 2 |
| 16***02 | Holder-Fuse | 3 |
243-5648 Circuit Breaker Gp
| 09***92 | Washer, Tooth | 4 |
| 24***48 | Circuit Breaker Group | 1 |
| 24***47 | Terminal-Circuit Breaker | 1 |
243-5651 Circuit Breaker Gp
| 16***16 | Insulator | 3 |
| 24***51 | Circuit Breaker Group | 1 |
| 28***07 | Panel As | 1 |
283-9212 Circuit Breaker Gp
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 3 |
| 16***16 | Insulator | 3 |
| 28***12 | Circuit Breaker Group | 1 |
242-8193 Circuit Breaker Gp
| 09***92 | Washer, Tooth | 4 |
| 24***93 | Circuit Breaker Group | 1 |
| 24***47 | Terminal-Circuit Breaker | 1 |
283-9213 Circuit Breaker Gp
| 14***56 | Insulator | 2 |
| 28***13 | Circuit Breaker Group | 1 |
| 31***98 | Terminal | 1 |
283-9214 Circuit Breaker Gp
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 16***02 | Holder-Fuse | 2 |
| 19***57 | Fuse; (4-Ampere)(Us Sourced) | 1 |
242-8198 Circuit Breaker Gp
| 20***56 | Kit-Terminal; (Circuit Breaker) | 1 |
| 24***98 | Bracket | 1 |
| 24***10 | Circuit Breaker As; (175-Ampere) | 1 |
300-9744 Conduit Gp-Electrical -Block Heater
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 2 |
| 14***95 | Battery Charger | 1 |
284-9227 Connection Gp-Electrical
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 1 |
| 14***80 | Fuse; (10-Ampere)(European Sourced) | 1 |
323-5760 Connection Gp-Electrical
| 16***02 | Holder-Fuse | 2 |
| 16***35 | Contactor | 1 |
| 19***58 | Fuse; (6-Ampere)(Us Sourced) | 1 |
237-6169 Connection Gp-Electrical
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 2 |
| 16***02 | Holder-Fuse | 4 |
284-9232 Connection Gp-Electrical
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 16***02 | Holder-Fuse | 2 |
| 19***57 | Fuse; (4-Ampere)(Us Sourced) | 1 |
284-9230 Connection Gp-Electrical
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 1 |
| 14***80 | Fuse; (10-Ampere)(European Sourced) | 1 |
235-8370 Contactor Gp -Heaters
| 16***02 | Holder-Fuse | 2 |
| 16***35 | Contactor | 1 |
| 23***70 | Contactor Group; -Heaters | 1 |
237-0112 Contactor Gp -Battery Charger
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 10***66 | Bezel | 1 |
| 15***05 | Control Group-Engine Monitoring | 1 |
261-6628 Contactor Gp
| 09***26 | Lockwasher-Tooth; (M4 Id) | 1 |
| 09***66 | Washer; (Hard) (4.5x9x1mm Thk) | 1 |
| 10***56 | Strap-Cable | 1 |
261-7137 Contactor Gp -Heaters
| 15***10 | Fuse; (16-Ampere)(European Sourced) | 1 |
| 16***02 | Holder-Fuse | 1 |
| 26***37 | Contactor Group; -Heaters | 1 |
237-0604 Contactor Gp -Battery Charger
| 23***04 | Contactor Group; -Battery Charger | 1 |
| 3K***06 | Screw-Machine-Relay To Bracket | 2 |
| 4B***63 | Washer; (4.7x11x1.2-mm Thk) | 2 |
237-0113 Contactor Gp -Battery Charger
| 15***96 | Support As | 1 |
| 15***98 | Support As | 1 |
| 16***19 | Stud | 4 |
237-0605 Contactor Gp -Battery Charger
| 09***26 | Lockwasher-Tooth; (M4 Id) | 1 |
| 09***66 | Washer; (Hard) (4.5x9x1mm Thk) | 1 |
| 23***05 | Contactor Group; -Battery Charger | 1 |
363-1607 Contactor Gp
| 16***02 | Holder-Fuse | 1 |
| 36***07 | Contactor Group | 1 |
| 3E***92 | Fuse; (30-Ampere)(30 Amp) | 1 |
236-5389 Control & Mtg Gp-Engine Elek
| 15***10 | Fuse; (16-Ampere)(European Sourced) | 1 |
| 16***02 | Holder-Fuse | 1 |
| 23***89 | Control & Mtg Group-Engine Elek | 1 |
243-1560 Control & Mtg Gp-Engine Elek
| 10***02 | Kit-Receptacle; (2-Pin)(Engine Sensor Wiring Harness) | 3 |
| 24***60 | Control & Mtg Group-Engine Elek | 1 |
236-5340 Control & Mtg Gp-Engine Elek -Cam
| 16***02 | Holder-Fuse | 1 |
| 23***40 | Control & Mtg Group-Engine Elek; -Cam | 1 |
| 9U***98 | Fuse; (15-Ampere)(Us Sourced) | 1 |
261-5825 Control Gp-Ether Electronic -Air Shutoff
| 26***25 | Control Group-Ether Electronic; -Air Shutoff | 1 |
9x-9591 Converter Gp-Electrical
| 10***02 | Kit-Receptacle; (2-Pin)(Engine Sensor Wiring Harness) | 3 |
| 9X***91 | Converter Group-Electrical; -Pulse Width Modulated | 1 |
261-8426 Converter Gp-Electrical -Speed Brick
| 13***58 | Cable-Electrical; (16-Ga)(3089-cm) | 0 |
| 15***65 | Kit-Connecting Plug; (8-Pin)(Electronic Control Channel) | 1 |
| 1S***93 | Strap; (Cable) (0.62in Dia) | 16 |
288-8608 Fastener Gp-Wiring Harness
| 10***02 | Kit-Receptacle; (2-Pin)(Engine Sensor Wiring Harness) | 1 |
| 15***60 | Kit-Connecting Plug; (3-Pin)(Engine Sensor Wiring Harness) | 2 |
| 16***89 | Plug As-Connector; (70-Pin)(50x80.9mm) | 1 |
261-7125 Fuse Gp -Block Heater
| 09***61 | Strap; (Cable) | 1 |
| 10***13 | Receptacle As-Connector; (70-Pin) | 1 |
| 12***68 | Socket-Connector; (14-Ga) | 49 |
237-0792 Fuse Gp -Heater, Cylinder Block
| 15***70 | Kit-Connecting Plug; (2-Pin)(Engine Sensor Wiring Harness) | 4 |
| 23***92 | Fuse Group; -Heater, Cylinder Block | 1 |
270-1902 Fuse Gp -Air Shutoff
| 27***02 | Fuse Group; -Air Shutoff | 1 |
261-7123 Fuse Gp -Jacket Water Heater
| 26***23 | Fuse Group; -Jacket Water Heater | 1 |
237-0795 Fuse Gp -Heater, Cylinder Block
| 13***58 | Cable-Electrical; (16-Ga)(3089-cm) | 0 |
| 15***65 | Kit-Connecting Plug; (8-Pin)(Electronic Control Channel) | 0 |
| 1S***93 | Strap; (Cable) (0.62in Dia) | 16 |
239-9416 Harness As -Open
| 1S***93 | Strap; (Cable) (0.62in Dia) | 8 |
| 23***16 | Harness As; -Engine Option | 1 |
240-5123 Harness As -Canopy
| 24***23 | Harness As; -Canopy | 1 |
239-9417 Harness As -Fuel Pump & Valve
| 23***17 | Harness As; -Fuel Pump & Valve | 1 |
261-5614 Harness As-Control
| 26***14 | Harness As-Control; -Discrete Input/Output | 1 |
244-1172 Harness As-Engine
| 10***06 | Receptacle Kit; (Includes Wedge And Receptacle Assem.) | 1 |
| 24***72 | Harness As-Engine | 1 |
| 3E***88 | Receptacle As-Connector; (8-Pin) | 1 |
269-8103 Harness As-Engine
| 26***03 | Harness As-Engine | 1 |
246-4142 Harness As-Lighting -Canopy
| 24***42 | Harness As-Lighting; -Canopy Lighting | 1 |
261-5621 Harness As-Monitor
| 09***61 | Strap; (Cable) | 1 |
| 12***12 | Connector | 1 |
| 18***35 | Pin-Connector; (16-Ga To 18-Ga) | 6 |
270-0096 Harness As-Motor -Winding And Bearing Temperature
| 1S***93 | Strap; (Cable) (0.62in Dia) | 10 |
| 27***96 | Harness As-Motor; -Winding And Bearing Temperature | 1 |
258-4700 Harness As-Panel -Emcp3
| 25***00 | Harness As-Panel; -Panel | 1 |
| 2L***75 | Terminal; (14-Ga To 16-Ga, No. 8 Screw)(Relay Switch "B" & "S") | 2 |
| 5P***92 | Terminal; (18-Ga To 22-Ga, 1/4-In Screw) | 2 |
261-8454 Harness As-Panel -Electrical Converter
| 26***54 | Harness As-Panel; -Electrical Converter | 1 |
| 27***51 | Harness As-Wiring; -Space Heater | 1 |
| 6V***18 | Conduit-Flexible; (18.62-mm Id, Split)(0.3-M Each) | 0 |
260-5309 Harness As-Power -Air Shutoff
| 1S***94 | Boot-Conduit 16mm (.63in) Id | 1 |
| 26***09 | Harness As-Power; -Air Shutoff | 1 |
261-5613 Harness As-Power -Sensing
| 14***13 | Cord As | 1 |
| 26***13 | Harness As-Power; -Sensing | 1 |
| 3B***55 | Bushing To Delivery Ports | 1 |
261-5616 Harness As-Wiring -Resistive Temperature Device
| 25***24 | Bracket As | 1 |
| 26***16 | Harness As-Wiring; -Resistive Temperature Device | 1 |
| 5C***90 | Nut; (M6x1-Thd)(Air Inlet Heater) | 4 |
237-8962 Harness As-Wiring
| 23***62 | Harness As-Wiring | 1 |
239-8198 Harness As-Wiring -Low Fuel Level
| 10***02 | Kit-Receptacle; (2-Pin)(Engine Sensor Wiring Harness) | 1 |
| 10***51 | Screw; (M4x32-mm) | 4 |
| 10***52 | Seal | 1 |
246-1428 Harness As-Wiring -Emergency Stop, Open
| 13***89 | Clip; (Ladder) | 17 |
| 15***75 | Ladder Clip | 4 |
| 17***73 | Lamp Group-Flood; -24-Volt, 65-Watt-Generator Enclosure | 4 |
269-8106 Harness As-Wiring -Battery Charger
| 25***24 | Bracket As | 1 |
| 26***06 | Harness As-Wiring; -Battery Charger | 1 |
| 30***85 | Plate | 2 |
183-2899 Harness As-Wiring -Optional Jacket Water Heater
| 14***13 | Cord As | 1 |
| 18***99 | Harness As-Wiring; -Optional Jacket Water Heater | 1 |
| 9Y***00 | Element As-Jacket Water Heater; (120-Volt, 1500-Watt) | 1 |
261-7139 Harness As-Wiring -Service Connector
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 14 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 14 |
| 26***39 | Harness As-Wiring; -Service Connector | 1 |
289-9728 Harness As-Wiring -Space Heater
| 24***20 | Harness As-Wiring; (Voltage Regulator) | 1 |
| 24***94 | Module As-Sensing; (3-Phase Voltage)(Sensor) | 1 |
| 25***85 | Kit-Installation; -Control Panel | 1 |
246-3101 Harness As-Wiring -Fuel Tank
| 24***01 | Harness As-Wiring; -Fuel Tank | 1 |
| 25***89 | Bracket | 1 |
| 5C***90 | Nut; (M6x1-Thd)(Air Inlet Heater) | 4 |
290-0188 Harness As-Wiring
| 24***20 | Harness As-Wiring; (Voltage Regulator) | 1 |
| 24***94 | Module As-Sensing; (3-Phase Voltage)(Sensor) | 1 |
| 25***87 | Mounting Group-Sensor | 1 |
273-1051 Harness As-Wiring -Space Heater
| 14***99 | Lockwasher | 4 |
| 14***99 | Insulator | 2 |
| 15***92 | Bar | 1 |
142-6924 Heater Gp-Jacket Water
| 00***99 | Connector-Flared | 2 |
| 00***70 | Nipple-Strainer To Flange | 1 |
| 11***36 | Valve As-Shutoff; (Jacket Water Heater) | 2 |
142-6925 Heater Gp-Jacket Water
| 00***99 | Connector-Flared | 2 |
| 00***70 | Nipple-Strainer To Flange | 1 |
| 11***36 | Valve As-Shutoff; (Jacket Water Heater) | 2 |
261-7837 Kit-Insulation
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 6 |
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 2 |
| 24***71 | Bracket As | 1 |
172-9973 Lamp Gp-Flood -24-Volt, 65-Watt
| 17***73 | Lamp Group-Flood; -24-Volt, 65-Watt-Generator Enclosure | 1 |
| 28***27 | Connection Group-Electrical | 1 |
| 8T***38 | Bolt-Plt; (M6 X 1.0 X 20) | 4 |
251-4504 Lighting Gp-Generator
| 25***04 | Lighting Group-Generator | 1 |
| 28***51 | Panel Group-Circuit Breaker | 1 |
| 8T***38 | Bolt-Plt; (M6 X 1.0 X 20) | 4 |
254-7188 Mounting Gp -Charger
| 16***93 | Adapter | 1 |
| 25***88 | Mounting Group; -Charger | 1 |
| 5P***76 | Bolt-12 Point Head; (3/8-16x1.50-In) | 1 |
255-0623 Mounting Gp -Charger
| 09***92 | Washer, Tooth | 4 |
| 13***92 | Screw; (M6x1x16-mm) | 2 |
| 13***22 | Nut | 6 |
261-7632 Mounting Gp -Extension Box
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 8 |
| 25***96 | Terminal & Plate As | 1 |
| 26***88 | Bolt; (M6x1x30-mm) | 8 |
304-8784 Mounting Gp-Battery Charger
| 28***72 | Strip Group-Terminal | 1 |
| 30***84 | Mounting Group-Battery Charger | 1 |
| 8T***38 | Bolt-Plt; (M6 X 1.0 X 20) | 3 |
258-6790 Mounting Gp-Bus Bar -Earth Bar
| 25***90 | Mounting Group-Bus Bar; -Earth Bar | 1 |
| 28***73 | Strip Group-Terminal | 1 |
| 8T***38 | Bolt-Plt; (M6 X 1.0 X 20) | 3 |
247-2705 Mounting Gp-Electronic Control
| 24***05 | Mounting Group-Electronic Control | 1 |
| 28***44 | Terminal Group-Circuit Breaker | 1 |
| 8T***38 | Bolt-Plt; (M6 X 1.0 X 20) | 3 |
247-2701 Mounting Gp-Electronic Control
| 24***01 | Mounting Group-Electronic Control | 1 |
| 28***42 | Terminal Group-Circuit Breaker | 1 |
| 8T***38 | Bolt-Plt; (M6 X 1.0 X 20) | 3 |
302-7356 Mounting Gp-Jacket Wtr Heater
| 16***16 | Insulator | 3 |
| 28***07 | Panel As | 1 |
| 30***56 | Mounting Group-Jacket Wtr Heater | 1 |
246-8984 Mounting Gp-Jacket Wtr Heater
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 4 |
| 24***84 | Mounting Group-Jacket Wtr Heater | 1 |
284-9228 Mounting Gp-Panel
| 14***78 | Relay; (24-Volt)(European Sourced) | 1 |
| 14***79 | Socket-Relay; (European Sourced) | 1 |
| 1S***93 | Strap; (Cable) (0.62in Dia) | 8 |
284-9245 Mounting Gp-Panel
| 1S***93 | Strap; (Cable) (0.62in Dia) | 9 |
| 28***45 | Mounting Group-Panel | 1 |
| 30***49 | Relay; (Ground Fault, 24-Volt, Dc) | 1 |
264-3310 Mounting Gp-Panel
| 21***85 | Grommet; (Blanking) | 4 |
| 26***10 | Mounting Group-Panel | 1 |
255-1087 Mounting Gp-Sensor
| 0S***91 | Screw,Cap,Hexagon Bearing Retainer; Part Of Kit P/N 1w***82 | 1 |
| 13***70 | Spacer Assem. | 1 |
| 1A***73 | Bolt; (5/8-18x1.25-In) | 1 |
188-7501 Mounting Gp-Sensor
| 18***01 | Mounting Group-Sensor; -Atmospheric, Engine Oil | 1 |
| 30***55 | Harness As-Wiring; (Ground Fault) | 1 |
| 31***18 | Harness As-Wiring; (Earth Fault) | 1 |
284-9243 Mounting Gp-Terminal Strip
| 27***18 | Sensor Group-Pressure; (Compressor Outlet) | 1 |
| 28***43 | Mounting Group-Terminal Strip | 1 |
| 6V***48 | Seal--O-Ring--To Governor Drive Housing | 1 |
284-9154 Mounting Gp-Terminal Strip
| 0S***91 | Screw,Cap,Hexagon Bearing Retainer; Part Of Kit P/N 1w***82 | 1 |
| 13***70 | Spacer Assem. | 1 |
| 1A***73 | Bolt; (5/8-18x1.25-In) | 1 |
258-6795 Mounting Gp-Terminal Strip
| 0S***91 | Screw,Cap,Hexagon Bearing Retainer; Part Of Kit P/N 1w***82 | 1 |
| 13***70 | Spacer Assem. | 1 |
| 1A***73 | Bolt; (5/8-18x1.25-In) | 1 |
284-9155 Mounting Gp-Terminal Strip
| 10***03 | Kit; (Receptacle) (3-Pin) (Includes Receptacle As & Wedge) | 1 |
| 18***35 | Pin-Connector; (16-Ga To 18-Ga) | 3 |
| 28***55 | Mounting Group-Terminal Strip | 1 |
284-9241 Mounting Gp-Terminal Strip
| 23***57 | Sensor Group-Liquid Level; -Coolant Loss | 1 |
| 28***41 | Mounting Group-Terminal Strip | 1 |
| 3B***64 | Bushing; (Reducing) | 1 |
262-9635 Mounting Gp-Wiring
| 26***35 | Mounting Group-Wiring; -Tie Wrap | 1 |
| 27***17 | Sensor-Pressure; (Turbocharger Inlet, Rh) | 1 |
| 6V***49 | Seal-O-Ring (Id=11.89mm); (11.89-mm Id) | 1 |
284-9151 Panel Gp-Circuit Breaker
| 27***19 | Sensor Group-Pressure; (Engine Block Oil Inlet) | 1 |
| 28***51 | Panel Group-Circuit Breaker | 1 |
| 6V***48 | Seal--O-Ring--To Governor Drive Housing | 1 |
268-8667 Plug Gp-Box
| 10***02 | Kit-Receptacle; (2-Pin)(Engine Sensor Wiring Harness) | 1 |
| 17***49 | Strap; (Marker) | 1 |
| 18***35 | Pin-Connector; (16-Ga To 18-Ga) | 2 |
261-5828 Relay Gp -General Alarm
| 23***12 | Receptacle As-Connector; (2-Pin) | 1 |
| 26***28 | Relay Group; -General Alarm | 1 |
| 9X***86 | Sleeve; (Bulk) (15 cm) | 0 |
261-5829 Relay Gp-Ground Fault
| 22***47 | Seal-O-Ring | 1 |
| 23***12 | Receptacle As-Connector; (2-Pin) | 1 |
| 26***29 | Relay Group-Ground Fault | 1 |
276-9769 Sensor Gp-Engine
| 22***47 | Seal-O-Ring | 1 |
| 27***69 | Sensor Group-Engine | 1 |
| 27***29 | Sensor Group-Speed; (Cam Gear) | 1 |
263-3751 Sensor Gp-Liquid Level -Coolant
| 10***03 | Kit; (Receptacle) (3-Pin) (Includes Receptacle As & Wedge) | 1 |
| 26***51 | Sensor Group-Liquid Level; -Coolant | 1 |
| 3E***71 | Wedge; (Receptacle Lock) (3 Pin) | 1 |
239-9957 Sensor Gp-Liquid Level
| 22***47 | Seal-O-Ring | 1 |
| 23***57 | Sensor Group-Liquid Level; -Coolant Loss | 1 |
| 27***28 | Sensor Group-Speed | 1 |
276-9067 Sensor Gp-Pressure
| 25***53 | Sensor As-Temperature; (Torque Converter Outlet Oil) | 1 |
| 27***67 | Sensor Group-Pressure; -Engine Oil, Fuel | 1 |
| 8L***86 | Seal-O-Ring (Id=16.36mm); (16.36-mm Id) | 1 |
249-0096 Sensor Gp-Pressure
| 13***52 | Sensor Group-Temperature; -Transmission Oil-Xmsn, Torque Converter | 1 |
| 24***96 | Sensor Group-Pressure; -Intake Air Manifold | 1 |
| 3J***07 | Seal Valve Assembly To; Seal- Tube Assembly To Logic Valve | 1 |
276-8548 Sensor Gp-Pressure
| 25***53 | Sensor As-Temperature; (Torque Converter Outlet Oil) | 1 |
| 27***48 | Sensor Group-Pressure; -Atmospheric | 1 |
| 6V***09 | Seal-O-Ring (Id=16.36mm); (16.36-mm Id) | 1 |
271-7538 Sensor Gp-Speed
| 23***15 | Harness As-Starting Aid | 1 |
| 27***38 | Sensor Group-Speed; -Crankshaft | 1 |
| 9D***21 | Switch-Toggle; (Monitoring System Service) | 1 |
284-3163 Sensor Gp-Speed -Timing, Crankshaft
| 10***02 | Kit-Receptacle; (2-Pin)(Engine Sensor Wiring Harness) | 1 |
| 18***35 | Pin-Connector; (16-Ga To 18-Ga) | 2 |
| 24***02 | Bracket | 1 |
284-3164 Sensor Gp-Speed -Timing, Camshaft
| 10***02 | Kit-Receptacle; (2-Pin)(Engine Sensor Wiring Harness) | 1 |
| 18***35 | Pin-Connector; (16-Ga To 18-Ga) | 2 |
| 19***09 | Box As | 1 |
300-9805 Sensor Gp-Speed
| 03***21 | Shim Lever Housing | 1 |
| 03***23 | Bolt; (1/4-28x1-In) | 13 |
| 04***65 | Screw 19.05 mm(.750 In.) Long | 4 |
300-9804 Sensor Gp-Speed
| 23***62 | Starting Motor Group-Electric | 1 |
| 30***04 | Sensor Group-Speed | 1 |
| 4N***59 | Gasket; (Starting Motor) | 1 |
257-4301 Sensor Gp-Speed
| 03***28 | Seal-O-Ring | 11 |
| 13***11 | Sensor Group-Temperature; (Transmission Lubrication Oil) | 1 |
| 25***01 | Sensor Group-Speed; -Crankshaft | 1 |
4p-7610 Sensor Gp-Speed
| 26***97 | Sensor Group-Temperature; (Air Inlet Manifold) | 1 |
| 4P***10 | Sensor Group-Speed; -Engine Speed | 1 |
| 8L***86 | Seal-O-Ring (Id=16.36mm); (16.36-mm Id) | 2 |
271-7537 Sensor Gp-Speed
| 03***28 | Seal-O-Ring | 11 |
| 26***97 | Sensor Group-Temperature; (Air Inlet Manifold) | 1 |
| 27***37 | Sensor Group-Speed; -Timing, Camshaft | 1 |
234-5012 Sensor Gp-Temperature
| 23***12 | Sensor Group-Temperature; -Coolant, Water | 1 |
| 28***08 | Terminal | 2 |
| 28***09 | Terminal | 2 |
179-1687 Sensor Gp-Temperature -Engine Oil
| 17***87 | Sensor Group-Temperature; -Engine Oil | 1 |
| 28***03 | Terminal; (Copper) | 1 |
| 28***04 | Terminal; (Copper) | 1 |
269-8078 Sensor Gp-Temperature
| 25***76 | Support Group-Battery | 1 |
| 26***78 | Sensor Group-Temperature; -Engine Oil-Jacket Water | 1 |
| 30***51 | Bracket | 1 |
262-9551 Sensor Gp-Temperature -Engine Oil
| 14***56 | Support Group-Battery | 1 |
| 14***57 | Angle | 1 |
| 24***66 | Cable As-Battery; (Negative)(Starter Motor Terminal) (Black) | 1 |
234-5013 Sensor Gp-Temperature
| 09***21 | Rail-Mounting; (60-cm) | 1 |
| 20***65 | Fuse; (4-Ampere) | 3 |
| 22***47 | Block-Terminal; (800-Volt, 31-Ampere) | 15 |
134-2252 Sensor Gp-Temperature -Transmission Oil
| 13***52 | Sensor Group-Temperature; -Transmission Oil-Xmsn, Torque Converter | 1 |
| 14***56 | Insulator | 2 |
| 28***56 | Terminal | 1 |
236-7859 Starting Aid Gp -Ether Start
| 23***59 | Starting Aid Group; -Ether Start | 1 |
| 7H***13 | Mat | 12 |
| 7K***81 | Strap-Pressure & Return Hoses To | 24 |
244-3701 Starting Aid Gp-Ether
| 11***84 | Switch As-Toggle; (Momentary)(Manual Engine Speed Control) | 1 |
| 24***01 | Starting Aid Group-Ether | 1 |
| 3L***87 | Lockwasher 7.24mm(.285in.)O.D.; (3.7x7.24x.48mm Thk) | 3 |
244-3700 Starting Aid Gp-Ether
| 1S***93 | Strap; (Cable) (0.62in Dia) | 6 |
| 24***00 | Starting Aid Group-Ether | 1 |
| 26***12 | Harness As-Starting Aid | 1 |
338-3454 Starting Motor Gp-Electric
| 33***54 | Starting Motor Group-Electric | 1 |
237-1962 Starting Motor Gp-Electric
| 23***62 | Starting Motor Group-Electric | 1 |
120-9100 Starting Motor Gp-Electric
| 12***00 | Starting Motor Group-Electric | 1 |
284-9173 Strip Gp-Terminal
| 28***73 | Strip Group-Terminal | 1 |
295-4048 Strip Gp-Terminal
| 29***48 | Strip Group-Terminal | 1 |
| 3L***87 | Lockwasher 7.24mm(.285in.)O.D.; (3.7x7.24x.48mm Thk) | 3 |
| 6T***31 | Nut-Hexagon-(15/32-32 Thd) | 2 |
284-9157 Strip Gp-Terminal
| 28***57 | Strip Group-Terminal | 1 |
284-9172 Strip Gp-Terminal
| 28***72 | Strip Group-Terminal | 1 |
315-1359 Support Gp-Battery
| 10***02 | Kit-Receptacle; (2-Pin)(Engine Sensor Wiring Harness) | 1 |
| 31***59 | Support Group-Battery | 1 |
| 9X***01 | Pin-Connector; (16-Ga To 18-Ga)(Throttle Position Sensor) | 2 |
302-7361 Support Gp-Battery
| 14***52 | Film-Information; (Battery Power Disconnect) | 1 |
| 16***45 | Bracket | 1 |
| 24***75 | Cable As | 1 |
251-1476 Support Gp-Battery
| 25***76 | Support Group-Battery | 1 |
| 2H***22 | Lockwasher | 2 |
| 6F***45 | Nut-Full; (3/8-24-Thd) | 2 |
272-2205 Support Gp-Cable
| 17***29 | Switch Group-Magnetic | 1 |
| 17***30 | Switch Group-Magnetic; (Inlet Air Heater Power Relay) | 1 |
| 27***05 | Support Group-Cable | 1 |
261-8430 Switch As -Volt Adjust Avr
| 01***80 | Lockwasher | 2 |
| 10***02 | Kit-Receptacle; (2-Pin)(Engine Sensor Wiring Harness) | 1 |
| 18***35 | Pin-Connector; (16-Ga To 18-Ga) | 2 |
261-5824 Switch As -Ether Start
| 01***80 | Lockwasher | 2 |
| 10***02 | Kit-Receptacle; (2-Pin)(Engine Sensor Wiring Harness) | 1 |
| 18***35 | Pin-Connector; (16-Ga To 18-Ga) | 2 |
7n-0718 Switch Gp-Disconnect -Battery
| 24***58 | Terminal | 1 |
| 24***34 | Terminal As | 2 |
| 7N***18 | Switch As-Disconnect; -Battery-Ground Level | 1 |
256-7147 Switch As-Liquid Level
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 3 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 3 |
| 14***89 | Block-Terminal | 2 |
256-7153 Switch As-Liquid Level
| 14***89 | Block-Terminal | 2 |
| 19***37 | Screw; (8-32x1/2-In) | 9 |
| 19***26 | Insert-Threaded; (M4x0.7-Thd)(M4x0.7 Thd) | 2 |
240-3149 Switch As-Liquid Level
| 10***06 | Receptacle Kit; (Includes Wedge And Receptacle Assem.) | 1 |
| 14***79 | Gasket | 1 |
| 15***65 | Kit-Connecting Plug; (8-Pin)(Electronic Control Channel) | 1 |
256-7156 Switch As-Liquid Level
| 24***68 | Terminal | 8 |
| 25***56 | Switch As-Liquid Level; -Fuel | 1 |
256-7154 Switch As-Liquid Level
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 3 |
| 14***89 | Block-Terminal | 2 |
| 14***60 | Rail; (200-cm) | 0 |
256-7159 Switch As-Liquid Level
| 24***58 | Terminal | 4 |
| 25***59 | Switch As-Liquid Level; -Fuel | 1 |
8n-0694 Switch As-Toggle
| 24***67 | Terminal | 2 |
| 24***60 | Terminal As | 1 |
| 28***15 | Terminal As | 1 |
251-1477 Switch Gp-Disconnect
| 24***58 | Terminal | 3 |
| 25***77 | Switch Group-Disconnect; -Battery | 1 |
172-8660 Switch Gp-Liquid Level
| 17***60 | Switch Group-Liquid Level; -Rear Engine Oil-Ster, Hydraulic Fan Oil-Engine On-Steering Oil, Engine Off-Auxiliary Coolant-Front Engine Oil-Brake Oil, Hoist-Engine Coolant-Tc Oil-Low, Cold | 1 |
| 24***68 | Terminal | 6 |
148-0757 Switch Gp-Magnetic -Starting Motor
| 14***57 | Switch Group-Magnetic; (Inlet Air Heater Power Relay) | 1 |
| 26***06 | Terminal | 3 |
| 26***07 | Terminal | 3 |
175-2330 Switch Gp-Magnetic
| 17***30 | Switch Group-Magnetic; (Inlet Air Heater Power Relay) | 1 |
| 28***03 | Terminal; (Copper) | 1 |
| 28***04 | Terminal; (Copper) | 1 |
175-2329 Switch Gp-Magnetic
| 17***29 | Switch Group-Magnetic | 1 |
| 28***08 | Terminal | 2 |
| 28***09 | Terminal | 2 |
235-4900 Switch Gp-Push Button
| 23***00 | Switch Group-Push Button; -Canopy, Emergency Stop | 1 |
| 28***13 | Terminal | 3 |
258-6796 Terminal & Plate As
| 24***67 | Terminal | 2 |
| 24***60 | Terminal As | 1 |
| 25***96 | Terminal & Plate As | 1 |
284-9190 Terminal Gp-Circuit Breaker
| 21***85 | Transformer-Current; (Ratio 1000:5) | 3 |
| 28***90 | Terminal Group-Circuit Breaker | 1 |
| 7K***81 | Strap-Pressure & Return Hoses To | 9 |
284-9186 Terminal Gp-Circuit Breaker
| 28***86 | Terminal Group-Circuit Breaker | 1 |
284-9199 Terminal Gp-Circuit Breaker
| 21***92 | Transformer; (Ratio 2000:5) | 3 |
| 28***99 | Terminal Group-Circuit Breaker | 1 |
| 7K***81 | Strap-Pressure & Return Hoses To | 9 |
284-9195 Terminal Gp-Circuit Breaker
| 21***88 | Transformer-Current; (Ratio 1500:5) | 3 |
| 28***95 | Terminal Group-Circuit Breaker | 1 |
| 7K***81 | Strap-Pressure & Return Hoses To | 9 |
361-7979 Terminal Gp-Circuit Breaker
| 24***14 | Harness As-Wiring; (Current Transformer, Droop) | 1 |
| 24***00 | Transformer-Current; (Ratio 700:1) | 1 |
| 36***79 | Terminal Group-Circuit Breaker | 1 |
289-2817 Terminal Gp-Circuit Breaker
| 24***14 | Harness As-Wiring; (Current Transformer, Droop) | 1 |
| 24***99 | Transformer-Current; (Ratio 600:1) | 1 |
| 28***17 | Terminal Group-Circuit Breaker | 1 |
284-9225 Terminal Gp-Circuit Breaker
| 15***87 | Transformer As-Current | 1 |
| 28***25 | Terminal Group-Circuit Breaker | 1 |
| 7K***81 | Strap-Pressure & Return Hoses To | 3 |
289-2814 Terminal Gp-Circuit Breaker
| 24***14 | Harness As-Wiring; (Current Transformer, Droop) | 1 |
| 24***96 | Transformer-Current; (Ratio 500:1) | 1 |
| 28***14 | Terminal Group-Circuit Breaker | 1 |
284-9189 Terminal Gp-Circuit Breaker
| 21***83 | Transformer-Current; (Ratio 800:5) | 3 |
| 28***89 | Terminal Group-Circuit Breaker | 1 |
| 7K***81 | Strap-Pressure & Return Hoses To | 9 |
284-9242 Terminal Gp-Circuit Breaker
| 28***42 | Terminal Group-Circuit Breaker | 1 |
| 31***05 | Transformer As; (Earth Fault) | 1 |
| 7K***81 | Strap-Pressure & Return Hoses To | 3 |
284-9188 Terminal Gp-Circuit Breaker
| 12***85 | Transformer As-Current | 4 |
| 28***88 | Terminal Group-Circuit Breaker | 1 |
284-9244 Terminal Gp-Circuit Breaker
| 24***84 | Transformer-Current | 1 |
| 24***14 | Harness As-Wiring; (Current Transformer, Droop) | 1 |
| 28***44 | Terminal Group-Circuit Breaker | 1 |
151-7746 Transformer
| 15***46 | Transformer | 1 |
| 24***14 | Harness As-Wiring; (Current Transformer, Droop) | 1 |
| 24***02 | Transformer-Current; (Ratio 1000:1) | 1 |
151-7745 Transformer -Potential
| 15***45 | Transformer; -Potential | 1 |
| 24***14 | Harness As-Wiring; (Current Transformer, Droop) | 1 |
| 24***01 | Transformer-Current; (Ratio 800:1) | 1 |
151-7747 Transformer
| 15***47 | Transformer | 1 |
| 24***14 | Harness As-Wiring; (Current Transformer, Droop) | 1 |
| 24***03 | Transformer-Current; (Ratio 1200:1) | 1 |
312-0168 Transformer As-Current
| 24***14 | Harness As-Wiring; (Current Transformer, Droop) | 1 |
| 24***04 | Transformer-Current; (Ratio 1600:1) | 1 |
| 31***68 | Transformer As-Current | 1 |
301-1644 Transformer Gp
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 14***78 | Relay; (24-Volt)(European Sourced) | 1 |
| 14***79 | Socket-Relay; (European Sourced) | 1 |
251-1461 Transformer Gp-Current
| 13***49 | Control Group-Alarm Module | 1 |
| 23***23 | Harness As-Panel; (Alarm Module) | 1 |
| 25***61 | Transformer Group-Current | 1 |
239-0432 Transformer Gp-Current
| 13***59 | Transformer As-Current | 4 |
| 23***32 | Transformer Group-Current | 1 |
246-6497 Transformer Gp-Current
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 11***75 | Control Group-Emcp Electronic | 1 |
| 23***71 | Harness As-Panel; (Kilowatt Relay)(Emcp Ii+ Electronic Control) | 1 |
239-0410 Transformer Gp-Current
| 21***94 | Transformer; (Ratio 2500:5) | 3 |
| 23***10 | Transformer Group-Current | 1 |
| 7K***81 | Strap-Pressure & Return Hoses To | 9 |
246-6496 Transformer Gp-Current
| 11***45 | Plug As-Connector; (40-Pin) | 1 |
| 13***58 | Cable-Electrical; (16-Ga)(3089-cm) | 0 |
| 23***06 | Harness As-Panel; (Emcp2e Door) | 1 |
246-6495 Transformer Gp-Current
| 11***44 | Seal | 1 |
| 11***45 | Plug As-Connector; (40-Pin) | 1 |
| 23***06 | Harness As-Panel; (Emcp2e Door) | 1 |
239-0433 Transformer Gp-Current
| 23***33 | Transformer Group-Current | 1 |
| 24***14 | Harness As-Wiring; (Current Transformer, Droop) | 1 |
| 31***53 | Transformer | 1 |
239-7137 Transformer Gp-Current
| 0L***51 | Bolt Starting Engine Fuel Tank Bracket To Diesel Intake Manifold | 1 |
| 0S***09 | Bolt (3/4") Filler Tube Assembly To Transfer Drive Case | 2 |
| 0S***76 | Bolt 5.08 cm(2 In.) Long | 2 |
314-3054 Transformer Gp-Current
| 20***54 | Relay; (Generator Temperature) | 4 |
| 23***88 | Harness As-Panel; (Generator Temperature)(Winding/Bearing Temp) | 1 |
| 31***54 | Transformer Group-Current | 1 |
246-6494 Transformer Gp-Current
| 12***95 | Screw-Pan Head; (M2.5x0.45x12-mm) | 4 |
| 16***12 | Washer-Hard; (2.7x6x0.5-mm Thk) | 8 |
| 16***16 | Nut; (M2.5x0.45-Thd) | 4 |
239-0431 Transformer Gp-Current
| 23***31 | Transformer Group-Current | 1 |
| 24***14 | Harness As-Wiring; (Current Transformer, Droop) | 1 |
| 25***52 | Transformer; (Current) | 1 |
246-6490 Transformer Gp-Current
| 23***47 | Cable As | 1 |
| 24***90 | Transformer Group-Current | 1 |
| 8T***21 | Washer-Hard; (11x21x2.5-mm Thk)(M10x1.50x30mm) | 2 |
251-4165 Transformer Gp-Current
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 2 |
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 1 |
| 14***78 | Relay; (24-Volt)(European Sourced) | 1 |
246-6493 Transformer Gp-Current
| 10***71 | Module Group-Synchronizing Lights | 1 |
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 2 |
| 16***02 | Holder-Fuse | 2 |
246-6491 Transformer Gp-Current
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 2 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 2 |
| 12***95 | Screw-Pan Head; (M2.5x0.45x12-mm) | 4 |
246-6492 Transformer Gp-Current
| 24***92 | Transformer Group-Current | 1 |
| 30***63 | Circuit Breaker; (4-Ampere) | 1 |
| 30***05 | Harness As-Panel | 1 |
240-5095 Wiring Gp-Air Shutoff
| 14***78 | Relay; (24-Volt)(European Sourced) | 0 |
| 14***79 | Socket-Relay; (European Sourced) | 1 |
| 21***40 | Spring; (Relay)(Us Sourced) | 1 |
276-4753 Wiring Gp-Electronic Control
| 14***78 | Relay; (24-Volt)(European Sourced) | 1 |
| 14***79 | Socket-Relay; (European Sourced) | 1 |
| 21***40 | Spring; (Relay)(Us Sourced) | 1 |
261-8479 Wiring Gp-Generator
| 26***79 | Wiring Group-Generator | 1 |
| 30***49 | Relay; (Ground Fault, 24-Volt, Dc) | 1 |
| 30***56 | Harness As-Panel; (Earth Fault) | 1 |
240-1621 Wiring Gp-Generator
| 23***70 | Harness As-Panel; (Earth Fault) | 1 |
| 24***21 | Wiring Group-Generator | 1 |
| 24***66 | Relay; (24-Vdc)(18-30-Volt Dc) | 1 |
302-4606 Wiring Gp-Heater
| 23***70 | Harness As-Panel; (Earth Fault) | 1 |
| 30***06 | Wiring Group-Heater | 1 |
| 31***18 | Harness As-Wiring; (Earth Fault) | 1 |
237-1465 Wiring Gp-Panel -Earth Fault
| 1D***12 | Bolt 4 In. (102.0 mm) Long Rear Bracket Assembly To Frame | 2 |
| 1F***58 | Nut-Full; (1/2-13-Thd)(Air Lines) | 6 |
| 23***27 | Washer-Bevel | 6 |
261-5826 Wiring Gp-Panel -Fuel Transfer
| 24***72 | Plate-Cover | 2 |
| 26***26 | Wiring Group-Panel; -Fuel Transfer | 1 |
| 5C***61 | Nut (M8x1.25 Thd); (M8x1.25 Thd) | 12 |
236-7893 Wiring Gp-Panel
| 23***93 | Wiring Group-Panel; -Fuel Systems | 1 |
| 24***86 | Base As | 1 |
| 7X***53 | Bolt-Plt; (M16 X 2.0 X 40) | 6 |
235-8390 Wiring Gp-Panel
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 2 |
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 1 |
| 14***78 | Relay; (24-Volt)(European Sourced) | 1 |
237-0822 Wiring Gp-Panel -Generator Temperature
| 23***69 | Base As; -Engine And Generator | 1 |
| 23***22 | Wiring Group-Panel; -Generator Wind/Bearing Temperature | 1 |
| 23***80 | Union; (3/4-14 Bspp Thd) | 2 |
237-1460 Wiring Gp-Panel -Generator Run
| 23***60 | Wiring Group-Panel; -Generator Run | 1 |
| 24***80 | Pipe-Fuel; (Filler) | 1 |
| 24***82 | Valve; (Fuel Tank)(Pressure Release) | 1 |
236-7894 Wiring Gp-Panel
| 23***94 | Wiring Group-Panel; -Fuel Systems | 1 |
| 24***14 | Base As | 1 |
| 7X***53 | Bolt-Plt; (M16 X 2.0 X 40) | 12 |
235-9063 Wiring Gp-Panel
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 2 |
| 14***78 | Relay; (24-Volt)(European Sourced) | 1 |
| 14***79 | Socket-Relay; (European Sourced) | 1 |
236-5314 Wiring Gp-Panel -Ac Transformer Box +
| 23***14 | Wiring Group-Panel; -Ac Transformer Box + | 1 |
| 23***01 | Union; (3/4-14 Npsf Thd) | 2 |
| 26***95 | Base As-Engine & Generator | 1 |
236-5309 Wiring Gp-Panel
| 23***09 | Wiring Group-Panel; -Emcp Ii+ | 1 |
237-1457 Wiring Gp-Panel -Alarm Relay
| 23***57 | Wiring Group-Panel; -Alarm Relay | 1 |
| 24***80 | Pipe-Fuel; (Filler) | 1 |
| 24***82 | Valve; (Fuel Tank)(Pressure Release) | 2 |
261-8431 Wiring Gp-Panel -Fuel Transfer
| 24***64 | Plate | 1 |
| 24***65 | Plate | 2 |
| 24***42 | Plate-Cover | 1 |
236-5328 Wiring Gp-Panel
| 23***28 | Wiring Group-Panel; -Prealarm | 1 |
| 24***85 | Base As | 1 |
| 7X***53 | Bolt-Plt; (M16 X 2.0 X 40) | 10 |
257-4183 Wiring Gp-Unit Injector
| 23***77 | Plate | 1 |
| 23***78 | Plate | 1 |
| 23***79 | Plate | 1 |
Enclosures, Guards And Bases
230-9369 Base As -Engine And Generator
| 23***69 | Base As; -Engine And Generator | 1 |
| 23***79 | Plate | 1 |
| 24***65 | Plate | 2 |
268-9996 Base As-Engine & Generator
| 15***52 | Boot | 1 |
| 15***11 | Strip | 1 |
| 26***96 | Base As-Engine & Generator | 1 |
251-1420 Base Gp -Engine And Generator
| 03***84 | Plug 12.7 mm(.50 In.) Dia. | 4 |
| 25***20 | Base Group; -Engine And Generator | 1 |
| 5N***67 | Seal; 1.52mm(.059in)Thk | 3 |
256-0406 Base Gp -Engine And Generator
| 14***94 | Rivet | 10 |
| 14***12 | Bracket | 2 |
| 14***83 | Ring-Retaining | 12 |
248-0188 Base Gp-Engine & Generator
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 6 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 6 |
| 24***88 | Base Group-Engine & Generator | 1 |
283-0948 Base Gp-Engine & Generator
| 14***94 | Rivet | 10 |
| 14***12 | Bracket | 2 |
| 14***83 | Ring-Retaining | 12 |
302-5735 Base Gp-Engine & Generator
| 03***32 | Strap--Harness Assembly To Compressor | 3 |
| 15***98 | Screw-Machine; (6-20x0.37-In) | 32 |
| 23***11 | Duct; (120-cm) | 0 |
248-0187 Base Gp-Engine & Generator
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 6 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 6 |
| 24***87 | Base Group-Engine & Generator | 1 |
296-2961 Base Gp-Engine & Generator
| 03***32 | Strap--Harness Assembly To Compressor | 3 |
| 15***98 | Screw-Machine; (6-20x0.37-In) | 32 |
| 23***11 | Duct; (120-cm) | 0 |
249-4713 Base Gp-Engine & Generator
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 10 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 10 |
| 24***13 | Base Group-Engine & Generator | 1 |
250-3138 Base Gp-Engine & Generator
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 6 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 6 |
| 25***38 | Base Group-Engine & Generator | 1 |
249-2697 Cover Gp-Base
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 4 |
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 18 |
| 24***97 | Cover Group-Base | 1 |
245-1222 Cover Gp-Base
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 4 |
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 18 |
| 24***22 | Cover Group-Base | 1 |
244-5773 Cover Gp-Base
| 11***29 | Tie-Cable | 3 |
| 15***98 | Screw-Machine; (6-20x0.37-In) | 32 |
| 23***11 | Duct; (120-cm) | 0 |
260-8418 Cover Gp-Base -Enclosure
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 4 |
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 18 |
| 26***18 | Cover Group-Base; -Enclosure | 1 |
261-0003 Cover Gp-Enclosure -Top
| 23***33 | Enclosure Group-Generator | 1 |
| 23***92 | Enclosure Group-Generator; -Outlet Box | 1 |
| 23***96 | Enclosure Group-Generator | 1 |
269-8466 Cover Gp-Enclosure
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 52 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
258-6812 Cover Gp-Enclosure -Frame
| 23***00 | Panel As | 1 |
| 23***02 | Panel As | 1 |
| 23***03 | Panel As | 1 |
260-5144 Cover Gp-Enclosure
| 22***51 | Bracket | 2 |
| 23***51 | Plate As | 1 |
| 23***91 | Panel As | 1 |
238-0881 Cover Gp-Enclosure
| 14***99 | Lockwasher | 4 |
| 14***01 | Screw; (M10x1.5x20-mm) | 4 |
| 14***94 | Rivet | 19 |
4p-1802 Cover Gp-Generator
| 23***33 | Enclosure Group-Generator | 1 |
| 23***92 | Enclosure Group-Generator; -Outlet Box | 1 |
| 23***96 | Enclosure Group-Generator | 1 |
227-5632 Door As
| 22***32 | Door As; -Generator Enclosure | 1 |
| 23***33 | Enclosure Group-Generator | 1 |
| 23***92 | Enclosure Group-Generator; -Outlet Box | 1 |
227-5634 Door As
| 22***34 | Door As; -Enclosure-Generator Enclosure | 1 |
| 23***33 | Enclosure Group-Generator | 1 |
| 23***92 | Enclosure Group-Generator; -Outlet Box | 1 |
239-5348 Duct Gp-Cable
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 52 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
239-3812 Duct Gp-Cable
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 52 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
239-5347 Duct Gp-Cable
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 52 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
258-6802 Enclosure As -Control Panel
| 14***94 | Rivet | 4 |
| 14***40 | Key | 2 |
| 23***82 | Exhaust Group | 1 |
258-6763 Enclosure As -Control Panel
| 14***94 | Rivet | 4 |
| 14***40 | Key | 2 |
| 23***82 | Exhaust Group | 1 |
258-6769 Enclosure As -Control Panel
| 14***94 | Rivet | 4 |
| 14***40 | Key | 2 |
| 23***82 | Exhaust Group | 1 |
253-9356 Enclosure Gp-Generator
| 14***94 | Rivet | 4 |
| 14***40 | Key | 1 |
| 23***00 | Switch Group-Push Button; -Canopy, Emergency Stop | 1 |
248-3062 Enclosure Gp-Generator
| 23***92 | Enclosure Group-Generator; -Outlet Box | 1 |
| 23***96 | Enclosure Group-Generator | 1 |
| 24***62 | Enclosure Group-Generator | 1 |
253-9357 Enclosure Gp-Generator
| 14***94 | Rivet | 4 |
| 14***40 | Key | 1 |
| 23***00 | Switch Group-Push Button; -Canopy, Emergency Stop | 1 |
255-4170 Enclosure Gp-Generator
| 23***98 | Insulation As | 1 |
| 23***97 | Insulation As | 1 |
| 23***03 | Insulation As | 1 |
248-3051 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 46 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
248-3071 Enclosure Gp-Generator
| 14***94 | Rivet | 4 |
| 14***40 | Key | 2 |
| 23***82 | Exhaust Group | 1 |
248-3052 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 46 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
255-4165 Enclosure Gp-Generator
| 14***94 | Rivet | 24 |
| 25***65 | Enclosure Group-Generator | 1 |
| 28***39 | Base As | 1 |
248-3064 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 57 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
253-9361 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 50 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
248-3069 Enclosure Gp-Generator
| 14***94 | Rivet | 4 |
| 14***40 | Key | 2 |
| 23***82 | Exhaust Group | 1 |
248-3053 Enclosure Gp-Generator
| 14***94 | Rivet | 4 |
| 14***40 | Key | 1 |
| 23***00 | Switch Group-Push Button; -Canopy, Emergency Stop | 1 |
248-3059 Enclosure Gp-Generator
| 23***92 | Enclosure Group-Generator; -Outlet Box | 1 |
| 23***96 | Enclosure Group-Generator | 1 |
| 24***59 | Enclosure Group-Generator | 1 |
248-3049 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 46 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
253-9359 Enclosure Gp-Generator
| 12***78 | Locknut; (M6x1-Thd) | 50 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
| 14***99 | Lockwasher | 48 |
255-4173 Enclosure Gp-Generator
| 23***14 | Cable As-Braided | 4 |
| 25***73 | Enclosure Group-Generator | 1 |
| 26***66 | Plate | 2 |
253-9367 Enclosure Gp-Generator
| 23***77 | Base As | 1 |
| 25***67 | Enclosure Group-Generator | 1 |
| 8T***23 | Washer-Plated; (22x35x3.5-mm Thk) | 12 |
248-3067 Enclosure Gp-Generator -Complete, Weather Protection, Yellow
| 14***94 | Rivet | 4 |
| 14***40 | Key | 2 |
| 23***82 | Exhaust Group | 1 |
253-9366 Enclosure Gp-Generator
| 14***94 | Rivet | 12 |
| 14***12 | Bracket | 6 |
| 22***40 | Door As | 1 |
255-4162 Enclosure Gp-Generator
| 14***94 | Rivet | 24 |
| 23***96 | Base As | 1 |
| 25***62 | Enclosure Group-Generator | 1 |
248-3065 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 57 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
255-4169 Enclosure Gp-Generator
| 23***98 | Insulation As | 1 |
| 23***04 | Insulation As | 1 |
| 23***16 | Insulation As | 1 |
253-9363 Enclosure Gp-Generator
| 14***94 | Rivet | 12 |
| 14***12 | Bracket | 6 |
| 22***40 | Door As | 1 |
233-6996 Enclosure Gp-Generator
| 14***94 | Rivet | 64 |
| 14***12 | Bracket | 16 |
| 22***40 | Door As | 1 |
255-4166 Enclosure Gp-Generator
| 14***94 | Rivet | 24 |
| 25***66 | Enclosure Group-Generator | 1 |
| 28***59 | Base As | 1 |
248-3056 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 1 |
| 14***99 | Lockwasher | 4 |
| 14***01 | Screw; (M10x1.5x20-mm) | 4 |
248-3050 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 46 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
248-3054 Enclosure Gp-Generator
| 14***94 | Rivet | 4 |
| 14***40 | Key | 1 |
| 23***00 | Switch Group-Push Button; -Canopy, Emergency Stop | 1 |
345-0747 Enclosure Gp-Generator
| 23***16 | Cable As-Braided | 4 |
| 26***66 | Plate | 2 |
| 34***47 | Enclosure Group-Generator | 1 |
345-0746 Enclosure Gp-Generator
| 23***15 | Cable As-Braided | 4 |
| 26***66 | Plate | 2 |
| 34***46 | Enclosure Group-Generator | 1 |
248-3061 Enclosure Gp-Generator
| 23***92 | Enclosure Group-Generator; -Outlet Box | 1 |
| 23***96 | Enclosure Group-Generator | 1 |
| 24***61 | Enclosure Group-Generator | 1 |
248-3063 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 57 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
248-3066 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 57 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
253-9358 Enclosure Gp-Generator
| 14***94 | Rivet | 4 |
| 14***40 | Key | 1 |
| 23***00 | Switch Group-Push Button; -Canopy, Emergency Stop | 1 |
233-2133 Enclosure Gp-Generator
| 14***94 | Rivet | 13 |
| 14***12 | Bracket | 4 |
| 22***40 | Door As | 1 |
253-9355 Enclosure Gp-Generator
| 14***94 | Rivet | 4 |
| 14***40 | Key | 1 |
| 23***00 | Switch Group-Push Button; -Canopy, Emergency Stop | 1 |
255-4167 Enclosure Gp-Generator
| 25***67 | Enclosure Group-Generator | 1 |
| 7F***98 | Lockwasher | 6 |
| 8T***21 | Washer-Hard; (11x21x2.5-mm Thk)(M10x1.50x30mm) | 12 |
253-9360 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 50 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
233-6992 Enclosure Gp-Generator -Outlet Box
| 14***94 | Rivet | 64 |
| 14***12 | Bracket | 16 |
| 22***40 | Door As | 1 |
255-4163 Enclosure Gp-Generator
| 14***94 | Rivet | 24 |
| 23***94 | Base As | 1 |
| 25***63 | Enclosure Group-Generator | 1 |
248-3055 Enclosure Gp-Generator
| 14***94 | Rivet | 4 |
| 14***40 | Key | 1 |
| 23***00 | Switch Group-Push Button; -Canopy, Emergency Stop | 1 |
255-4171 Enclosure Gp-Generator
| 23***94 | Plate | 1 |
| 25***71 | Enclosure Group-Generator | 1 |
| 6V***97 | Bolt; (M12x1.75x40-mm)(Locking) | 4 |
248-3060 Enclosure Gp-Generator
| 23***92 | Enclosure Group-Generator; -Outlet Box | 1 |
| 23***96 | Enclosure Group-Generator | 1 |
| 24***60 | Enclosure Group-Generator | 1 |
255-4164 Enclosure Gp-Generator
| 14***94 | Rivet | 24 |
| 25***64 | Enclosure Group-Generator | 1 |
| 28***74 | Base As | 1 |
253-9362 Enclosure Gp-Generator
| 11***81 | Adhesive; (All Joints To Be Sealed) | 0 |
| 12***78 | Locknut; (M6x1-Thd) | 50 |
| 13***40 | Locknut; (M8x1.25-Thd) | 5 |
238-3272 Enclosure Gp-Generator
| 14***94 | Rivet | 64 |
| 14***12 | Bracket | 16 |
| 22***40 | Door As | 1 |
255-4172 Enclosure Gp-Generator
| 23***15 | Cable As-Braided | 4 |
| 25***72 | Enclosure Group-Generator | 1 |
| 26***66 | Plate | 2 |
248-3070 Enclosure Gp-Generator
| 14***94 | Rivet | 4 |
| 14***40 | Key | 2 |
| 23***82 | Exhaust Group | 1 |
253-9364 Enclosure Gp-Generator
| 14***94 | Rivet | 12 |
| 14***12 | Bracket | 6 |
| 22***40 | Door As | 1 |
253-9365 Enclosure Gp-Generator
| 14***94 | Rivet | 12 |
| 14***12 | Bracket | 6 |
| 22***40 | Door As | 1 |
255-4168 Enclosure Gp-Generator
| 17***19 | Mount As | 2 |
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 5 |
| 23***57 | Bracket | 1 |
344-9000 Enclosure Gp-Genset
| 23***18 | Cable As-Braided | 4 |
| 26***66 | Plate | 2 |
| 34***00 | Enclosure Group-Genset | 1 |
344-8996 Enclosure Gp-Genset
| 23***17 | Cable As-Braided | 4 |
| 26***66 | Plate | 2 |
| 34***96 | Enclosure Group-Genset | 1 |
282-6166 Extension Gp-Base
| 23***23 | Cable As-Braided | 4 |
| 27***74 | Plate | 2 |
| 28***66 | Extension Group-Base | 1 |
282-6167 Extension Gp-Base
| 23***24 | Cable As-Braided | 4 |
| 27***74 | Plate | 2 |
| 28***67 | Extension Group-Base | 1 |
282-6165 Extension Gp-Base
| 23***22 | Cable As-Braided | 4 |
| 27***74 | Plate | 2 |
| 28***65 | Extension Group-Base | 1 |
237-7219 Extension Gp-Base
| 23***19 | Extension Group-Base | 1 |
| 23***20 | Cable As-Braided | 4 |
| 27***74 | Plate | 2 |
235-7035 Extension Gp-Base
| 23***35 | Extension Group-Base | 1 |
| 23***19 | Cable As-Braided | 4 |
| 26***66 | Plate | 2 |
237-7221 Extension Gp-Base
| 23***21 | Extension Group-Base | 1 |
| 23***21 | Cable As-Braided | 4 |
| 27***74 | Plate | 2 |
240-1411 Fastener Gp-Enclosure
| 23***25 | Cable As-Braided | 8 |
| 24***11 | Fastener Group-Enclosure | 1 |
| 27***74 | Plate | 2 |
254-1490 Guard Gp-Engine
| 23***26 | Cable As-Braided | 8 |
| 25***90 | Guard Group-Engine | 1 |
| 27***74 | Plate | 2 |
291-3891 Insulation Gp-Generator
| 29***91 | Insulation Group-Generator | 1 |
| 4D***43 | Lockwasher | 16 |
| 8T***21 | Washer-Hard; (11x21x2.5-mm Thk)(M10x1.50x30mm) | 26 |
291-3889 Insulation Gp-Generator
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 10 |
| 24***07 | Bolt; (M6x1x40-mm)(Hex Head) | 10 |
| 29***89 | Insulation Group-Generator | 1 |
344-9075 Insulation Gp-Sound Suppr
| 34***75 | Insulation Group-Sound Suppr | 1 |
| 8T***21 | Washer-Hard; (11x21x2.5-mm Thk)(M10x1.50x30mm) | 32 |
| 8T***33 | Nut (M10x1.50 Thd) | 16 |
213-1508 Mounting Gp-Beam
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 8 |
| 21***08 | Mounting Group-Beam | 1 |
| 24***07 | Bolt; (M6x1x40-mm)(Hex Head) | 8 |
Engine Arrangement
272-6915 Engine Ar-Complete
| 11***88 | Lifting Group-Engine; (Rear) | 1 |
| 12***00 | Starting Motor Group-Electric | 1 |
| 12***64 | Lifting Group-Engine; -Remote | 1 |
296-5206 Engine Ar-Complete
| 11***88 | Lifting Group-Engine; (Rear) | 1 |
| 12***00 | Starting Motor Group-Electric | 1 |
| 12***64 | Lifting Group-Engine; -Remote | 1 |
272-6916 Engine Ar-Core
| 10***57 | Fastener Group-Valve Mechanism | 1 |
| 16***13 | Pump Group-Engine Oil | 1 |
| 18***17 | Crankshaft Group | 1 |
312-5965 Engine Ar-Core
| 10***57 | Fastener Group-Valve Mechanism | 1 |
| 16***13 | Pump Group-Engine Oil | 1 |
| 18***17 | Crankshaft Group | 1 |
296-5205 General Ar
| 29***05 | General Ar | 1 |
| 29***06 | Engine Ar-Complete | 1 |
273-5732 General Ar-Genset
| 27***15 | Engine Ar-Complete | 1 |
| 27***32 | General Ar-Genset | 1 |
261-2215 Modification Ar-Engine
| 26***15 | Modification Ar-Engine | 1 |
Fuel System
237-7220 Base As-Fuel Tank
| 06***10 | Plug-Steel Pipe | 1 |
| 17***60 | Switch Group-Liquid Level; -Rear Engine Oil-Ster, Hydraulic Fan Oil-Engine On-Steering Oil, Engine Off-Auxiliary Coolant-Front Engine Oil-Brake Oil, Hoist-Engine Coolant-Tc Oil-Low, Cold | 1 |
| 22***42 | Tank-Fuel | 1 |
191-5055 Base Gp-Fuel Filter
| 19***55 | Base Group-Fuel Filter | 1 |
245-7697 Base Gp-Fuel Tank
| 22***78 | Seal-Ring; (Fuel And Water Sep Filter) | 1 |
| 24***97 | Base Group-Fuel Tank | 1 |
| 27***20 | Bowl As; (Fuel, Water Separator) | 1 |
245-7698 Base Gp-Fuel Tank
| 12***75 | Bowl As-Water Collection; (Water Separator, Fuel Filter) | 1 |
| 13***73 | Element; (Filter) (Fuel/Water Separator) (Primary) | 1 |
| 13***67 | Base As-Fuel | 1 |
245-7695 Base Gp-Fuel Tank
| 24***95 | Base Group-Fuel Tank | 1 |
245-7700 Base Gp-Fuel Tank
| 22***53 | Filter Group-Water Sep & Fuel | 1 |
| 24***00 | Base Group-Fuel Tank | 1 |
282-6276 Base Gp-Fuel Tank
| 00***26 | Connector; (Flared)(3/4-16 Thd, 47 mm Long) | 2 |
| 03***47 | Elbow-Filtered Fuel From Based Assembly | 1 |
| 03***42 | Seal-O-Ring; (11.89mm Id) | 1 |
245-7696 Base Gp-Fuel Tank
| 24***96 | Base Group-Fuel Tank | 1 |
245-7699 Base Gp-Fuel Tank
| 19***68 | Base As-Fuel Filter | 1 |
| 22***52 | Filter Group-Fuel; -With Water Separator | 1 |
| 24***99 | Base Group-Fuel Tank | 1 |
161-0797 Control As-Governor -Load Share
| 03***47 | Elbow-Filtered Fuel From Based Assembly | 1 |
| 03***42 | Seal-O-Ring; (11.89mm Id) | 1 |
| 09***66 | Clamp-Hose | 1 |
309-1583 Control As-Governor -Load Share
| 03***47 | Elbow-Filtered Fuel From Based Assembly | 5 |
| 03***42 | Seal-O-Ring; (11.89mm Id) | 6 |
| 06***51 | Clamp | 2 |
131-5567 Control As-Governor -Load Share
| 03***47 | Elbow-Filtered Fuel From Based Assembly | 1 |
| 03***42 | Seal-O-Ring; (11.89mm Id) | 1 |
| 09***66 | Clamp-Hose | 1 |
225-4152 Filter Gp-Fuel
| 03***37 | Connector-Port | 1 |
| 03***47 | Elbow-Filtered Fuel From Based Assembly | 4 |
| 03***62 | Elbow, Swivel Nut 45 Degrees (-6) | 1 |
133-5671 Filter Gp-Water Sep & Fuel
| 00***26 | Connector; (Flared)(3/4-16 Thd, 47 mm Long) | 6 |
| 03***47 | Elbow-Filtered Fuel From Based Assembly | 1 |
| 10***12 | Spacer; (11.13x19.05x53-mm Thk) | 1 |
225-4153 Filter Gp-Water Sep & Fuel
| 00***26 | Connector; (Flared)(3/4-16 Thd, 47 mm Long) | 6 |
| 03***47 | Elbow-Filtered Fuel From Based Assembly | 1 |
| 13***60 | Spacer; (11x19x10-mm Thk) | 2 |
264-2467 Filter Gp-Water Sep & Fuel
| 00***26 | Connector; (Flared)(3/4-16 Thd, 47 mm Long) | 2 |
| 03***47 | Elbow-Filtered Fuel From Based Assembly | 1 |
| 0T***65 | Bolt--3/8" X 3 1/2"--Use As Required; Bolt 5t***56 Plate To Cover Gp 4n***72 | 2 |
279-8774 Lines Gp-Fuel
| 0S***99 | Stud (1.4325" Long) | 2 |
| 10***69 | Seal-O-Ring; (Fuel Transfer Pump) | 2 |
| 13***16 | Cover | 1 |
298-6774 Lines Gp-Fuel
| 00***99 | Connector-Flared | 1 |
| 00***03 | Adapter-Pipe | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 5 |
250-2742 Lines Gp-Fuel
| 00***26 | Connector; (Flared)(3/4-16 Thd, 47 mm Long) | 2 |
| 03***47 | Elbow-Filtered Fuel From Based Assembly | 1 |
| 10***12 | Spacer; (11.13x19.05x53-mm Thk) | 1 |
302-7358 Lines Gp-Fuel
| 00***99 | Connector-Flared | 1 |
| 00***03 | Adapter-Pipe | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 3 |
276-8019 Lines Gp-Fuel
| 0S***99 | Stud (1.4325" Long) | 2 |
| 10***69 | Seal-O-Ring; (Fuel Transfer Pump) | 2 |
| 13***16 | Cover | 1 |
308-4896 Lines Gp-Fuel
| 13***41 | Pump Group-Fuel Priming; (Hand) | 1 |
| 19***55 | Base Group-Fuel Filter | 1 |
| 1B***82 | Bolt (1.25 In. Long X .313 In. Dia.) | 1 |
255-9077 Lines Gp-Fuel
| 03***42 | Seal-O-Ring; (11.89mm Id) | 2 |
| 0S***19 | Bolt,Machine Gear Retaining Part Of Kit P/N 1w***46 | 2 |
| 19***80 | Manifold As | 1 |
250-2928 Lines Gp-Fuel
| 0S***94 | Bolt (1 In. Long 3/8 In. Dia.); Plate Assembly To Support Assembly | 4 |
| 11***28 | Elbow; (90-Deg) | 3 |
| 1P***78 | Clamp; (Hose) | 1 |
308-4895 Lines Gp-Fuel
| 10***72 | Spacer; (9.8x15.85x37.6-mm Thk) | 1 |
| 23***28 | Seal-O-Ring; (32.99mm Id) | 1 |
| 23***75 | Seal-O-Ring; (36.09mm Id) | 1 |
213-3595 Lines Gp-Fuel Filter
| 00***99 | Connector-Flared | 1 |
| 11***36 | Valve As-Shutoff; (Jacket Water Heater) | 1 |
| 14***47 | Pump Group-Hand; (Fuel Transfer)(Fuel) | 1 |
191-0583 Manifold Gp-Fuel
| 00***99 | Connector-Flared | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 1 |
| 10***96 | Plug-Pipe; (3-1/2-8 Nptf Thread) | 1 |
150-4279 Pump & Mtg Gp-Fuel Transfer -Rear
| 00***99 | Connector-Flared | 1 |
| 00***03 | Adapter-Pipe | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 3 |
241-0361 Pump & Mtg Gp-Fuel Transfer
| 00***99 | Connector-Flared | 2 |
| 11***36 | Valve As-Shutoff; (Jacket Water Heater) | 1 |
| 14***47 | Pump Group-Hand; (Fuel Transfer)(Fuel) | 1 |
241-0363 Pump & Mtg Gp-Fuel Transfer
| 00***99 | Connector-Flared | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 1 |
| 13***52 | Plug-Adapter | 1 |
261-0048 Pump Gp-Fuel Injection
| 00***15 | Nipple-Pipe; (59.4mm Long) | 1 |
| 13***52 | Plug-Adapter | 1 |
| 14***47 | Pump Group-Hand; (Fuel Transfer)(Fuel) | 1 |
276-8020 Pump Gp-Fuel Prm & Sec Filter
| 00***99 | Connector-Flared | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 1 |
| 13***52 | Plug-Adapter | 1 |
255-3334 Pump Gp-Fuel Transfer
| 23***77 | Base As | 1 |
| 24***80 | Pipe-Fuel; (Filler) | 1 |
| 24***82 | Valve; (Fuel Tank)(Pressure Release) | 2 |
254-6706 Pump Gp-Fuel Transfer
| 00***99 | Connector-Flared | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 1 |
| 13***52 | Plug-Adapter | 1 |
255-3331 Pump Gp-Fuel Transfer
| 23***78 | Base As | 1 |
| 24***80 | Pipe-Fuel; (Filler) | 1 |
| 24***82 | Valve; (Fuel Tank)(Pressure Release) | 2 |
255-3329 Pump Gp-Fuel Transfer
| 00***99 | Connector-Flared | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 1 |
| 10***96 | Plug-Pipe; (3-1/2-8 Nptf Thread) | 1 |
254-6709 Pump Gp-Fuel Transfer
| 00***99 | Connector-Flared | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 1 |
| 10***96 | Plug-Pipe; (3-1/2-8 Nptf Thread) | 1 |
255-4646 Pump Gp-Fuel Transfer
| 25***46 | Pump Group-Fuel Transfer | 1 |
| 28***25 | Valve Group-Check; -Fuel | 1 |
| 6V***89 | Seal-O-Ring (Id=19.18mm) | 1 |
256-4149 Pump Gp-Fuel Transfer
| 03***33 | Seal-O-Ring; (12.42mm Id) | 1 |
| 25***49 | Pump Group-Fuel Transfer | 1 |
| 6V***23 | Ring; (Backup) (13.16mm Id) | 1 |
256-4150 Pump Gp-Fuel Transfer
| 00***99 | Connector-Flared | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 1 |
| 13***52 | Plug-Adapter | 1 |
255-3328 Pump Gp-Fuel Transfer
| 00***99 | Connector-Flared | 2 |
| 11***36 | Valve As-Shutoff; (Jacket Water Heater) | 1 |
| 14***47 | Pump Group-Hand; (Fuel Transfer)(Fuel) | 1 |
255-3330 Pump Gp-Fuel Transfer
| 09***08 | Seal-O-Ring (Id=44.70mm) | 1 |
| 10***52 | Plug | 1 |
| 14***51 | Pipe-Fuel Filler | 1 |
254-6757 Pump Gp-Fuel Transfer
| 00***99 | Connector-Flared | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 1 |
| 10***96 | Plug-Pipe; (3-1/2-8 Nptf Thread) | 1 |
254-6707 Pump Gp-Fuel Transfer
| 00***99 | Connector-Flared | 1 |
| 00***03 | Adapter-Pipe | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 5 |
256-4151 Pump Gp-Hand -Fuel Transfer
| 00***99 | Connector-Flared | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 1 |
| 13***52 | Plug-Adapter | 1 |
256-4152 Pump Gp-Hand -Fuel Transfer
| 00***99 | Connector-Flared | 2 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 3 |
| 13***52 | Plug-Adapter | 1 |
334-0485 Tank & Base Gp-Fuel
| 00***99 | Connector-Flared | 2 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 3 |
| 13***52 | Plug-Adapter | 1 |
251-1421 Tank & Base Gp-Fuel
| 25***21 | Tank & Base Group-Fuel | 1 |
| 9X***37 | Seal-O-Ring | 1 |
249-4655 Tank & Base Gp-Fuel
| 00***99 | Connector-Flared | 1 |
| 00***15 | Nipple-Pipe; (59.4mm Long) | 1 |
| 10***96 | Plug-Pipe; (3-1/2-8 Nptf Thread) | 1 |
251-1422 Tank Gp-Fuel
| 03***12 | Screw-Forming; (10-24x0.5-In) | 5 |
| 11***19 | Diode As-Alternator | 1 |
| 18***34 | Nut-Flange; (5/8-18-Thd) | 1 |
281-2725 Valve Gp-Check -Fuel
| 28***25 | Valve Group-Check; -Fuel | 1 |
233-6742 Valve Gp-Check -Fuel
| 23***42 | Valve Group-Check; -Fuel Filter | 1 |
255-3333 Valve Gp-Fuel
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 2 |
| 14***95 | Battery Charger | 1 |
| 16***02 | Holder-Fuse | 2 |
255-4645 Valve Gp-Fuel
| 14***72 | Fuse; (6-Ampere)(European Sourced) | 1 |
| 14***80 | Fuse; (10-Ampere)(European Sourced) | 1 |
| 14***94 | Battery Charger | 1 |
256-4153 Valve Gp-Fuel
| 25***53 | Valve Group-Fuel | 1 |
| 7N***60 | Vent As; (Battery) | 6 |
254-6708 Valve Gp-Fuel
| 25***08 | Valve Group-Fuel; -Shutoff | 1 |
139-6873 Valve Gp-Fuel Bypass -Filter
| 12***73 | Cap As-Filler; (Battery) | 6 |
| 13***73 | Valve Group-Fuel Bypass; -Filter | 1 |
241-0362 Valve Gp-Fuel Shutoff
| 14***58 | Bolt | 3 |
| 24***65 | Cable As | 1 |
| 24***62 | Valve Group-Fuel Shutoff | 1 |
Generators
330-0982 Connection Gp-Generator Leads
| 32***90 | Generator Group | 1 |
| 33***82 | Connection Group-Generator Leads | 1 |
330-0979 Connection Gp-Generator Leads
| 32***85 | Generator Group | 1 |
| 33***79 | Connection Group-Generator Leads | 1 |
330-0952 Connection Gp-Generator Leads
| 33***05 | Cable As | 3 |
| 33***07 | Cable As | 1 |
| 33***52 | Connection Group-Generator Leads | 1 |
239-7792 Connection Gp-Generator Leads
| 23***92 | Connection Group-Generator Leads | 1 |
| 23***21 | Cable As-Braided | 8 |
| 27***74 | Plate | 2 |
330-0969 Connection Gp-Generator Leads
| 14***56 | Insulator | 2 |
| 25***34 | Bar-Bus | 1 |
| 25***35 | Bar-Bus | 1 |
330-0869 Connection Gp-Generator Leads
| 33***69 | Connection Group-Generator Leads | 1 |
| 33***33 | Cable As | 1 |
| 33***34 | Cable As | 2 |
299-5924 Connection Gp-Generator Leads
| 29***24 | Connection Group-Generator Leads | 1 |
| 33***36 | Cable As | 2 |
| 33***37 | Cable As | 2 |
330-0892 Connection Gp-Generator Leads
| 33***92 | Connection Group-Generator Leads | 1 |
| 33***36 | Cable As | 1 |
| 33***37 | Cable As | 2 |
330-0972 Connection Gp-Generator Leads
| 14***56 | Insulator | 2 |
| 29***67 | Terminal | 1 |
| 33***72 | Connection Group-Generator Leads | 1 |
330-0954 Connection Gp-Generator Leads
| 33***33 | Cable As | 2 |
| 33***34 | Cable As | 1 |
| 33***35 | Cable As | 1 |
239-9728 Connection Gp-Generator Leads
| 03***95 | Terminal-Ring; (0000-Ga, 3/8-In Screw) | 2 |
| 18***58 | Cable; (0000-Ga)(180-cm) | 0 |
| 23***28 | Connection Group-Generator Leads | 1 |
299-5922 Connection Gp-Generator Leads
| 29***22 | Connection Group-Generator Leads | 1 |
| 33***04 | Cable As | 3 |
| 33***05 | Cable As | 1 |
284-9218 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 28***18 | Connection Group-Generator Leads | 1 |
| 29***02 | Cable As | 4 |
239-9808 Connection Gp-Generator Leads
| 23***08 | Connection Group-Generator Leads | 1 |
| 25***85 | Cable-Electrical; (0000-Ga, Black)(145-cm) | 0 |
| 29***39 | Cable As | 1 |
240-2118 Connection Gp-Generator Leads
| 24***18 | Connection Group-Generator Leads | 1 |
| 24***52 | Cable As; -Copper Braid | 4 |
| 27***74 | Plate | 2 |
239-7790 Connection Gp-Generator Leads
| 23***90 | Connection Group-Generator Leads | 1 |
| 24***17 | Cable As-Braided | 4 |
| 27***74 | Plate | 2 |
330-0977 Connection Gp-Generator Leads
| 32***81 | Generator Group | 1 |
| 33***77 | Connection Group-Generator Leads | 1 |
330-0986 Connection Gp-Generator Leads
| 32***94 | Generator Group | 1 |
| 33***86 | Connection Group-Generator Leads | 1 |
330-0987 Connection Gp-Generator Leads
| 32***98 | Generator Group | 1 |
| 33***87 | Connection Group-Generator Leads | 1 |
330-0980 Connection Gp-Generator Leads
| 32***87 | Generator Group | 1 |
| 33***80 | Connection Group-Generator Leads | 1 |
330-0866 Connection Gp-Generator Leads
| 33***66 | Connection Group-Generator Leads | 1 |
| 33***73 | Cable As | 1 |
| 33***74 | Cable As | 2 |
330-0989 Connection Gp-Generator Leads
| 32***00 | Generator Group | 1 |
| 33***89 | Connection Group-Generator Leads | 1 |
330-0973 Connection Gp-Generator Leads
| 14***56 | Insulator | 2 |
| 29***74 | Terminal | 1 |
| 33***73 | Connection Group-Generator Leads | 1 |
330-0921 Connection Gp-Generator Leads
| 33***01 | Cable As | 1 |
| 33***02 | Cable As | 5 |
| 33***03 | Cable As | 1 |
330-0899 Connection Gp-Generator Leads
| 33***99 | Connection Group-Generator Leads | 1 |
| 33***02 | Cable As | 1 |
| 33***03 | Cable As | 5 |
239-7799 Connection Gp-Generator Leads
| 23***99 | Connection Group-Generator Leads | 1 |
| 23***18 | Cable As-Braided | 4 |
| 26***66 | Plate | 2 |
289-2780 Connection Gp-Generator Leads
| 26***66 | Plate | 2 |
| 28***80 | Connection Group-Generator Leads | 1 |
| 29***08 | Cable As | 4 |
330-0868 Connection Gp-Generator Leads
| 33***68 | Connection Group-Generator Leads | 1 |
| 33***74 | Cable As | 1 |
| 33***75 | Cable As | 3 |
330-0929 Connection Gp-Generator Leads
| 33***06 | Cable As | 2 |
| 33***07 | Cable As | 1 |
| 33***08 | Cable As | 1 |
289-2818 Connection Gp-Generator Leads
| 26***66 | Plate | 2 |
| 28***18 | Connection Group-Generator Leads | 1 |
| 29***14 | Cable As | 4 |
330-0837 Connection Gp-Generator Leads
| 33***37 | Connection Group-Generator Leads | 1 |
| 33***71 | Cable As | 3 |
| 33***72 | Cable As | 3 |
298-5296 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 29***96 | Connection Group-Generator Leads | 1 |
| 29***20 | Cable As | 8 |
299-5907 Connection Gp-Generator Leads
| 29***07 | Connection Group-Generator Leads | 1 |
| 33***49 | Cable As | 2 |
| 33***50 | Cable As | 2 |
299-5927 Connection Gp-Generator Leads
| 29***27 | Connection Group-Generator Leads | 1 |
| 33***35 | Cable As | 3 |
| 33***36 | Cable As | 1 |
330-0966 Connection Gp-Generator Leads
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 6 |
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 8 |
| 23***82 | Bracket As | 1 |
330-0960 Connection Gp-Generator Leads
| 33***06 | Cable As | 2 |
| 33***07 | Cable As | 4 |
| 33***08 | Cable As | 1 |
330-0974 Connection Gp-Generator Leads
| 14***56 | Insulator | 2 |
| 31***95 | Terminal | 1 |
| 33***74 | Connection Group-Generator Leads | 1 |
330-0968 Connection Gp-Generator Leads
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 6 |
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 8 |
| 23***82 | Bracket As | 1 |
284-9219 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 28***19 | Connection Group-Generator Leads | 1 |
| 29***97 | Cable As | 4 |
284-9159 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 28***59 | Connection Group-Generator Leads | 1 |
| 29***94 | Cable As | 8 |
299-5925 Connection Gp-Generator Leads
| 29***25 | Connection Group-Generator Leads | 1 |
| 33***33 | Cable As | 3 |
| 33***34 | Cable As | 1 |
330-0976 Connection Gp-Generator Leads
| 32***80 | Generator Group | 1 |
| 33***76 | Connection Group-Generator Leads | 1 |
239-7795 Connection Gp-Generator Leads
| 23***95 | Connection Group-Generator Leads | 1 |
| 23***15 | Cable As-Braided | 8 |
| 26***66 | Plate | 2 |
330-0898 Connection Gp-Generator Leads
| 33***98 | Connection Group-Generator Leads | 1 |
| 33***06 | Cable As | 1 |
| 33***07 | Cable As | 5 |
299-5910 Connection Gp-Generator Leads
| 29***10 | Connection Group-Generator Leads | 1 |
| 33***43 | Cable As | 3 |
| 33***44 | Cable As | 1 |
284-9217 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 28***17 | Connection Group-Generator Leads | 1 |
| 29***00 | Cable As | 4 |
239-7794 Connection Gp-Generator Leads
| 23***94 | Connection Group-Generator Leads | 1 |
| 23***14 | Cable As-Braided | 8 |
| 26***66 | Plate | 2 |
299-5905 Connection Gp-Generator Leads
| 29***05 | Connection Group-Generator Leads | 1 |
| 33***44 | Cable As | 3 |
| 33***45 | Cable As | 1 |
299-5893 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 29***93 | Connection Group-Generator Leads | 1 |
| 29***31 | Cable As | 8 |
330-0926 Connection Gp-Generator Leads
| 33***45 | Cable As | 3 |
| 33***47 | Cable As | 1 |
| 33***26 | Connection Group-Generator Leads | 1 |
330-1086 Connection Gp-Generator Leads
| 32***06 | Generator Group | 1 |
| 33***86 | Connection Group-Generator Leads | 1 |
239-9735 Connection Gp-Generator Leads
| 23***35 | Connection Group-Generator Leads | 1 |
| 24***67 | Terminal | 2 |
| 24***60 | Terminal As | 1 |
284-9216 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 28***16 | Connection Group-Generator Leads | 1 |
| 29***99 | Cable As | 8 |
295-2265 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 29***65 | Connection Group-Generator Leads | 1 |
| 29***18 | Cable As | 4 |
330-0838 Connection Gp-Generator Leads
| 33***38 | Connection Group-Generator Leads | 1 |
| 33***76 | Cable As | 1 |
| 33***77 | Cable As | 5 |
330-0955 Connection Gp-Generator Leads
| 33***35 | Cable As | 3 |
| 33***37 | Cable As | 1 |
| 33***55 | Connection Group-Generator Leads | 1 |
330-0964 Connection Gp-Generator Leads
| 33***05 | Cable As | 2 |
| 33***06 | Cable As | 3 |
| 33***07 | Cable As | 2 |
299-5901 Connection Gp-Generator Leads
| 29***01 | Connection Group-Generator Leads | 1 |
| 33***46 | Cable As | 2 |
| 33***47 | Cable As | 2 |
330-0975 Connection Gp-Generator Leads
| 32***77 | Generator Group | 1 |
| 33***75 | Connection Group-Generator Leads | 1 |
301-3040 Connection Gp-Generator Leads
| 30***40 | Connection Group-Generator Leads | 1 |
| 33***34 | Cable As | 3 |
| 33***35 | Cable As | 1 |
330-0864 Connection Gp-Generator Leads
| 33***64 | Connection Group-Generator Leads | 1 |
| 33***72 | Cable As | 2 |
| 33***73 | Cable As | 3 |
330-0891 Connection Gp-Generator Leads
| 33***91 | Connection Group-Generator Leads | 1 |
| 33***31 | Cable As | 3 |
| 33***33 | Cable As | 1 |
330-0970 Connection Gp-Generator Leads
| 14***56 | Insulator | 2 |
| 28***20 | Terminal; (Copper) | 1 |
| 28***21 | Terminal | 1 |
299-5892 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 29***92 | Connection Group-Generator Leads | 1 |
| 29***30 | Cable As | 4 |
330-0956 Connection Gp-Generator Leads
| 33***73 | Cable As | 3 |
| 33***74 | Cable As | 3 |
| 33***75 | Cable As | 1 |
299-5898 Connection Gp-Generator Leads
| 23***14 | Cable As-Braided | 4 |
| 26***66 | Plate | 2 |
| 29***98 | Connection Group-Generator Leads | 1 |
330-0924 Connection Gp-Generator Leads
| 33***43 | Cable As | 2 |
| 33***44 | Cable As | 1 |
| 33***45 | Cable As | 1 |
330-0865 Connection Gp-Generator Leads
| 33***65 | Connection Group-Generator Leads | 1 |
| 33***78 | Cable As | 3 |
| 33***79 | Cable As | 2 |
239-9809 Connection Gp-Generator Leads
| 23***09 | Connection Group-Generator Leads | 1 |
| 27***74 | Plate | 2 |
| 29***97 | Braid | 8 |
330-0953 Connection Gp-Generator Leads
| 33***36 | Cable As | 2 |
| 33***37 | Cable As | 1 |
| 33***38 | Cable As | 1 |
330-0978 Connection Gp-Generator Leads
| 32***83 | Generator Group | 1 |
| 33***78 | Connection Group-Generator Leads | 1 |
309-8691 Connection Gp-Generator Leads
| 30***91 | Connection Group-Generator Leads | 1 |
| 33***35 | Cable As | 1 |
| 33***36 | Cable As | 2 |
239-7787 Connection Gp-Generator Leads
| 23***87 | Connection Group-Generator Leads | 1 |
| 4D***43 | Lockwasher | 16 |
| 8T***21 | Washer-Hard; (11x21x2.5-mm Thk)(M10x1.50x30mm) | 32 |
330-0962 Connection Gp-Generator Leads
| 33***08 | Cable As | 1 |
| 33***09 | Cable As | 3 |
| 33***10 | Filter Head Adapter, Cable As | 3 |
330-0990 Connection Gp-Generator Leads
| 32***01 | Generator Group | 1 |
| 33***90 | Connection Group-Generator Leads | 1 |
330-0895 Connection Gp-Generator Leads
| 33***95 | Connection Group-Generator Leads | 1 |
| 33***33 | Cable As | 3 |
| 33***35 | Cable As | 1 |
239-7796 Connection Gp-Generator Leads
| 23***96 | Connection Group-Generator Leads | 1 |
| 24***67 | Terminal | 8 |
239-7793 Connection Gp-Generator Leads
| 23***93 | Connection Group-Generator Leads | 1 |
| 23***21 | Cable As-Braided | 8 |
| 27***74 | Plate | 2 |
330-0951 Connection Gp-Generator Leads
| 33***03 | Cable As | 2 |
| 33***04 | Cable As | 1 |
| 33***05 | Cable As | 1 |
330-0985 Connection Gp-Generator Leads
| 32***93 | Generator Group | 1 |
| 33***85 | Connection Group-Generator Leads | 1 |
239-7798 Connection Gp-Generator Leads
| 23***98 | Connection Group-Generator Leads | 1 |
| 23***17 | Cable As-Braided | 4 |
| 26***66 | Plate | 2 |
330-0861 Connection Gp-Generator Leads
| 33***61 | Connection Group-Generator Leads | 1 |
| 33***71 | Cable As | 1 |
| 33***72 | Cable As | 5 |
330-1082 Connection Gp-Generator Leads
| 32***03 | Generator Group | 1 |
| 33***82 | Connection Group-Generator Leads | 1 |
239-8272 Connection Gp-Generator Leads
| 23***19 | Cable As-Braided | 4 |
| 23***72 | Connection Group-Generator Leads | 1 |
| 26***66 | Plate | 2 |
299-5915 Connection Gp-Generator Leads
| 29***15 | Connection Group-Generator Leads | 1 |
| 33***06 | Cable As | 2 |
| 33***07 | Cable As | 2 |
330-0967 Connection Gp-Generator Leads
| 14***56 | Insulator | 2 |
| 23***88 | Terminal | 1 |
| 23***89 | Terminal | 1 |
330-0959 Connection Gp-Generator Leads
| 33***75 | Cable As | 2 |
| 33***76 | Cable As | 3 |
| 33***77 | Cable As | 2 |
289-2816 Connection Gp-Generator Leads
| 26***66 | Plate | 2 |
| 28***16 | Connection Group-Generator Leads | 1 |
| 29***09 | Cable As | 4 |
330-0867 Connection Gp-Generator Leads
| 33***67 | Connection Group-Generator Leads | 1 |
| 33***72 | Cable As | 1 |
| 33***73 | Cable As | 2 |
239-9170 Connection Gp-Generator Leads
| 03***95 | Terminal-Ring; (0000-Ga, 3/8-In Screw) | 2 |
| 18***58 | Cable; (0000-Ga)(180-cm) | 0 |
| 23***70 | Connection Group-Generator Leads | 1 |
239-7788 Connection Gp-Generator Leads
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 16 |
| 23***88 | Connection Group-Generator Leads | 1 |
| 24***07 | Bolt; (M6x1x40-mm)(Hex Head) | 16 |
330-0897 Connection Gp-Generator Leads
| 33***97 | Connection Group-Generator Leads | 1 |
| 33***01 | Cable As | 3 |
| 33***02 | Cable As | 3 |
330-0925 Connection Gp-Generator Leads
| 33***49 | Cable As | 2 |
| 33***50 | Cable As | 1 |
| 33***51 | Cable As | 1 |
330-0922 Connection Gp-Generator Leads
| 33***03 | Cable As | 5 |
| 33***04 | Cable As | 1 |
| 33***05 | Cable As | 2 |
330-0992 Connection Gp-Generator Leads
| 24***24 | Generator Group | 1 |
| 33***92 | Connection Group-Generator Leads | 1 |
330-0957 Connection Gp-Generator Leads
| 33***78 | Cable As | 1 |
| 33***79 | Cable As | 3 |
| 33***80 | Cable As | 3 |
330-0963 Connection Gp-Generator Leads
| 33***04 | Cable As | 3 |
| 33***05 | Cable As | 3 |
| 33***06 | Cable As | 1 |
330-0981 Connection Gp-Generator Leads
| 32***89 | Generator Group | 1 |
| 33***81 | Connection Group-Generator Leads | 1 |
330-1084 Connection Gp-Generator Leads
| 32***05 | Generator Group | 1 |
| 33***84 | Connection Group-Generator Leads | 1 |
284-9185 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 28***85 | Connection Group-Generator Leads | 1 |
| 29***97 | Cable As | 8 |
330-0983 Connection Gp-Generator Leads
| 32***91 | Generator Group | 1 |
| 33***83 | Connection Group-Generator Leads | 1 |
250-9941 Connection Gp-Generator Leads
| 24***53 | Cable As; -Copper Braid | 4 |
| 25***41 | Connection Group-Generator Leads | 1 |
| 27***74 | Plate | 2 |
330-0991 Connection Gp-Generator Leads
| 32***02 | Generator Group | 1 |
| 33***91 | Connection Group-Generator Leads | 1 |
299-5896 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 29***96 | Connection Group-Generator Leads | 1 |
| 30***39 | Cable As | 8 |
330-0893 Connection Gp-Generator Leads
| 33***93 | Connection Group-Generator Leads | 1 |
| 33***32 | Cable As | 1 |
| 33***33 | Cable As | 2 |
309-8692 Connection Gp-Generator Leads -Generator Leads
| 30***92 | Connection Group-Generator Leads; -Generator Leads | 1 |
| 33***73 | Cable As | 1 |
| 33***74 | Cable As | 4 |
299-5890 Connection Gp-Generator Leads
| 26***66 | Plate | 2 |
| 29***90 | Connection Group-Generator Leads | 1 |
| 29***28 | Cable As | 4 |
330-1087 Connection Gp-Generator Leads
| 32***07 | Generator Group | 1 |
| 33***87 | Connection Group-Generator Leads | 1 |
330-0988 Connection Gp-Generator Leads
| 32***99 | Generator Group | 1 |
| 33***88 | Connection Group-Generator Leads | 1 |
330-1083 Connection Gp-Generator Leads
| 32***04 | Generator Group | 1 |
| 33***83 | Connection Group-Generator Leads | 1 |
330-0894 Connection Gp-Generator Leads
| 33***94 | Connection Group-Generator Leads | 1 |
| 33***31 | Cable As | 1 |
| 33***32 | Cable As | 2 |
299-5903 Connection Gp-Generator Leads
| 29***03 | Connection Group-Generator Leads | 1 |
| 33***45 | Cable As | 3 |
| 33***46 | Cable As | 1 |
330-0965 Connection Gp-Generator Leads
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 6 |
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 8 |
| 23***82 | Bracket As | 1 |
299-5889 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 29***89 | Connection Group-Generator Leads | 1 |
| 29***16 | Cable As | 8 |
299-5919 Connection Gp-Generator Leads
| 29***19 | Connection Group-Generator Leads | 1 |
| 33***09 | Cable As | 2 |
| 33***10 | Filter Head Adapter, Cable As | 2 |
330-0896 Connection Gp-Generator Leads
| 33***96 | Connection Group-Generator Leads | 1 |
| 33***03 | Cable As | 1 |
| 33***04 | Cable As | 4 |
330-0984 Connection Gp-Generator Leads
| 32***92 | Generator Group | 1 |
| 33***84 | Connection Group-Generator Leads | 1 |
299-5923 Connection Gp-Generator Leads
| 29***23 | Connection Group-Generator Leads | 1 |
| 33***05 | Cable As | 1 |
| 33***06 | Cable As | 2 |
239-7791 Connection Gp-Generator Leads
| 23***91 | Connection Group-Generator Leads | 1 |
| 23***20 | Cable As-Braided | 8 |
| 27***74 | Plate | 2 |
330-0839 Connection Gp-Generator Leads
| 33***39 | Connection Group-Generator Leads | 1 |
| 33***72 | Cable As | 1 |
| 33***73 | Cable As | 5 |
330-1085 Connection Gp-Generator Leads
| 24***29 | Generator Group | 1 |
| 33***85 | Connection Group-Generator Leads | 1 |
330-0927 Connection Gp-Generator Leads
| 33***44 | Cable As | 3 |
| 33***46 | Cable As | 1 |
| 33***27 | Connection Group-Generator Leads | 1 |
299-5911 Connection Gp-Generator Leads
| 29***11 | Connection Group-Generator Leads | 1 |
| 33***45 | Cable As | 1 |
| 33***46 | Cable As | 2 |
299-5895 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 29***95 | Connection Group-Generator Leads | 1 |
| 29***29 | Cable As | 8 |
299-5921 Connection Gp-Generator Leads
| 29***21 | Connection Group-Generator Leads | 1 |
| 33***05 | Cable As | 3 |
| 33***06 | Cable As | 1 |
330-0862 Connection Gp-Generator Leads
| 33***62 | Connection Group-Generator Leads | 1 |
| 33***73 | Cable As | 5 |
| 33***74 | Cable As | 1 |
330-0923 Connection Gp-Generator Leads
| 33***46 | Cable As | 2 |
| 33***47 | Cable As | 1 |
| 33***48 | Cable As | 1 |
239-7797 Connection Gp-Generator Leads
| 23***97 | Connection Group-Generator Leads | 1 |
| 26***66 | Plate | 2 |
| 26***98 | Cable As-Braided | 4 |
299-5891 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 29***91 | Connection Group-Generator Leads | 1 |
| 29***29 | Cable As | 4 |
330-0863 Connection Gp-Generator Leads
| 33***63 | Connection Group-Generator Leads | 1 |
| 33***75 | Cable As | 1 |
| 33***76 | Cable As | 4 |
330-0971 Connection Gp-Generator Leads
| 26***06 | Terminal | 4 |
| 26***07 | Terminal | 4 |
| 33***71 | Connection Group-Generator Leads | 1 |
299-5917 Connection Gp-Generator Leads
| 29***17 | Connection Group-Generator Leads | 1 |
| 33***03 | Cable As | 3 |
| 33***04 | Cable As | 1 |
289-2779 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 28***79 | Pin Dowel, Pin Dowel; Application:, Connection Group-Generator Leads | 1 |
| 29***94 | Cable As | 4 |
251-0901 Connection Gp-Generator Leads
| 24***51 | Cable As; -Copper Braid | 4 |
| 25***01 | Connection Group-Generator Leads | 1 |
| 26***66 | Plate | 2 |
283-9199 Connection Gp-Generator Leads
| 24***68 | Cable As; -Copper Braid | 8 |
| 27***74 | Plate | 2 |
| 28***99 | Connection Group-Generator Leads | 1 |
284-9158 Connection Gp-Generator Leads
| 24***52 | Cable As; -Copper Braid | 8 |
| 27***74 | Plate | 2 |
| 28***58 | Connection Group-Generator Leads | 1 |
239-7789 Connection Gp-Generator Leads
| 23***89 | Connection Group-Generator Leads | 1 |
| 4D***43 | Lockwasher | 16 |
| 8T***21 | Washer-Hard; (11x21x2.5-mm Thk)(M10x1.50x30mm) | 24 |
295-2264 Connection Gp-Generator Leads
| 27***74 | Plate | 2 |
| 29***64 | Connection Group-Generator Leads | 1 |
| 29***16 | Cable As | 4 |
299-5926 Connection Gp-Generator Leads
| 29***26 | Connection Group-Generator Leads | 1 |
| 33***39 | Cable As | 2 |
| 33***40 | Cable As | 2 |
330-0961 Connection Gp-Generator Leads
| 33***03 | Cable As | 3 |
| 33***04 | Cable As | 3 |
| 33***05 | Cable As | 1 |
239-9736 Connection Gp-Generator Leads
| 23***36 | Connection Group-Generator Leads | 1 |
| 25***85 | Cable-Electrical; (0000-Ga, Black)(145-cm) | 0 |
| 29***40 | Cable As | 1 |
330-0928 Connection Gp-Generator Leads
| 33***45 | Cable As | 1 |
| 33***46 | Cable As | 1 |
| 33***47 | Cable As | 2 |
330-0958 Connection Gp-Generator Leads
| 33***75 | Cable As | 3 |
| 33***76 | Cable As | 3 |
| 33***77 | Cable As | 2 |
284-9226 Connection Gp-Terminal Strip
| 13***26 | Film-Control Panel; (Generator Wiring Diagram) | 1 |
| 28***26 | Connection Group-Terminal Strip | 1 |
| 29***01 | Generator Group | 1 |
250-9936 Connection Gp-Terminal Strip
| 25***36 | Connection Group-Terminal Strip | 1 |
| 32***24 | Generator Group | 1 |
237-2625 Connection Gp-Terminal Strip
| 23***25 | Connection Group-Terminal Strip | 1 |
| 32***10 | Generator Group | 1 |
237-2624 Connection Gp-Terminal Strip
| 23***24 | Connection Group-Terminal Strip | 1 |
| 32***09 | Generator Group | 1 |
284-9224 Connection Gp-Terminal Strip
| 28***24 | Connection Group-Terminal Strip | 1 |
| 32***28 | Generator Group | 1 |
284-9222 Connection Gp-Terminal Strip
| 28***22 | Connection Group-Terminal Strip | 1 |
| 32***26 | Generator Group | 1 |
323-5757 Connection Gp-Terminal Strip
| 32***57 | Connection Group-Terminal Strip | 1 |
| 33***95 | Generator Group | 1 |
295-2381 Connection Gp-Terminal Strip
| 29***81 | Connection Group-Terminal Strip | 1 |
| 33***93 | Generator Group | 1 |
250-9939 Connection Gp-Terminal Strip
| 25***39 | Connection Group-Terminal Strip | 1 |
| 32***25 | Generator Group | 1 |
351-2630 Connection Gp-Terminal Strip
| 33***99 | Generator Group | 1 |
| 35***30 | Connection Group-Terminal Strip | 1 |
237-9990 Connection Gp-Terminal Strip
| 23***90 | Connection Group-Terminal Strip | 1 |
| 32***15 | Generator Group | 1 |
237-2627 Connection Gp-Terminal Strip
| 23***27 | Connection Group-Terminal Strip | 1 |
| 32***12 | Generator Group | 1 |
237-2626 Connection Gp-Terminal Strip
| 23***26 | Connection Group-Terminal Strip | 1 |
| 32***11 | Generator Group | 1 |
284-9223 Connection Gp-Terminal Strip
| 28***23 | Connection Group-Terminal Strip | 1 |
| 32***27 | Generator Group | 1 |
295-2379 Connection Gp-Terminal Strip
| 29***79 | Connection Group-Terminal Strip | 1 |
| 33***91 | Generator Group | 1 |
323-5758 Connection Gp-Terminal Strip
| 32***58 | Connection Group-Terminal Strip | 1 |
| 33***97 | Generator Group | 1 |
237-9987 Connection Gp-Terminal Strip
| 23***87 | Connection Group-Terminal Strip | 1 |
| 32***14 | Generator Group | 1 |
237-2623 Connection Gp-Terminal Strip
| 23***23 | Connection Group-Terminal Strip | 1 |
| 32***08 | Generator Group | 1 |
295-2372 Connection Gp-Terminal Strip
| 29***72 | Connection Group-Terminal Strip | 1 |
| 32***26 | Generator Group | 1 |
295-2373 Connection Gp-Terminal Strip
| 29***73 | Connection Group-Terminal Strip | 1 |
| 32***96 | Generator Group | 1 |
245-2639 Connection Gp-Terminal Strip
| 24***39 | Connection Group-Terminal Strip | 1 |
| 32***23 | Generator Group | 1 |
237-6178 Connection Gp-Terminal Strip
| 23***78 | Connection Group-Terminal Strip | 1 |
| 32***13 | Generator Group | 1 |
338-2009 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
247-1709 Generator Ar
| 24***09 | Generator Ar | 1 |
| 33***65 | Generator Group | 1 |
247-1712 Generator Ar
| 24***12 | Generator Ar | 1 |
| 33***71 | Generator Group | 1 |
247-1705 Generator Ar
| 24***05 | Generator Ar | 1 |
| 33***57 | Generator Group | 1 |
338-2011 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 23***90 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***77 | Eye-Lifting | 1 |
338-1996 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2098 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 23***90 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***77 | Eye-Lifting | 1 |
247-6124 Generator Ar
| 24***24 | Generator Ar | 1 |
| 33***87 | Generator Group | 1 |
356-0127 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-1998 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
235-1216 Generator Ar
| 23***16 | Generator Ar | 1 |
| 33***28 | Generator Group | 1 |
338-2080 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
235-1207 Generator Ar
| 23***07 | Generator Ar | 1 |
| 33***10 | Generator Group | 1 |
338-2007 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2074 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
235-1212 Generator Ar
| 23***12 | Generator Ar | 1 |
| 33***20 | Generator Group | 1 |
338-2086 Generator Ar
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
| 24***03 | Exciter | 1 |
356-0125 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
235-1218 Generator Ar
| 23***18 | Generator Ar | 1 |
| 33***32 | Generator Group | 1 |
235-1220 Generator Ar
| 23***20 | Generator Ar | 1 |
| 33***34 | Generator Group | 1 |
338-2129 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
247-6121 Generator Ar
| 24***21 | Generator Ar | 1 |
| 33***83 | Generator Group | 1 |
338-2003 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 23***90 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***77 | Eye-Lifting | 1 |
338-2062 Generator Ar
| 23***91 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
235-1205 Generator Ar
| 23***05 | Generator Ar, Shaft-Drive | 1 |
| 33***06 | Generator Group | 1 |
247-6122 Generator Ar
| 24***22 | Generator Ar | 1 |
| 33***85 | Generator Group | 1 |
338-2096 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 23***90 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***77 | Eye-Lifting | 1 |
338-2054 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 23***91 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***77 | Eye-Lifting | 1 |
338-2052 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2070 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2082 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2104 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
235-1237 Generator Ar
| 23***37 | Generator Ar | 1 |
| 33***53 | Generator Group | 1 |
266-7105 Generator Ar
| 26***05 | Generator Ar | 1 |
| 33***03 | Generator Group | 1 |
338-2064 Generator Ar
| 23***91 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
338-1992 Generator Ar
| 10***49 | Stator-Exciter | 1 |
| 10***50 | Rotor-Exciter | 1 |
| 10***22 | Retainer | 2 |
338-2066 Generator Ar
| 23***91 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
338-2112 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
247-1710 Generator Ar
| 24***10 | Generator Ar | 1 |
| 33***67 | Generator Group | 1 |
247-1706 Generator Ar
| 24***06 | Generator Ar | 1 |
| 33***57 | Generator Group | 1 |
338-1990 Generator Ar
| 23***91 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
247-1714 Generator Ar
| 24***14 | Generator Ar | 1 |
| 33***75 | Generator Group | 1 |
266-7108 Generator Ar
| 26***08 | Generator Ar | 1 |
| 33***09 | Generator Group | 1 |
338-2019 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 23***90 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***77 | Eye-Lifting | 1 |
338-2072 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2084 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 23***91 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***77 | Eye-Lifting | 1 |
266-7103 Generator Ar
| 26***03 | Generator Ar | 1 |
| 33***99 | Generator Group | 1 |
266-7107 Generator Ar
| 26***07 | Generator Ar | 1 |
| 33***07 | Generator Group | 1 |
338-2025 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
235-1215 Generator Ar
| 23***15 | Generator Ar | 1 |
| 33***26 | Generator Group | 1 |
235-1210 Generator Ar
| 23***10 | Generator Ar | 1 |
| 33***16 | Generator Group | 1 |
338-2060 Generator Ar
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
| 24***03 | Exciter | 1 |
235-1204 Generator Ar
| 23***04 | Generator Ar | 1 |
| 33***04 | Generator Group | 1 |
338-2092 Generator Ar
| 23***91 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
266-7104 Generator Ar
| 26***04 | Generator Ar | 1 |
| 33***01 | Generator Group | 1 |
323-6297 Generator Ar
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
| 24***03 | Exciter | 1 |
356-0124 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2023 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
296-5200 Generator Ar
| 29***00 | Generator Ar | 1 |
| 33***13 | Generator Group | 1 |
235-1208 Generator Ar
| 23***08 | Generator Ar | 1 |
| 33***12 | Generator Group | 1 |
247-1711 Generator Ar
| 24***11 | Generator Ar | 1 |
| 33***69 | Generator Group | 1 |
235-1203 Generator Ar
| 23***03 | Generator Ar | 1 |
| 33***01 | Generator Group | 1 |
338-2029 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
266-7109 Generator Ar
| 26***09 | Generator Ar | 1 |
| 33***11 | Generator Group | 1 |
338-2108 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
247-1713 Generator Ar
| 24***13 | Generator Ar | 1 |
| 33***73 | Generator Group | 1 |
247-6126 Generator Ar
| 24***26 | Generator Ar | 1 |
| 33***91 | Generator Group | 1 |
247-6119 Generator Ar
| 24***19 | Generator Ar | 1 |
| 33***81 | Generator Group | 1 |
338-2058 Generator Ar
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
| 24***03 | Exciter | 1 |
247-6128 Generator Ar
| 24***28 | Generator Ar | 1 |
| 33***95 | Generator Group | 1 |
242-4994 Generator Ar
| 24***94 | Generator Ar | 1 |
| 33***55 | Generator Group | 1 |
338-2033 Generator Ar
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
| 24***03 | Exciter | 1 |
235-1209 Generator Ar
| 23***09 | Generator Ar | 1 |
| 33***14 | Generator Group | 1 |
338-2088 Generator Ar
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
| 24***03 | Exciter | 1 |
322-8927 Generator Ar
| 32***27 | Generator Ar | 1 |
| 33***30 | Generator Group | 1 |
247-6129 Generator Ar
| 24***29 | Generator Ar | 1 |
| 33***97 | Generator Group | 1 |
338-2110 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
266-7106 Generator Ar
| 26***06 | Generator Ar | 1 |
| 33***05 | Generator Group | 1 |
338-2021 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2027 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 23***90 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***77 | Eye-Lifting | 1 |
361-1449 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
235-1206 Generator Ar
| 23***06 | Generator Ar | 1 |
| 33***08 | Generator Group | 1 |
235-1211 Generator Ar
| 23***11 | Generator Ar | 1 |
| 33***18 | Generator Group | 1 |
338-2005 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2094 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2056 Generator Ar
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
| 24***03 | Exciter | 1 |
247-1708 Generator Ar
| 24***08 | Generator Ar | 1 |
| 33***63 | Generator Group | 1 |
338-2000 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2015 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
235-1217 Generator Ar
| 23***17 | Generator Ar | 1 |
| 33***30 | Generator Group | 1 |
338-2013 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
356-0126 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-1994 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2031 Generator Ar
| 24***80 | Screw | 2 |
| 24***03 | Exciter | 1 |
| 24***30 | Panel-Access | 1 |
338-2090 Generator Ar
| 23***91 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
247-6125 Generator Ar
| 24***25 | Generator Ar | 1 |
| 33***89 | Generator Group | 1 |
235-1214 Generator Ar
| 23***14 | Generator Ar | 1 |
| 33***24 | Generator Group | 1 |
338-2100 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 23***90 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***77 | Eye-Lifting | 1 |
235-1213 Generator Ar
| 23***13 | Generator Ar | 1 |
| 33***22 | Generator Group | 1 |
338-2017 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2102 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 23***90 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***77 | Eye-Lifting | 1 |
338-2106 Generator Ar
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
247-1707 Generator Ar
| 24***07 | Generator Ar | 1 |
| 33***61 | Generator Group | 1 |
247-6127 Generator Ar
| 24***27 | Generator Ar | 1 |
| 33***93 | Generator Group | 1 |
338-2068 Generator Ar
| 23***91 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 24***80 | Screw | 2 |
| 24***90 | Bolt; (M6x16x8.8-mm) | 34 |
324-7725 Generator Gp
| 23***90 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 32***25 | Generator Group | 1 |
338-2057 Generator Gp
| 11***45 | Plug As-Connector; (40-Pin) | 1 |
| 13***51 | Control Group-Emcp Electronic; -Generator Set Control | 1 |
| 13***58 | Cable-Electrical; (16-Ga)(3089-cm) | 0 |
338-2065 Generator Gp
| 11***87 | Film-Control Panel; (Generator Set Control +) | 1 |
| 13***26 | Film-Control Panel; (Custom Alarm Module Idents) | 1 |
| 14***64 | Control Group-Emcp Electronic; -Generator Set Control + P | 1 |
324-7683 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2067 Generator Gp
| 16***80 | Control Group-Monitor; (Caterpillar Monitoring System) | 1 |
| 22***05 | Film; (Control Panel)(Engine Monitoring) | 1 |
| 33***67 | Generator Group | 1 |
338-2071 Generator Gp
| 23***75 | Control Group-Engine Monitoring; -Discrete Input/Output | 1 |
| 26***14 | Harness As-Control; -Discrete Input/Output | 1 |
| 33***71 | Generator Group | 1 |
338-2111 Generator Gp
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 6 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 6 |
| 25***11 | Cover | 1 |
324-7679 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2095 Generator Gp
| 14***89 | Block-Terminal | 2 |
| 23***24 | Terminal; (End) | 1 |
| 23***53 | Terminal; (Spring) | 3 |
338-2018 Generator Gp
| 13***29 | Film-Control Panel; (Alarm Module) | 1 |
| 13***49 | Control Group-Alarm Module | 1 |
| 17***90 | Wire; (18-Ga, White)(42.5-cm Ea) | 0 |
324-7702 Generator Gp
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
| 24***03 | Exciter | 1 |
324-7714 Generator Gp
| 09***92 | Washer, Tooth | 8 |
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
324-7728 Generator Gp
| 1S***93 | Strap; (Cable) (0.62in Dia) | 4 |
| 25***02 | Regulator Group-Voltage; -Generator | 1 |
| 25***52 | Bracket As | 1 |
338-2101 Generator Gp
| 23***75 | Cover | 1 |
| 33***01 | Generator Group | 1 |
| 6V***98 | Bolt; (M5x0.8x16-mm) | 12 |
324-7690 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2022 Generator Gp
| 24***14 | Horn | 1 |
| 33***22 | Generator Group | 1 |
324-7722 Generator Gp
| 24***39 | Heater As-Space | 1 |
| 32***22 | Generator Group | 1 |
338-2089 Generator Gp
| 10***52 | Screw-Pan Head; (8-32x0.375-In) | 8 |
| 16***77 | Screw-Button Head; (M6x1x28-mm) | 6 |
| 26***57 | Film-Certification; (Emcp 3) | 1 |
324-7688 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2020 Generator Gp
| 13***24 | Module Group-Alarm | 1 |
| 13***28 | Film-Control Panel; (Custom Alarm Module) | 1 |
| 23***23 | Harness As-Panel; (Alarm Module) | 1 |
338-2109 Generator Gp
| 24***70 | Grommet; (European Sourced) | 2 |
| 33***09 | Generator Group | 1 |
| 9R***20 | Plug; (Blanking) | 2 |
324-7682 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
324-7715 Generator Gp
| 09***92 | Washer, Tooth | 8 |
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
324-7686 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
324-7706 Generator Gp
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
| 24***03 | Exciter | 1 |
324-7691 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
324-7680 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
324-7710 Generator Gp
| 09***92 | Washer, Tooth | 8 |
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
323-6296 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2075 Generator Gp
| 16***77 | Screw-Button Head; (M6x1x28-mm) | 4 |
| 23***58 | Module Group-Alarm | 1 |
| 24***03 | Film-Information; (Emcp 3 Annunciator) | 1 |
338-2059 Generator Gp
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 10***25 | Control Group-Emcp Electronic | 1 |
| 33***59 | Generator Group | 1 |
324-7687 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2030 Generator Gp
| 10***00 | Control Group-Electronic; (Relay Module) | 1 |
| 13***16 | Film-Information; (Control Panel)(Emcp Ii - Graphic/Text) | 1 |
| 1S***74 | Seal-O-Ring (164.69mm Id) | 1 |
338-1991 Generator Gp
| 1S***93 | Strap; (Cable) (0.62in Dia) | 6 |
| 25***50 | Regulator Group-Voltage; -Generator | 1 |
| 33***91 | Generator Group | 1 |
338-2010 Generator Gp
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 6 |
| 26***69 | Bracket As | 1 |
| 33***10 | Generator Group | 1 |
338-2085 Generator Gp
| 23***59 | Module Group-Alarm; -Annunciator | 1 |
| 33***85 | Generator Group | 1 |
324-7694 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2032 Generator Gp
| 13***16 | Film-Information; (Control Panel)(Emcp Ii - Graphic/Text) | 1 |
| 13***50 | Control Group-Emcp Electronic; -Generator Set Control | 1 |
| 33***32 | Generator Group | 1 |
338-2053 Generator Gp
| 10***27 | Screw-Pan Head; (10-24x0.25-In) | 6 |
| 33***53 | Generator Group | 1 |
| 5N***59 | Jumper-Strip | 1 |
338-2107 Generator Gp
| 28***66 | Cover As | 1 |
| 33***07 | Generator Group | 1 |
| 6V***98 | Bolt; (M5x0.8x16-mm) | 4 |
338-2061 Generator Gp
| 09***26 | Lockwasher-Tooth; (M4 Id) | 1 |
| 11***45 | Plug As-Connector; (40-Pin) | 1 |
| 13***58 | Cable-Electrical; (16-Ga)(3089-cm) | 0 |
324-7692 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-1995 Generator Gp
| 24***58 | Film-Warning; (Shock, Electrocution Hazard)(Shock, Electrocution Hazard) | 1 |
| 33***95 | Generator Group | 1 |
324-7700 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
322-8926 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
324-7712 Generator Gp
| 09***92 | Washer, Tooth | 8 |
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
324-7727 Generator Gp
| 03***75 | Washer; (0.266x1.25x0.06-In Thk) | 6 |
| 24***64 | Spacer; (8.5x12.7x94.3-mm Thk) | 3 |
| 32***27 | Generator Group | 1 |
324-7699 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
324-7681 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-1999 Generator Gp
| 14***89 | Block-Terminal | 2 |
| 16***02 | Holder-Fuse | 3 |
| 1S***93 | Strap; (Cable) (0.62in Dia) | 2 |
338-2026 Generator Gp
| 10***27 | Screw-Pan Head; (10-24x0.25-In) | 8 |
| 15***65 | Kit-Connecting Plug; (8-Pin)(Electronic Control Channel) | 1 |
| 18***36 | Socket-Connector; (16-Ga To 18-Ga) | 8 |
324-7711 Generator Gp
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
| 24***03 | Exciter | 1 |
338-2055 Generator Gp
| 13***51 | Control Group-Emcp Electronic; -Generator Set Control | 1 |
| 23***77 | Harness As; (Emc P2 Door) | 1 |
| 33***55 | Generator Group | 1 |
338-2069 Generator Gp
| 23***45 | Control Group-Engine Monitoring; (Resistive Temperature Device) | 1 |
| 26***16 | Harness As-Wiring; -Resistive Temperature Device | 1 |
| 30***37 | Kit-Marker | 1 |
247-1824 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2091 Generator Gp
| 10***52 | Screw-Pan Head; (8-32x0.375-In) | 8 |
| 16***77 | Screw-Button Head; (M6x1x28-mm) | 6 |
| 26***57 | Film-Certification; (Emcp 3) | 1 |
324-7678 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2113 Generator Gp
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 8 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 8 |
| 26***00 | Cover-Top | 1 |
324-7705 Generator Gp
| 24***80 | Screw | 2 |
| 24***03 | Exciter | 1 |
| 24***30 | Panel-Access | 1 |
324-7726 Generator Gp
| 23***91 | Kit-Exciter; (Permanent Magnet)(Generator) | 1 |
| 32***26 | Generator Group | 1 |
324-7708 Generator Gp
| 09***92 | Washer, Tooth | 8 |
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
324-7677 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
324-7689 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
324-7703 Generator Gp
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
| 24***03 | Exciter | 1 |
338-2097 Generator Gp
| 28***51 | Harness As-Wiring; (Speed Adjust) | 1 |
| 30***13 | Block-Terminal; (800-Volt, 24-Ampere) | 3 |
| 30***16 | Cover-End | 1 |
324-7704 Generator Gp
| 09***92 | Washer, Tooth | 8 |
| 24***80 | Screw | 2 |
| 24***03 | Exciter | 1 |
338-2087 Generator Gp
| 10***52 | Screw-Pan Head; (8-32x0.375-In) | 8 |
| 16***77 | Screw-Button Head; (M6x1x28-mm) | 6 |
| 26***57 | Film-Certification; (Emcp 3) | 1 |
338-2006 Generator Gp
| 24***87 | Mounting Group-Voltage Regulator | 1 |
| 31***55 | Regulator As-Voltage; -Generator | 1 |
| 33***06 | Generator Group | 1 |
338-2130 Generator Gp
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 8 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 8 |
| 24***82 | Plate As | 1 |
324-7723 Generator Gp
| 24***38 | Heater As-Space | 1 |
| 32***23 | Generator Group | 1 |
338-1997 Generator Gp
| 14***89 | Block-Terminal | 2 |
| 16***02 | Holder-Fuse | 3 |
| 1S***93 | Strap; (Cable) (0.62in Dia) | 37 |
338-2008 Generator Gp
| 33***08 | Generator Group | 1 |
| 4P***73 | Disc | 2 |
| 5N***32 | Bolt-Special | 20 |
247-1829 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2093 Generator Gp
| 33***93 | Generator Group | 1 |
| 4W***72 | Knob; (Engine Speed Control) | 1 |
| 7C***50 | Seal; (Rotating Shaft) | 1 |
338-2004 Generator Gp
| 14***89 | Block-Terminal | 4 |
| 16***02 | Holder-Fuse | 3 |
| 1S***93 | Strap; (Cable) (0.62in Dia) | 35 |
338-2012 Generator Gp
| 17***90 | Wire; (18-Ga, White)(42.5-cm Ea) | 0 |
| 2W***80 | Boot-Switch | 2 |
| 33***12 | Generator Group | 1 |
324-7709 Generator Gp
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
| 24***03 | Exciter | 1 |
338-1993 Generator Gp
| 21***84 | Film-Warning; (Shock, Electrocution Hazard)(Voltage Regulator) | 1 |
| 33***93 | Generator Group | 1 |
324-7713 Generator Gp
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
| 24***03 | Exciter | 1 |
338-2028 Generator Gp
| 13***15 | Film-Control Panel; (Generator Set Control +)(Emcpii+) | 1 |
| 13***50 | Control Group-Electronic; (Relay Module)(Generator Set Control +) | 1 |
| 15***98 | Film-Control Panel; (Generator Set Control +)(Eui) | 1 |
338-2001 Generator Gp
| 14***89 | Block-Terminal | 4 |
| 16***02 | Holder-Fuse | 3 |
| 1S***93 | Strap; (Cable) (0.62in Dia) | 35 |
338-2099 Generator Gp
| 21***82 | Cover | 1 |
| 33***99 | Generator Group | 1 |
| 8T***89 | Locknut; (M10x1.15-Thd) | 1 |
338-2073 Generator Gp
| 23***44 | Control Group-Engine Monitoring; -Thermocouple | 1 |
| 26***21 | Harness As-Monitor; -Thermocouple | 1 |
| 33***73 | Generator Group | 1 |
324-7685 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2081 Generator Gp
| 09***26 | Lockwasher-Tooth; (M4 Id) | 1 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 6 |
| 23***42 | Screw; (M4x0.7x7-mm) | 1 |
324-7698 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2083 Generator Gp
| 09***26 | Lockwasher-Tooth; (M4 Id) | 1 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 6 |
| 23***42 | Screw; (M4x0.7x7-mm) | 1 |
324-7724 Generator Gp
| 23***92 | Panel As | 1 |
| 32***24 | Generator Group | 1 |
338-2103 Generator Gp
| 23***24 | Cover | 1 |
| 33***03 | Generator Group | 1 |
| 6V***98 | Bolt; (M5x0.8x16-mm) | 12 |
338-2024 Generator Gp
| 10***22 | Housing As; (Transformer Box-Emcp Ii) | 1 |
| 10***03 | Channel As; (Transformer-Emcp Ii) | 1 |
| 10***16 | Seal-Interface | 1 |
324-7684 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
324-7701 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
361-1448 Generator Gp
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 4 |
| 26***41 | Cover; (Canopy) | 1 |
324-7693 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
296-5201 Generator Gp
| 16***46 | Bolt; (M12x1.75x18-mm) | 6 |
| 24***77 | Eye-Lifting | 1 |
| 24***94 | Cover; (Outer Bearing) | 1 |
338-2014 Generator Gp
| 33***14 | Generator Group | 1 |
| 3J***54 | Packing,Preformed Part Of Kit P/N 5r***27 | 1 |
| 9S***02 | Plug-O-Ring; (Straight Thread O-Ring) | 1 |
338-2034 Generator Gp
| 13***26 | Film-Control Panel; (Custom Alarm Module Idents) | 1 |
| 13***15 | Film-Control Panel; (Generator Set Control +)(Emcpii+) | 1 |
| 1S***74 | Seal-O-Ring (164.69mm Id) | 1 |
324-7707 Generator Gp
| 23***51 | Bolt-Flange Head; (M6x1x16-mm) | 34 |
| 24***80 | Screw | 2 |
| 24***03 | Exciter | 1 |
338-2016 Generator Gp
| 33***16 | Generator Group | 1 |
| 3J***54 | Packing,Preformed Part Of Kit P/N 5r***27 | 1 |
| 9S***02 | Plug-O-Ring; (Straight Thread O-Ring) | 1 |
338-2105 Generator Gp
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 6 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 6 |
| 26***64 | Cover | 1 |
338-2063 Generator Gp
| 11***70 | Control Group-Emcp Electronic; -Generator Set Control + | 1 |
| 11***87 | Film-Control Panel; (Generator Set Control +) | 1 |
| 13***26 | Film-Control Panel; (Custom Alarm Module Idents) | 1 |
239-9949 Heater Gp-Space -Generator
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 14***87 | Plate-Cover | 1 |
| 23***49 | Heater Group-Space; -Generator | 1 |
239-9399 Heater Gp-Space -Generator
| 23***89 | Plate; (Cable-Inlet) | 1 |
| 23***99 | Heater Group-Space; -Generator | 1 |
| 8T***28 | Washer; (Hard) (5.5x10x1mm Thk) | 10 |
241-6058 Insulation Gp-Weather
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 23***94 | Plate-Cover | 1 |
| 24***58 | Insulation Group-Weather | 1 |
239-9373 Mounting Gp-Generator
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 16 |
| 23***28 | Cover | 2 |
| 23***73 | Mounting Group-Generator | 1 |
239-9387 Mounting Gp-Generator
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 4 |
| 23***65 | Cover; (Top) | 1 |
| 23***87 | Mounting Group-Generator | 1 |
242-3487 Mounting Gp-Voltage Regulator
| 23***63 | Cover; (Top) | 1 |
| 24***87 | Mounting Group-Voltage Regulator | 1 |
| 8T***89 | Bolt (20mm Long) 0 Degrees); (L=20mm) {For 5br, 6cr} | 8 |
259-0983 Mounting Gp-Voltage Regulator
| 09***26 | Lockwasher-Tooth; (M4 Id) | 4 |
| 12***95 | Screw-Pan Head; (M2.5x0.45x12-mm) | 4 |
| 16***12 | Washer-Hard; (2.7x6x0.5-mm Thk) | 8 |
259-0982 Mounting Gp-Voltage Regulator
| 19***22 | Screw-Flat Head | 8 |
| 25***83 | Door Group; -Control Panel | 1 |
| 25***82 | Mounting Group-Voltage Regulator | 1 |
235-5725 Regulator As-Voltage -Digital
| 09***26 | Lockwasher-Tooth; (M4 Id) | 4 |
| 12***95 | Screw-Pan Head; (M2.5x0.45x12-mm) | 4 |
| 15***22 | Mount | 2 |
314-7755 Regulator As-Voltage -Digital
| 09***26 | Lockwasher-Tooth; (M4 Id) | 2 |
| 12***95 | Screw-Pan Head; (M2.5x0.45x12-mm) | 4 |
| 16***12 | Washer-Hard; (2.7x6x0.5-mm Thk) | 8 |
252-2050 Regulator Gp-Voltage
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 4 |
| 23***44 | Lock As | 2 |
| 25***50 | Regulator Group-Voltage; -Generator | 1 |
251-9202 Regulator Gp-Voltage
| 10***72 | Seal; (Control) | 1 |
| 24***13 | Gasket; (Control Panel) | 1 |
| 25***02 | Regulator Group-Voltage; -Generator | 1 |
336-8902 Regulator Gp-Voltage
| 26***36 | Bracket | 1 |
| 26***37 | Cover As-Access; (Vandalism Guard) | 1 |
| 33***02 | Regulator Group-Voltage | 1 |
295-4049 Regulator Gp-Voltage
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 4 |
| 23***44 | Lock As | 2 |
| 26***38 | Door As-Access | 1 |
320-3708 Rotor As
| 26***09 | Door Group-Access; -Vandalism Guard | 1 |
| 32***08 | Rotor As | 1 |
Lubrication System
299-2204 Drain Gp-Oil -Engine
| 03***53 | Seal-O-Ring; (08.92mm Id) | 1 |
| 12***81 | Seal-Integral; (Air Compressor Mounting) | 1 |
| 18***09 | Plug As; (High Temperature) | 1 |
302-7353 Drain Gp-Oil -Engine
| 0S***88 | Bolt,Machine; Hose Assembly Mounting,Hose Assembly To Transmission,And To Torque Converter | 7 |
| 0S***19 | Bolt,Machine Gear Retaining Part Of Kit P/N 1w***46 | 1 |
| 17***59 | Base Group-Oil Filter; (Engine) | 1 |
4n-2481 Fastener Gp-Oil Pump Mounting -Engine
| 16***22 | Clip-Loop | 1 |
| 20***28 | Hose As; (Fumes Disposal) | 1 |
| 4N***81 | Fastener Group-Oil Pump Mounting; Oil Pump Mounting Fastener Group | 1 |
245-2066 Filler Gp-Engine Oil
| 24***66 | Filler Group-Engine Oil | 1 |
| 5P***57 | Hose 7.6 cm(3 In.); 6.98cm(2.75in) | 0 |
| 9M***64 | Clamp; (Hose) | 1 |
6i-3944 Filler Gp-Engine Oil
| 0L***70 | Bolt (2-1/4") Filler Tube Assembly To Transfer Drive Case | 1 |
| 18***49 | Hose; (Fumes Disposal) | 2 |
| 21***66 | Tube As; (Fumes) | 1 |
241-4187 Filter Gp-Engine Oil
| 24***87 | Filter Group-Engine Oil | 1 |
| 28***53 | Hose; (112-cm), Flexible Hose | 0 |
| 2A***39 | Bolt,Machine Tube To Torque Converter And Tube To Oil Cooler | 1 |
299-2388 Fumes Disposal Gp
| 03***88 | Connector-Tube Assembly To Main Relief | 1 |
| 0S***90 | Bolt; (3/8-16x2in)(Clip Thru Spacer To Bracket As) | 1 |
| 24***34 | Tube As | 1 |
302-7355 Fumes Disposal Gp
| 09***81 | Spacer; (10.5x20x10.0mm Thk) | 1 |
| 0L***43 | Bolt 63.5 mm (3/8" X 2 1/2" -Cover Assembly To Fender | 2 |
| 0S***71 | Screw,Cap,Hexagon; Tube Assembly To Turbocharger And Elbow Mounting | 1 |
212-2765 Fumes Disposal Gp
| 0S***09 | Bolt (3/4") Filler Tube Assembly To Transfer Drive Case | 1 |
| 11***68 | Seal-O-Ring; (15.54mm Id) | 1 |
| 16***25 | Tube As | 1 |
251-1514 Fumes Disposal Gp
| 0S***09 | Bolt (3/4") Filler Tube Assembly To Transfer Drive Case | 1 |
| 11***68 | Seal-O-Ring; (15.54mm Id) | 1 |
| 16***25 | Tube As | 1 |
159-9362 Fumes Disposal Gp
| 15***62 | Fumes Disposal Group | 1 |
| 2A***39 | Bolt,Machine Tube To Torque Converter And Tube To Oil Cooler | 1 |
| 5P***57 | Hose 7.6 cm(3 In.); 6.98cm(2.75in) | 0 |
319-5267 Gauge Gp-Oil Level (Dipstick) -Engine
| 12***56 | Cover As-Pump | 1 |
| 1M***44 | Bolt; (3/8-16x2-1/4 In) | 2 |
| 1W***38 | Shaft As-Pump Drive; (8-Teeth) | 1 |
187-0672 Guide Gp-Oil Level Gauge -Engine
| 12***78 | Locknut; (M6x1-Thd) | 4 |
| 14***70 | Pump Group-Sump | 1 |
| 14***23 | Elbow | 1 |
245-2065 Lines Gp-Engine Oil
| 16***26 | Valve-Ball; (Shutoff, Oil) | 1 |
| 24***65 | Lines Group-Engine Oil, Hose,6000.00 mm; Control Valve To Lowering Braking Valve, Lower Block | 1 |
| 3B***41 | Nipple-- To Quick Release Valve; -- To Quick Release Valve | 1 |
210-0783 Lines Gp-Turbocharger Oil
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 10 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 10 |
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 4 |
161-4113 Pump Gp-Engine Oil
| 00***63 | Elbow, 90 Deg Street, 3/4in. N.P.T. | 1 |
| 11***36 | Valve As-Shutoff; (Jacket Water Heater) | 1 |
| 16***13 | Pump Group-Engine Oil | 1 |
250-9646 Pump Gp-Sump
| 00***63 | Elbow, 90 Deg Street, 3/4in. N.P.T. | 1 |
| 11***36 | Valve As-Shutoff; (Jacket Water Heater) | 1 |
| 23***01 | Union; (3/4-14 Npsf Thd) | 1 |
308-3873 Valve Gp-Fluid Control
| 23***01 | Union; (3/4-14 Npsf Thd) | 1 |
| 2P***86 | Locknut-Bulkhead; (1-5/16-12-Thd) | 1 |
| 30***73 | Valve Group-Fluid Control | 1 |
Operator Station
262-9625 Alarm Gp
| 26***25 | Alarm Group | 1 |
| 8T***89 | Bolt (20mm Long) 0 Degrees); (L=20mm) {For 5br, 6cr} | 8 |
| 8T***24 | Washer-To Assemble Valve As And Plates | 8 |
260-0568 Bracket Gp-Mounting
| 24***47 | Filter-Electronic; (Radio Frequency Interference) | 1 |
| 26***68 | Bracket Group-Mounting | 1 |
| 2L***71 | Terminal; (10-Ga To 12-Ga, 1/2-In Screw)(1/2 In Screw) | 5 |
130-3332 Control Gp-Alarm Module
| 13***32 | Control Group-Alarm Module | 1 |
| 13***58 | Film; (Identification) (On Radiator Filler Cap) (On Near Of Radiator Filler Cap) | 1 |
| 14***43 | Film-Information; (Diesel Fuel Fill)(Info Diesel Fuel Fill) | 1 |
130-3333 Module Gp-Alarm
| 13***33 | Control Group-Alarm Module; (Custom) | 1 |
130-3349 Control Gp-Alarm Module
| 13***49 | Control Group-Alarm Module | 1 |
236-5341 Control Gp-Alarm Module
| 23***41 | Control Group-Alarm Module | 1 |
247-7014 Control Gp-Emcp Electronic
| 14***89 | Block-Terminal | 2 |
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 4 |
| 20***12 | Contact | 1 |
235-8078 Control Gp-Emcp Electronic
| 19***22 | Screw-Flat Head | 8 |
| 23***78 | Control Group-Emcp Electronic | 1 |
| 27***84 | Hinge As | 2 |
101-0225 Control Gp-Emcp Electronic
| 10***25 | Control Group-Emcp Electronic | 1 |
| 24***48 | Filter-Electronic; (480-Volt)(Radio Frequency Interference) | 1 |
| 2L***71 | Terminal; (10-Ga To 12-Ga, 1/2-In Screw)(1/2 In Screw) | 5 |
118-2070 Control Gp-Emcp Electronic
| 11***70 | Control Group-Emcp Electronic; -Generator Set Control + | 1 |
| 13***24 | Module Group-Alarm | 1 |
| 13***26 | Film-Control Panel; (Custom Alarm Module Idents) | 1 |
235-7981 Control Gp-Emcp Electronic
| 23***81 | Control Group-Emcp Electronic | 1 |
| 5P***37 | Seal 1.667 M(65.25 In.) | 0 |
| 7F***98 | Lockwasher | 5 |
133-6350 Control Gp-Emcp Electronic
| 13***26 | Film-Control Panel; (Custom Alarm Module Idents) | 1 |
| 13***27 | Film-Control Panel; (Custom Alarm Module) | 1 |
| 13***32 | Control Group-Alarm Module | 1 |
133-6351 Control Gp-Emcp Electronic
| 10***64 | Cover; (Synchronizing Lights Module) | 1 |
| 13***51 | Control Group-Emcp Electronic; -Generator Set Control | 1 |
| 17***81 | Nut; (1/4-20-Thd) | 2 |
143-5464 Control Gp-Emcp Electronic
| 14***64 | Control Group-Emcp Electronic; -Generator Set Control + P | 1 |
| 17***65 | Screw; (8-16x0.63-In) | 6 |
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 14 |
118-0175 Control Gp-Emcp Electronic
| 11***75 | Control Group-Emcp Electronic | 2 |
| 11***70 | Control Group-Emcp Electronic; -Generator Set Control + | 1 |
| 33***38 | Film-Control Panel; (Generator Set Control +) | 1 |
247-7015 Control Gp-Emcp Electronic
| 14***89 | Block-Terminal | 2 |
| 20***98 | Insert-Threaded; (M5x0.8-Thd)(Threated M6) | 4 |
| 20***09 | Button-Stop | 1 |
236-5307 Control Gp-Emcp Electronic
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 8 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 8 |
| 16***07 | Grommet | 1 |
169-4701 Control Gp-Emcp Electronic
| 16***01 | Control Group-Emcp Electronic | 1 |
| 19***22 | Screw-Flat Head | 8 |
| 25***00 | Panel Group-Control; -Annunciator | 1 |
261-8427 Control Gp-Engine Monitoring -Thermocouple Module
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 8 |
| 11***48 | Socket-Relay | 2 |
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 2 |
154-5505 Control Gp-Engine Monitoring
| 15***05 | Control Group-Engine Monitoring | 1 |
| 23***33 | Harness As-Wiring; (Engine Speed) | 1 |
| 8C***60 | Washer; (4.6x7.9x0.8-mm Thk) | 2 |
262-4281 Control Gp-Engine Monitoring -Thermocouple Module
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 8 |
| 10***66 | Bezel | 1 |
| 10***03 | Kit; (Receptacle) (3-Pin) (Includes Receptacle As & Wedge) | 1 |
261-8428 Control Gp-Engine Monitoring -Discrete I/O Module
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 8 |
| 10***03 | Kit; (Receptacle) (3-Pin) (Includes Receptacle As & Wedge) | 1 |
| 11***48 | Socket-Relay | 2 |
300-7645 Control Gp-Generator Set -Emcp 3.1
| 09***26 | Lockwasher-Tooth; (M4 Id) | 4 |
| 12***95 | Screw-Pan Head; (M2.5x0.45x12-mm) | 4 |
| 15***22 | Mount | 2 |
300-7647 Control Gp-Generator Set -Emcp 3.3
| 14***78 | Relay; (24-Volt)(European Sourced) | 1 |
| 14***79 | Socket-Relay; (European Sourced) | 1 |
| 21***40 | Spring; (Relay)(Us Sourced) | 1 |
261-5133 Control Gp-Generator Set -Emcp 3.3
| 14***82 | Switch As-Push Button; (Close Breaker) | 1 |
| 14***84 | Base-Lamp | 2 |
| 14***85 | Block-Contact | 2 |
261-5132 Control Gp-Generator Set -Emcp 3.2
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 4 |
| 13***58 | Cable-Electrical; (16-Ga)(3089-cm) | 0 |
| 15***74 | Kit-Connecting Plug; (6-Pin)(Cat Electronic Display Harness) | 1 |
267-1226 Control Gp-Generator Set
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 4 |
| 13***58 | Cable-Electrical; (16-Ga)(3089-cm) | 0 |
| 15***63 | Wedge-Plug Lock; (6-Pin) | 1 |
300-7646 Control Gp-Generator Set -Emcp 3.2
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 1 |
| 14***78 | Relay; (24-Volt)(European Sourced) | 1 |
| 14***79 | Socket-Relay; (European Sourced) | 1 |
245-3609 Control Gp-Speed -Adjust
| 16***02 | Holder-Fuse | 1 |
| 16***35 | Contactor | 1 |
| 19***58 | Fuse; (6-Ampere)(Us Sourced) | 1 |
284-1428 Control Gp-Speed
| 16***08 | Block-Fuse | 2 |
| 19***16 | Plate; (End) | 1 |
| 20***01 | Contactor | 1 |
293-2811 Cover Gp-Access -Control Panel
| 29***11 | Cover Group-Access; -Control Panel | 1 |
| 7F***98 | Lockwasher | 4 |
| 8T***21 | Washer-Hard; (11x21x2.5-mm Thk)(M10x1.50x30mm) | 8 |
269-8465 Cover Gp-Access -Control Panel
| 06***44 | Grommet | 4 |
| 16***07 | Grommet | 1 |
| 18***48 | Insert-Threaded; (M8x1.25-Thd) | 19 |
243-5599 Cover Gp-Access
| 14***99 | Lockwasher | 4 |
| 14***99 | Insulator | 2 |
| 15***92 | Bar | 1 |
238-0008 Cover Gp-Access -Generator
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 10***06 | Receptacle Kit; (Includes Wedge And Receptacle Assem.) | 1 |
| 10***13 | Receptacle As-Connector; (70-Pin) | 2 |
238-0009 Cover Gp-Access -Generator
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 16 |
| 10***06 | Receptacle Kit; (Includes Wedge And Receptacle Assem.) | 1 |
213-0144 Cover Gp-Access -Protective Lift
| 09***42 | Screw; (Machine) (M6x1.0x16mm) | 4 |
| 10***06 | Receptacle Kit; (Includes Wedge And Receptacle Assem.) | 1 |
| 10***13 | Receptacle As-Connector; (70-Pin) | 2 |
261-7645 Cover Gp-Control Panel -Top
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 5 |
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 3 |
| 14***78 | Relay; (24-Volt)(European Sourced) | 1 |
266-1422 Cover Gp-Control Panel
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 3 |
| 14***78 | Relay; (24-Volt)(European Sourced) | 1 |
| 14***79 | Socket-Relay; (European Sourced) | 1 |
266-2701 Cover Gp-Control Panel
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 5 |
| 14***71 | Fuse; (2-Ampere)(European Sourced) | 3 |
| 14***78 | Relay; (24-Volt)(European Sourced) | 1 |
261-0001 Cover Gp-Control Panel -Top
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 4 |
| 25***92 | Panel Group-Electronic | 1 |
| 26***88 | Bolt; (M6x1x30-mm) | 4 |
245-3638 Cover Gp-Control Panel
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 6 |
| 24***38 | Cover Group-Control Panel | 1 |
| 25***79 | Panel Group-Electronic | 1 |
258-6810 Cover Gp-Control Panel
| 09***27 | Lockwasher-Tooth; (0.6mm Thk) | 5 |
| 14***60 | Rail; (200-cm) | 0 |
| 19***37 | Screw; (8-32x1/2-In) | 11 |
235-7998 Cover Gp-Instrument Panel
| 03***49 | Nut-Self Lock; (No.10.Unc) | 2 |
| 10***72 | Seal; (Control) | 1 |
| 10***07 | Switch-Operator; (Secondary Stop Push Button) | 1 |
236-4433 Cover Gp-Instrument Panel
| 13***25 | Module Group-Alarm; (Custom) | 1 |
| 13***33 | Control Group-Alarm Module; (Custom) | 1 |
| 23***33 | Cover Group-Instrument Panel | 1 |
236-4395 Cover Gp-Instrument Panel
| 13***25 | Module Group-Alarm; (Custom) | 1 |
| 23***95 | Cover Group-Instrument Panel | 1 |
| 4P***60 | Washer; (Retaining Ring) | 6 |
236-4840 Cover Gp-Instrument Panel
| 13***50 | Module Group-Alarm | 1 |
| 23***40 | Cover Group-Instrument Panel | 1 |
| 4P***60 | Washer; (Retaining Ring) | 6 |
235-7992 Cover Gp-Instrument Panel
| 23***92 | Cover Group-Instrument Panel | 1 |
| 5P***37 | Seal 1.667 M(65.25 In.) | 0 |
| 7F***98 | Lockwasher | 6 |
258-6783 Door Gp -Control Panel
| 12***70 | Potentiometer; (10,000-Ohm)(Voltage Adjustment) | 1 |
| 25***83 | Door Group; -Control Panel | 1 |
| 4W***72 | Knob; (Engine Speed Control) | 1 |
261-7127 Door Gp -Dustproof
| 10***72 | Seal; (Control) | 1 |
| 15***14 | Gasket | 1 |
| 24***29 | Gasket | 1 |
258-6782 Door Gp -Control Panel
| 12***58 | Potentiometer; (1000-Ohm)(Speed Adjust) | 1 |
| 25***82 | Door Group; -Control Panel | 1 |
| 4W***72 | Knob; (Engine Speed Control) | 1 |
266-1419 Door Gp-Access -Control Panel
| 26***80 | Connector-Electrical | 1 |
| 26***19 | Door Group-Access; -Control Panel | 1 |
| 29***08 | Reducer | 1 |
269-8609 Door Gp-Access -Vandalism Guard
| 22***69 | Plate-Identification; (C18 Acert) | 1 |
| 23***00 | Plate-Identification; (Blank) | 1 |
| 23***01 | Plate-Identification; (Cat) | 1 |
258-6787 Door Gp-Access -Control Panel
| 24***70 | Grommet; (European Sourced) | 6 |
| 25***87 | Door Group-Access; -Control Panel | 1 |
266-1417 Door Gp-Access -Control Panel
| 19***39 | Seal; (Each Includes 44-Dm) | 0 |
| 26***17 | Door Group-Access; -Control Panel | 1 |
279-3444 Door Gp-Access -Vandalism Guard
| 27***44 | Door Group-Access; -Vandalism Guard | 1 |
| 3B***15 | Bolt Guard Assembly To Accessory Drive Housing | 4 |
| 5N***36 | Cover | 1 |
258-6786 Door Gp-Access -Control Panel
| 24***91 | Seal; (380cm) | 0 |
| 25***86 | Door Group-Access; -Control Panel | 1 |
253-3023 Fastener Gp-Instrument Panel
| 12***61 | Film-Information; (Laminate) | 1 |
| 13***58 | Film; (Identification) (On Radiator Filler Cap) (On Near Of Radiator Filler Cap) | 3 |
| 14***43 | Film-Information; (Diesel Fuel Fill)(Info Diesel Fuel Fill) | 1 |
239-9401 Filter Gp-Electronic -Generator
| 23***01 | Filter Group-Electronic; -Generator | 1 |
| 30***30 | Film-Identification; (Cat) | 1 |
| 30***34 | Film-Identification; (Caterpillar), . Flange | 1 |
240-0528 Filter Gp-Electronic -Generator
| 13***58 | Film; (Identification) (On Radiator Filler Cap) (On Near Of Radiator Filler Cap) | 1 |
| 14***43 | Film-Information; (Diesel Fuel Fill)(Info Diesel Fuel Fill) | 1 |
| 14***55 | Film-Trademark; (Caterpillar)(Trademark Caterpillar) | 1 |
332-8866 Kit-Electronic Conversion -Generator Set Control +
| 33***66 | Kit-Electronic Conversion; -Generator Set Control + | 1 |
| 4L***37 | Hex Head Capscrew, 3/8 Nc X 1 1/2 In. (38 mm) | 6 |
| 4M***25 | B. 5/16 N.C. X 1" | 18 |
236-1159 Module Gp-Alarm -Annunciator
| 23***59 | Module Group-Alarm; -Annunciator | 1 |
130-3350 Module Gp-Alarm
| 13***50 | Module Group-Alarm | 1 |
130-3325 Module Gp-Alarm
| 11***98 | Lead As | 1 |
| 13***25 | Module Group-Alarm; (Custom) | 1 |
| 3N***63 | Strip (Terminal Marker) | 1 |
130-3324 Module Gp-Alarm
| 13***92 | Screw; (M6x1x16-mm) | 4 |
| 13***24 | Module Group-Alarm | 1 |
| 1P***21 | Screw-Head; (5/16-18x1-In) | 2 |
106-5171 Module Gp-Synchronizing Lights
| 10***71 | Module Group-Synchronizing Lights | 1 |
239-6758 Mounting Gp-Control Panel -Turret
| 23***58 | Mounting Group-Control Panel; -Turret | 1 |
258-6799 Mounting Gp-Control Panel
| 25***99 | Mounting Group-Control Panel; -Door | 1 |
290-3741 Mounting Gp-Control Panel
| 29***41 | Mounting Group-Control Panel | 1 |
266-1425 Mounting Gp-Control Panel
| 26***25 | Mounting Group-Control Panel | 1 |
284-9201 Mounting Gp-Control Panel
| 28***01 | Mounting Group-Control Panel | 1 |
258-6776 Mounting Gp-Divider Plate
| 25***76 | Mounting Group-Divider Plate | 1 |
235-7943 Panel Gp-Control
| 23***43 | Panel Group-Control | 1 |
236-6508 Panel Gp-Control
| 23***08 | Panel Group-Control | 1 |
236-5836 Panel Gp-Control
| 23***36 | Panel Group-Control | 1 |
258-6800 Panel Gp-Control -Annunciator
| 25***00 | Panel Group-Control; -Annunciator | 1 |
235-8332 Panel Gp-Control
| 23***32 | Panel Group-Control | 1 |
290-3742 Panel Gp-Control
| 29***42 | Panel Group-Control | 1 |
266-1426 Panel Gp-Control -Annunciator
| 26***26 | Panel Group-Control; -Annunciator | 1 |
261-5830 Panel Gp-Control -Fuel Transfer
| 26***30 | Panel Group-Control; -Fuel Transfer | 1 |
269-8111 Panel Gp-Electrical -Battery Charger Contactor
| 26***11 | Panel Group-Electrical; -Battery Charger Contactor | 1 |
292-5967 Panel Gp-Electrical
| 29***67 | Panel Group-Electrical | 1 |
261-6623 Panel Gp-Electrical -Generator Run Relay
| 26***23 | Panel Group-Electrical; -Generator Run Relay | 1 |
261-5827 Panel Gp-Electrical -Fuel Transfer
| 26***27 | Panel Group-Electrical; -Fuel Transfer | 1 |
301-9761 Panel Gp-Electrical
| 30***61 | Panel Group-Electrical | 1 |
261-0736 Panel Gp-Electronic
| 26***36 | Panel Group-Electronic; -Control | 1 |
235-8002 Panel Gp-Electronic
| 23***02 | Panel Group-Electronic | 1 |
258-6792 Panel Gp-Electronic
| 25***92 | Panel Group-Electronic | 1 |
258-6779 Panel Gp-Electronic
| 25***79 | Panel Group-Electronic | 1 |
294-4674 Panel Gp-Electronic
| 29***74 | Panel Group-Electronic | 1 |
258-6778 Panel Gp-Electronic
| 25***78 | Panel Group-Electronic | 1 |
258-6791 Panel Gp-Electronic
| 25***91 | Panel Group-Electronic | 1 |
240-0484 Panel Gp-Electronic
| 24***84 | Panel Group-Electronic | 1 |
235-9566 Panel Gp-Electronic
| 23***66 | Panel Group-Electronic | 1 |
144-8325 Panel Gp-Instrument
| 14***25 | Panel Group-Instrument | 1 |
131-1960 Panel Gp-Instrument
| 13***60 | Panel Group-Instrument | 1 |
131-1961 Panel Gp-Instrument
| 13***61 | Panel Group-Instrument | 1 |
292-5966 Potentiometer As
| 29***66 | Potentiometer As; -Speed Adjust | 1 |
261-8464 Potentiometer As -Speed Adjust
| 26***64 | Potentiometer As; -Speed Adjust | 1 |
261-8429 Potentiometer As -Volt Adjust Avr
| 26***29 | Potentiometer As; -Volt Adjust Avr | 1 |
291-3709 Seal Gp-Enclosure
| 29***09 | Seal Group-Enclosure | 1 |
236-4560 Seal Gp-Enclosure -Grommet
| 23***60 | Seal Group-Enclosure; -Grommet | 1 |
240-5813 Seal Gp-Enclosure -Panel
| 24***13 | Seal Group-Enclosure; -Control Panel | 1 |
277-3571 Seal Gp-Enclosure
| 27***71 | Seal Group-Enclosure | 1 |
241-6078 Seal Gp-Enclosure -Grommet
| 24***78 | Seal Group-Enclosure; -Grommet | 1 |
241-3092 Seal Gp-Enclosure
| 24***92 | Seal Group-Enclosure | 1 |
Service Equipment And Supplies
6l-4502 Chart-Plate & Film
| 6L***02 | Chart-Plate & Film | 1 |
282-4077 Cover Gp-Shipping
| 28***77 | Cover Group-Shipping | 1 |
248-0969 Film Gp
| 24***69 | Film Group | 1 |
306-5105 Film Gp -Multiple Films, Locations
| 30***05 | Film Group; -Multiple Films, Locations | 1 |
252-0476 Film Gp
| 25***76 | Film Group | 1 |
4p-1782 Kit-Bus Bar
| 4P***82 | Kit-Bus Bar | 1 |
255-1085 Kit-Installation -Control Panel
| 25***85 | Kit-Installation; -Control Panel | 1 |
4p-1788 Kit-Space Heater
| 4P***88 | Kit-Space Heater; -Generator | 1 |
246-8719 Plate & Film Gp
| 24***19 | Plate & Film Group | 1 |
C18 serial number reference
The C18 engine serial number is recorded on a metal data plate affixed to the engine block; on most installations this plate is located on the left side of the block, and a second identification plate near the valve cover or timing cover carries the arrangement number and emissions certification data. The serial number consists of three alphanumeric characters (the prefix) followed by five numeric digits, for example 'WJH12345' — the total serial number is eight characters. The three-character prefix is the only portion needed to identify the engine family, application type, and which service or parts manual applies. Always read the prefix from the engine block data plate rather than from the valve-cover EPA emissions tag, as the emissions tag alone does not carry sufficient information to uniquely identify the engine variant. For machine-installed engines (such as prefix RDP), the data plate may be partially obscured by surrounding structure and may require minor clearance to read.
| Prefix | Identifies | Notes |
|---|---|---|
| CJP | C18 Truck Engine (on-highway) | C18 on-highway truck engine prefix. Service manuals cover the C18 ACERT in Class 8 truck applications. |
| MDP | C18 Truck Engine (on-highway) | C18 on-highway truck engine prefix. Grouped with CJP and MEP in the same C18 truck engine specification manual set. Exact configuration differences from CJP not publicly documented — confirm with dealer. |
| MEP | C18 Truck Engine (on-highway) | C18 on-highway truck engine prefix. Grouped with CJP and MDP in the same manual set. Exact configuration differences not publicly documented — confirm with dealer. |
| WJH | C18 Industrial Engine | C18 Industrial Engine Prefix WJH, WJH00001 and up. Production year approximately 2004. One of the earliest-documented C18 ACERT industrial serial series. |
| EJG | C18 Industrial Engine | C18 INDUSTRIAL ENGINE, prefix EJG. Production year approximately 2004. Service and electrical/hydraulic schematic manuals documented for this prefix. |
| GJE | C18 Industrial Engine | Caterpillar Cat C18 Industrial Engine (Prefix GJE) Service Repair Manual GJE00001 and up. |
| BDN | C18 Industrial Engine | Caterpillar Cat C18 Industrial Engine (Prefix BDN) Service Repair Manual BDN00001 and up. Exact configuration differences not publicly documented — confirm with dealer. |
| WJB | C18 Industrial Engine | Caterpillar Cat C18 Industrial Engine (Prefix WJB) Service Repair Manual WJB00001 and up. |
| WRH | C18 Industrial Engine (700 hp twin-turbo configuration) | C18 WRH twin-turbo industrial, 700 hp twin-turbo rating distinguishes this configuration from single-turbo C18 industrial variants. |
| JDA | C18 Industrial Engine | Caterpillar Cat C18 Industrial Engine (Prefix JDA) Service Repair Manual JDA00001 and up. Exact configuration differences not publicly documented — confirm with dealer. |
| NBB | C18 Industrial Engine | Caterpillar Cat C18 Industrial Engine (Prefix NBB) Service Repair Manual NBB00001 and up. Exact configuration differences not publicly documented — confirm with dealer. |
| ZPS | C18 Industrial Engine | Caterpillar Cat C18 Industrial Engine (Prefix ZPS) Service Repair Manual ZPS00001 and up, approximately 2013. Among the later documented C18 ACERT industrial series — confirm with dealer. |
| N8F | C18 Industrial Engine | Single confirmed independent source (avspare.com, approximately 2013) — confirm with dealer before relying on it for parts or manual selection. |
| RDP | C18 Engine-Machine (installed in heavy equipment) | C18 Caterpillar Engine-Machine (Serial Number RDP). Covers C18 as fitted in Caterpillar machine platforms (wheel loaders, excavators, motor graders, and similar). |
| STD | C18 Generator Set (land/standby) | C18 Generator Set Service Repair Manual (STD). One of the most widely referenced C18 generator set prefixes. |
| STM | C18 Generator Set (land/standby) | Paired with STD. Exact configuration differences from STD not publicly documented — confirm with dealer. |
| DKE | C18 Generator Set (land) | C18 Caterpillar Generator Set (DKE). Parts Catalog documented. |
| EKW | C18 Generator Set (land) | |
| G4C | C-18 Generator Set (land) — older hyphenated designation | Listed as 'C-18 GENERATOR SET' in IMPC's prefix table and confirmed in Caterpillar serial number prefix reference charts. The hyphenated 'C-18' label in primary sources suggests this prefix may correspond to an earlier product designation predating the C18 ACERT branding. Whether this is mechanically identical to the C18 ACERT or represents a distinct earlier product has not been confirmed in open sources — confirm with dealer before treating it as equivalent to the ACERT-era C18. |
| C6C | C18 Generator Set (land) | Exact configuration differences not publicly documented — confirm with dealer. |
| X6X | C18 Power Module | C18 POWER MODULE — packaged generating-set variant distinct from standard open-frame generator set. Confirm application specifics with dealer. |
| NAW | C18 Generator Set (land) — catalogued as 'C18 I6 Generator Set' | C18 I6 Generator Set (NAW) — inline-six catalog designation, not a distinct configuration. Confirm with dealer. |
| PEJ | C18 Generator Set (land) | C18 Caterpillar Generator Set (Serial Number PEJ) Operation and Maintenance Manual. Confirm with dealer for configuration details. |
| BG4 | C18 Generator Set (land) | C18 Generator Set (Serial No. BG4). Confirm with dealer for configuration details. |
| NR7 | C18 Generator Set (land) | C18 Generator Set NR7 Service Repair Manual. Confirm with dealer. |
| SSM | C18 Generator Set (land) | C18 CAT Generator Set (SSM) Repair Service Manual. Confirm with dealer. |
| GBM | C18 Marine Generator Set | C18 Marine Generator Set (GBM1-Up, August 2010). Operation and Maintenance Manual documented. |
| MGS | C18 Marine Generator Set | C18 Generator Set (MGS) — Marine auxiliary power application. Operation and Maintenance Manual (July 2009). |
| C1J | C18 Marine Engine (propulsion/auxiliary) | C18 Marine Engine (prefix C1J). Specific propulsion versus auxiliary distinction not confirmed — confirm with dealer. |
| CKH | C18 Marine Engine (propulsion/auxiliary) | C18 Caterpillar Marine Engine (CKH) Service Repair Manual documented. |
| CYN | C18 Marine Engine (propulsion/auxiliary) | C18 DITA (2008). Specific propulsion versus auxiliary distinction not confirmed — confirm with dealer. |
| KJT | C18 Marine Engine (propulsion/auxiliary) | C18 Marine Engine (Serial KJT). |
| NAX | C18 Marine Engine (propulsion/auxiliary) | Specific application not distinguished — confirm with dealer. |
| NAY | C18 Marine Engine (propulsion/auxiliary) | Specific application not distinguished — confirm with dealer. |
| GES | C18 Marine Engine (commercial propulsion) | C18 GES Marine Engine (GES00001 and up). Commercial marine propulsion application. |
| GEX | C18 Marine Engine (propulsion/auxiliary) | C18 Caterpillar Marine Engine (GEX) Service Repair Manual. Application specifics not confirmed — confirm with dealer. |
Frequently asked questions
What engine does the Caterpillar C18 engineer support tractor (D9T/D9) use?
The D9T (2004–2020) and current D9 (2020–present) use the Cat C18 ACERT, an 18.1-litre inline-six diesel with electronic unit injection and air-to-air aftercooling. Net power is 306–325 kW (410–436 hp) on the D9T and 328–337 kW (440–452 hp) on the current D9, varying by emissions tier.
What is the operating weight of the Cat D9 in engineer support configuration?
Operating weight varies by configuration and generation. The D9T with SU-blade and single-shank ripper weighs approximately 47,900 kg (105,600 lb); the current D9 in equivalent specification reaches approximately 49,988 kg (110,225 lb). Armoured military variants carry additional weight depending on the protection package fitted.
What model replaced the Cat D9T?
Caterpillar replaced the D9T with the Cat D9, launched in 2020. The D9 retains the C18 ACERT engine but adds a torque-converter stator clutch for improved fuel economy, an integrated AutoLube system, extended filter intervals, and an updated operator display, while reducing overall owning and operating costs compared with the D9T.
What C18 owners discuss
What powertrain and transmission behavior should D9T (C18 ACERT) operators expect, and what are the known quirks?
The D9T uses a powershift transmission with hydraulically engaged clutch packs that require Cat TO-4 specification oil — standard motor oil lacks the necessary friction-modifier additives and will cause premature clutch pack wear. Operators on Heavy Equipment Forums report that shifting under load can feel like a brief hesitation or near-stall before the gear engages; this is characteristic of the load-sensing powershift logic rather than a fault, but if hesitation becomes a lurch or a false-neutral condition, the first checks are suction screens, powertrain oil line clamps and O-rings, and clutch pack pressure at the diagnostic taps. The elevated-sprocket design isolates the final drives well above ground level, which protects them from impact loading but also means any final-drive oil seal weep is less visible during a walk-around — operators should wipe the housing flanges during every service interval. Powertrain oil analysis at each oil-change interval is the single most effective early warning for internal clutch and gear wear on high-hour machines.
What are the known engine quirks and failure modes specific to the Cat C18 ACERT across its Tier 2, Tier 3, and Tier 4 Final generations?
The C18 ACERT was introduced around 2004 and evolved through Tier 2, Tier 3, and Tier 4 Final (T4F) configurations. ACERT engines run notably higher turbocharger boost than earlier Cat engines of comparable displacement, and excessive blow-by is more common than on pre-ACERT engines; Cat addressed this with crankcase ventilation filter updates. Low boost should always be pressure-tested before condemning a turbocharger, as fuel-system issues and internal wear are frequent root causes. The high-pressure common rail fuel system is sensitive to fuel cleanliness — the majority of injector failures traced in independent diesel diagnostics link to particulate or water contamination; operators in wet or dusty environments should change fuel filters on the shorter end of the service interval range. T4F machines added a urea-based selective catalytic reduction (SCR) system; the DEF injector is prone to urea crystallisation at its nozzle tip during short-cycle or predominantly idle operation, leading to false SCR-efficiency fault codes. Have your dealer verify any persistent NOx or SCR-efficiency code before approving catalyst or injector replacement, as cleaning the nozzle or purge-line resolves the majority of cases.
What are the most commonly reported DPF and aftertreatment issues on Tier 4 Final C18-powered dozers like the D9T, and how do operators manage them?
The DPF pressure sensing ports on C13, C15, and C18 engines run along the exhaust system and are prone to soot plugging, particularly on machines that spend extended time at low load or idle. Caterpillar's own troubleshooting documentation notes that cleaning these ports resolves the majority of differential-pressure fault codes without replacing the sensor. When the DPF soot load estimate rises above roughly 80–90 percent, the ECM progressively limits engine speed and power; above 90 percent, automatic high-speed regeneration is inhibited, and a stationary forced regeneration via Cat ET diagnostic software is required. Operators report that D9T machines used in stop-and-go site work or left idling between tasks accumulate soot faster than those working sustained heavy push cycles. On Heavy Equipment Forums, a D9T owner documented fault codes linking the aftertreatment ECM losing communication on the CAN-B data link — initial troubleshooting pointed to wiring corrosion and connector backshell integrity rather than ECM failure. The DEF supply line barb connection, particularly where it passes near heat sources, is noted as a failure point on Tier 4 Final machines. Have your dealer verify any forced-regen or SCR-derating event before authorising aftertreatment component replacement.
What undercarriage wear patterns are typical for the D9T's elevated-sprocket design, and what inspection intervals do operators recommend?
The majority of sprocket tooth wear concentrates between roughly the seven and nine o'clock position as the machine moves forward, and hooking or irregular tooth profiles indicate misalignment or advanced wear that will accelerate chain-pitch elongation. Track tension is critical: tracks set too tight increase idler and roller loading significantly; tracks set too loose risk de-tracking and accelerate bushing wear. A two-dip sag between the front idler and the drive sprocket is the field rule of thumb for correct tension. Caterpillar's Custom Track Service (CTS) program uses physical measurement of link pitch, roller flanges, and idler wear faces to project remaining component life — most experienced operators and dealers recommend a CTS inspection roughly every 500–1,000 hours in abrasive conditions. Pin-and-bushing rotation is the single largest interval-based undercarriage task; pushed too far, elongated chain pitch causes rapid sprocket wear. Idler oil seals should be checked for weeping at every service, as a dry idler bearing fails quickly and can cause track derailment.
What electrical, sensor, and ECM issues do owners and technicians most commonly report on C18-powered track-type tractors?
Community consensus identifies connector and wiring integrity as the most frequent root cause of electrical faults — not failed ECMs or sensors. On Tier 4 Final machines, the CAN-B communication circuit between the engine ECM and the aftertreatment ECM is a documented weakness; corrosion at the connector backshells or bent terminals causes the aftertreatment ECM to drop off the data link intermittently, generating codes that appear to be aftertreatment hardware failures. Operators report that the DPF differential-pressure sensor circuit generates false high-soot codes when the sensing ports themselves are blocked — cleaning the ports is step one before any sensor replacement. For Tier 4 Final machines, DEF quality sensor faults can appear when the DEF tank is low or when DEF has partially crystallised in the tank during cold weather — topping up with fresh, specification-grade DEF and allowing the system to normalise clears the majority of these codes. Cat Electronic Technician (ET) software connected via an appropriate diagnostic adapter is required for active fault reading, snapshot data, and calibration on these machines. Electrical faults on safety-critical systems (braking, steering) should always be verified by a Cat dealer before returning the machine to service.
What hydraulic system behaviors and failure modes should D9T operators watch for in the blade, ripper, and steering circuits?
Operators and technicians report that the D9T's load-sensing hydraulic system can exhibit apparent blade power loss when the ripper is raised simultaneously — the load-sensing priority logic momentarily redistributes flow, which is normal behaviour, but if the drop in blade force is pronounced or repeatable, priority valve calibration and hydraulic pressure sensor condition should be checked. Blade drift (slow unintended descent when the control is in hold) is usually traceable to worn spool-valve lands inside the control valve or cylinder-seal bypass; a flow-meter test at the cylinder ports is the definitive diagnostic step. Steering intermittently locking out or entering limp mode is most commonly linked to the steering speed sensor, wiring to the steer motor solenoid valves, or a cut-off relief valve sticking open. Contaminated hydraulic oil is a common upstream cause of premature pump and valve wear; control-valve seal wear is measurably reduced by cold-weather start procedures that warm the hydraulic system under light load before full operation.
What should a buyer prioritise when inspecting a used C18-powered D9T or equivalent large track-type tractor before purchase?
Community consensus points to the undercarriage as the single most important area, because its replacement cost on a D9-class machine can be very substantial. Have a qualified technician physically measure track link pitch, sprocket tooth profile, idler tread width, and roller flange height — visual inspection alone is unreliable and dealers with Cat CTS tooling can provide a percentage-remaining wear report. Confirm the service history includes S·O·S oil analysis records; gaps in sampling are a red flag for deferred maintenance on powertrain and hydraulic circuits. For Tier 4 Final machines, request the Cat ET fault history including inactive and logged codes — a high count of aftertreatment or DEF system events indicates either poor maintenance practices or a machine used heavily at low load. Run the engine to full operating temperature and watch coolant and oil temperatures on the display. On any Tier 4 Final C18-powered machine, have your dealer pull Cat ET data and conduct a pre-purchase inspection that includes a stationary DPF regen test and aftertreatment system health check before committing to purchase.
Compiled from owner and technician discussions across the industry — experiences vary by serial range and machine history.
Serial-range & configuration variants
This page covers the Caterpillar C18. Related factory variants of the same model family:
C18C18C18C18C18C18C18C18C-18
Need a specific C18 part?
Search live OEM part data, check fitment, and cross-reference alternatives with Heavy Parts AI.
